INSULATION PACK Worcester part no. 77161922160 |
£31.35 | ||
 |
HARNESS-FLAME SENSE TO PCB BOARD Worcester part no. 87161201260 |
£5.35 | ||
 |
BLANKING CAP RED Worcester part no. 87161412110 |
£2.63 | ||
| 1 |  |
AIR PRESSURE SWITCH 28I HUBA Worcester part no. 87161461590 |
||
| 2 | GAS SENSOR CONNECTOR Worcester part no. 87161412270 |
£4.66 | ||
| 3 | NUT - CLAMPING(BRASS) Worcester part no. 87161402530 |
£3.36 | ||
| 4 | BUNG-PILOT LARGE HOLE (5 PACK) Worcester part no. 87161407070 |
£7.16 | ||
| 5 |  |
PIPE - AIR PRESSURE SWITCH Worcester part no. 87161000030 |
£16.90 | |
| 6 |  |
RED SILICONE TUBING 5M LONG Worcester part no. 87161010810 |
£17.40 | |
| 7 | POSITIVE AIR PRESS TUBE MARKER Worcester part no. 87161002770 |
£2.07 | ||
| 8 |  |
BEIGE SILICONE TUBING 1M LONG Worcester part no. 87161010800 |
£9.29 | |
| 9 |  |
PRB 20/501 G/W HEAT EXCHANGER Worcester part no. 87161429050 |
£305.28 | |
| 10 |  |
AUTOMATIC PURGER Worcester part no. 87161405040 |
£11.55 | |
| 11 |  |
T/STAT RANCO LM7 P9024 (LIMIT) Worcester part no. 87161423070 |
£24.78 | |
| 12 |  |
PIN RETAINING Worcester part no. 87161483420 |
£2.83 | |
| 13 |  |
BURNER ASSEMBLY NG Worcester part no. 87161426520 |
£65.85 | |
| 14 |  |
FLAME SENCE ELECTRODE AND HARNESS Worcester part no. 87161203450 |
£11.64 | |
| 15 |  |
ELECTRODE SPARK AFTER FD292 Worcester part no. 87161051860 |
£12.43 | |
| 15 |  |
SPARK ELECTRODE ASSEMBLY BEFORE FD291 Worcester part no. 87161421000 |
£8.13 | |
| 16 |  |
NUT M4 EXTENDED Worcester part no. 87161401020 |
£4.94 | |
| 17 |  |
CLIP - FLUE HOOD RETAINING Worcester part no. 87161483050 |
£2.11 | |
| 18 |  |
COMBUSTION CHAMBER COVER Worcester part no. 87161002650 |
£19.10 | |
| 19 |  |
COLLECTOR HOOD ASSEMBLY Worcester part no. 87161212270 |
||
| 20 |  |
FAN ASSEMBLY 28I Worcester part no. 87161216810 |
£111.02 | |
| 21 |  |
AIR FLOW SENSOR Worcester part no. 87161410000 |
£8.26 | |
| 22 |  |
HARNESS FAN 24/28I Worcester part no. 87161209800 |
£6.79 | |
| 23 |  |
HARNESS IGNITION ASSEMBLY Worcester part no. 87161202360 |
||
| 24 |  |
RUBBER GROMMET Worcester part no. 87161407080 |
||
| 25 |  |
INNER CASING COVER ASSEMBLY Worcester part no. 87161202540 |
||
| 26 |  |
SEAL Worcester part no. 87161006400 |
£12.57 | |
| 27 |  |
NUT CAPTIVE NO:8 Worcester part no. 87161482040 |
£4.24 | |
| 28 | BURNER GAUZE Worcester part no. 87161426010 |
£19.27 | ||
| 29 |  |
SCREW M4X8 (3X) AFTER FD992 AND BEFORE FD111 Worcester part no. 29144114120 |
£2.68 | |
| 30 |  |
FIBRE WASHER 23.9 X 17.2 X 1.5 Worcester part no. 87101030430 |
£2.84 | |
| 30 |  |
WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991 Worcester part no. 87161156740 |
£2.84 | |
| 31 |  |
WASHER 18.6 X 13.5 X 1.5 (10X) Worcester part no. 87101030450 |
£2.95 | |
| 31 |  |
WASHER 18.6 X 13.5 X 1.5 (1X) Worcester part no. 87161156800 |
£0.86 | |
| 32 |  |
SCREW (10X) 8X1/2" AFTER FD992 Worcester part no. 87161153060 |
£3.59 | |
| 33 |  |
SCREW M3X6MM ZC PL P/H TAPTITE AFTER FD992 Worcester part no. 29144114110 |
£2.79 | |
| 34 |  |
INSULATION-REAR(2302) Worcester part no. 87161422090 |
£16.75 | |
| 35 |  |
INSULATION-SIDE Worcester part no. 87161422100 |
£25.17 | |
| 36 |  |
INSULATION-FRONT Worcester part no. 87161422110 |
£16.75 | |
