1 |
|
OBSOLETE OUTER BACK RIVETED A Valor Gas Fire part no. 0507769 |
|
2 |
|
OBSOLETE HEAT EXCH UNIT ASSY Valor Gas Fire part no. 0504729 |
|
3 |
|
OBSOLETE LH HEAT EX/OUTER BACK Valor Gas Fire part no. 0504739 |
|
4 |
|
OBSOLETE RH HEAT EX/OUTER BACK Valor Gas Fire part no. 0504749 |
|
6 |
|
OBSOLETE HT EX/FIREBOX BRKT Valor Gas Fire part no. 0504759 |
|
8 |
|
OBSOLETE GASKET Valor Gas Fire part no. 0504769 |
|
9 |
|
OBSOLETE NO.8X1/2 POZI PAN BLACK SCREW Valor Gas Fire part no. 0548989 |
|
9 |
|
OBSOLETE OUTER BACK FORWARD EX Valor Gas Fire part no. 0557119 |
|
10 |
|
OBSOLETE SCREW Valor Gas Fire part no. 0513059 |
|
11 |
|
OBSOLETE FLUE BAFFLE ASSY Valor Gas Fire part no. 0507779 |
|
12 |
|
OBSOLETE EARTH LEAD ASSY Valor Gas Fire part no. 0504779 |
|
13 |
|
OBSOLETE NO8X3/8 SELF TAP SCREW Valor Gas Fire part no. 0536809 |
|
14 |
|
OBSOLETE RH TOP WALL MTG BRKT Valor Gas Fire part no. 0507789 |
|
15 |
|
OBSOLETE LH TOP WALL MTG BRKT Valor Gas Fire part no. 0507799 |
|
17 |
|
OBSOLETE TAP FIXING BRKT Valor Gas Fire part no. 0504789 |
|
18 |
|
OBSOLETE GAS TAP Valor Gas Fire part no. 0504799 |
|
19 |
|
OBSOLETE CONTROL SPINDLE ADAPTER Valor Gas Fire part no. 0516669 |
|
20 |
|
OBSOLETE COTTER PIN Valor Gas Fire part no. 0528389 |
|
21 |
|
OBSOLETE CONTROL SPINDLE Valor Gas Fire part no. 0504809 |
|
22 |
|
OBSOLETE TENSION 160/180 PIN Valor Gas Fire part no. 0516679 |
|
23 |
|
LOCK NUT Valor Gas Fire part no. 0502739 |
|
25 |
|
OBSOLETE RH FOOT & RIVNUT ASSY Valor Gas Fire part no. 0507809 |
|
26 |
|
OBSOLETE LH FOOT & RIVNUT ASSY Valor Gas Fire part no. 0507819 |
|
27 |
|
OBSOLETE LEVELLING SCREW Valor Gas Fire part no. 0535979 |
|
28 |
|
OBSOLETE NUT Valor Gas Fire part no. 0532259 |
|
28 |
|
OBSOLETE SCREW M6X16 PAN POZI Valor Gas Fire part no. 0507929 |
|
28 |
|
OBSOLETE FOOT EXT & RIVNUT ASSY Valor Gas Fire part no. 0507919 |
|
29 |
|
OBSOLETE AIR GUIDE TRAY Valor Gas Fire part no. 0505319 |
|
31 |
|
OBSOLETE BOTTOM WALL MTG BRKT Valor Gas Fire part no. 0507829 |
|
32 |
|
M4X12 POZI PAN TT CH/B Valor Gas Fire part no. 0552839 |
|
33 |
|
OBSOLETE FIREBOX WELDED ASSY Valor Gas Fire part no. 0504839 |
|
34 |
|
OBSOLETE FIREBOX LOCATION BRKT Valor Gas Fire part no. 0504849 |
|
35 |
|
OBSOLETE FIREBOX EXTENSION Valor Gas Fire part no. 0504859 |
|
36 |
|
OBSOLETE SCREW Valor Gas Fire part no. 0534729 |
|
36 |
|
OBSOLETE IGNITION REPLACEMENT K Valor Gas Fire part no. 0507689 |
|
37 |
|
OBSOLETE SPARK & EARTH ELECTRODE ASSY Valor Gas Fire part no. 0504869 |
|
38 |
|
OBSOLETE THERMOCOUPLE Valor Gas Fire part no. 0504879 |
|
40 |
|
OBSOLETE FIREBOX FRONT TOP PLATE ASSY Valor Gas Fire part no. 0504889 |
|
41 |
|
OBSOLETE M5 STUD Valor Gas Fire part no. 0549319 |
|
42 |
|
OBSOLETE WINDOW SEAL 463 Valor Gas Fire part no. 0504899 |
|
43 |
|
OBSOLETE STAPLE Valor Gas Fire part no. 0504909 |
|
44 |
|
OBSOLETE TOP FRONT PLATE GASKET Valor Gas Fire part no. 0504919 |
|
45 |
|
OBSOLETE FRONT TOP PLATE SIDE GASKET Valor Gas Fire part no. 0504929 |
|
47 |
|
OBSOLETE RH REAR CASE SIDE EXT Valor Gas Fire part no. 0507889 |
|
48 |
|
OBSOLETE LH REAR CASE SIDE EXT Valor Gas Fire part no. 0507899 |
|
50 |
|
OBSOLETE BURNER BOX UNIT ASSY Valor Gas Fire part no. 0504939 |
|
52 |
|
INJECTOR Valor Gas Fire part no. 0504949 |
|
54 |
|
OBSOLETE FRONT FUEL SUPPORT ASSY Valor Gas Fire part no. 0504959 |
|
56 |
|
OBSOLETE FLAME BUR. REST/TOR Valor Gas Fire part no. 0548579 |
|
57 |
|
OBSOLETE PIPE ASSY - TAP/FLAME BNR Valor Gas Fire part no. 0504969 |
|
58 |
|
OBSOLETE PIPE ASSY TAP/FRONT INJ Valor Gas Fire part no. 0504979 |
|
59 |
|
OBSOLETE PIPE ASSY - TAP/REAR INJ Valor Gas Fire part no. 0504989 |
|
60 |
|
OBSOLETE INLET PIPE ASSY Valor Gas Fire part no. 0507839 |
|
61 |
|
OBSOLETE INLET PIPE RETAINING Valor Gas Fire part no. 0517199 |
|
63 |
|
OBSOLETE F.E BNR ASSY Valor Gas Fire part no. 0505009 |
|
64 |
|
OBSOLETE M3.X 6 SCREW Valor Gas Fire part no. 0547299 |
|
65 |
|
ELBOW Valor Gas Fire part no. 0532519 |
|
66 |
|
OBSOLETE COAL BED Valor Gas Fire part no. 0505019 |
|
67 |
|
OBSOLETE WINDOW UNIT ASSY 460 Valor Gas Fire part no. 0505029 |
|
68 |
|
OBSOLETE RH HEATSHIELD EXTENSION Valor Gas Fire part no. 0507909 |
|
68 |
|
OBSOLETE NO.6AB X 5/8 PZ PN BL Valor Gas Fire part no. 0557389 |
|
68 |
|
OBSOLETE WING NUT Valor Gas Fire part no. 0533249 |
|
68 |
|
OBSOLETE NUT WING M5 SN Valor Gas Fire part no. 636102 |
|
69 |
|
OBSOLETE REAR CASE WELDED ASSY Valor Gas Fire part no. 0507419 |
|
72 |
|
OBSOLETE BEZEL INSULATION Valor Gas Fire part no. 0557249 |
|
73 |
|
OBSOLETE CONTROL KNOB Valor Gas Fire part no. 0505049 |
|
74 |
|
OBSOLETE CONTROLS BEZEL Valor Gas Fire part no. 0557259 |
|
75 |
|
OBSOLETE BUTTON Valor Gas Fire part no. 0516819 |
|
76 |
|
PIEZO IGNITOR UNIT Valor Gas Fire part no. 0507669 |
|
77 |
|
OBSOLETE INSULATION SLEEVE Valor Gas Fire part no. 0505279 |
|
77 |
|
OBSOLETE ELECTRODE LEAD Valor Gas Fire part no. 0505069 |
|
78 |
|
OBSOLETE EDGE REF:22440-07CLI Valor Gas Fire part no. 0549519 |
|
79 |
|
OBSOLETE CABLE/PIPE CLIP (EDGE TYPE) - SPRING Valor Gas Fire part no. 080160179 |
|
79 |
|
OBSOLETE EDGE CLIP Valor Gas Fire part no. 0507679 |
|
80 |
|
OBSOLETE RH CASING SIDE HEATSHIELD Valor Gas Fire part no. 0507939 |
|
81 |
|
OBSOLETE LH CASING SIDE HEATSHIELD Valor Gas Fire part no. 0507949 |
|
82 |
|
OBSOLETE KNURLED THUMB NUT Valor Gas Fire part no. 0514679 |
|
83 |
|
OBSOLETE .8MM BLACK FIBRE WASHER Valor Gas Fire part no. 0549419 |
|
84 |
|
OBSOLETE OUTER CASE FRONT Valor Gas Fire part no. 0557359 |
|
84 |
|
OBSOLETE OUTER CASE FRONT TEAK Valor Gas Fire part no. 0557619 |
|
85 |
|
OBSOLETE OUTER CASE LOCATING SCREW Valor Gas Fire part no. 0557399 |
|
87 |
|
OBSOLETE OUTER CASE TOP H/SHIE Valor Gas Fire part no. 0557409 |
|
87 |
|
OBSOLETE HEAT DEFLECTOR BRACKE Valor Gas Fire part no. 0557419 |
|
89 |
|
OBSOLETE RADIANT TRIM SECURING BRKT Valor Gas Fire part no. 0507959 |
|
91 |
|
OBSOLETE BOTTOM CASE EXTENSION Valor Gas Fire part no. 0507969 |
|
93 |
|
OBSOLETE BOTTOM HEAT DEFLECTOR Valor Gas Fire part no. 0507989 |
|
94 |
|
OBSOLETE LOWER AIR GRILLE ASS Valor Gas Fire part no. 0557459 |
|
95 |
|
OBSOLETE L/H BOTTOM GRILLE RETAINING BR Valor Gas Fire part no. 0557469 |
|
96 |
|
OBSOLETE R/H BOTTOM GRILLE RET Valor Gas Fire part no. 0557489 |
|
97 |
|
OBSOLETE LH BOTTOM GRILLE RET. Valor Gas Fire part no. 0557479 |
|
98 |
|
OBSOLETE BTM GRILLE RETAINING Valor Gas Fire part no. 0557499 |
|
101 |
|
OBSOLETE HEAT DEFLECTOR ASS Valor Gas Fire part no. 0557509 |
|
104 |
|
OBSOLETE UPPER AIR GRILLE ASS Valor Gas Fire part no. 0557519 |
|
105 |
|
OBSOLETE L/H TOP GRILLE RETEA Valor Gas Fire part no. 0557529 |
|
106 |
|
OBSOLETE R/H TOP GRILLE RETAINING BRKT Valor Gas Fire part no. 0557539 |
|
109 |
|
OBSOLETE L/H SIDE CASE EXT ASS Valor Gas Fire part no. 0557549 |
|
110 |
|
OBSOLETE R/H SIDE CASE EXT ASSY Valor Gas Fire part no. 0557559 |
|
111 |
|
OBSOLETE M5 STUD Valor Gas Fire part no. 0557569 |
|
113 |
|
OBSOLETE RADIANT TRIM Valor Gas Fire part no. 0507999 |
|
114 |
|
OBSOLETE GRILLE BAR Valor Gas Fire part no. 0508059 |
|
115 |
|
OBSOLETE SCREW Valor Gas Fire part no. 0508079 |
|
116 |
|
OBSOLETE M4X0.8 SCANDURA NOVUS Valor Gas Fire part no. 0557599 |
|
117 |
|
OBSOLETE STRAIGHT GRILLE BAR Valor Gas Fire part no. 0508069 |
|
118 |
|
OBSOLETE SCREW Valor Gas Fire part no. 0508089 |
|
119 |
|
OBSOLETE WASHER Valor Gas Fire part no. 0508099 |
|
120 |
|
SCREW Valor Gas Fire part no. 0508109 |
|
120 |
|
OBSOLETE NAME BADGE Valor Gas Fire part no. 0507979 |
|
120 |
|
OBSOLETE NAME BADGE Valor Gas Fire part no. 0508029 |
|
121 |
|
OBSOLETE CLOSURE PLATE Valor Gas Fire part no. 0507429 |
|
122 |
|
OBSOLETE FLUE SPIGOT Valor Gas Fire part no. 0507879 |
|
123 |
|
8X3/8 SCREW Valor Gas Fire part no. 0511569 |
|
124 |
|
OBSOLETE 12X2 RD HD SLOT ZP WD/SCREW Valor Gas Fire part no. 0549759 |
|
125 |
|
OBSOLETE NO.12 HEAVY DUTY WALL PLUG Valor Gas Fire part no. 0516879 |
|
126 |
|
OBSOLETE USERS INSTRUCTIONS Valor Gas Fire part no. 0508049 |
|
126 |
|
OBSOLETE USERS INSTRUCTIONS Valor Gas Fire part no. 0508019 |
|
127 |
|
OBSOLETE INSTALLATION INSTRUCTIONS Valor Gas Fire part no. 0508009 |
|
127 |
|
OBSOLETE INSTALLATION INSTRUCTIONS Valor Gas Fire part no. 0508039 |
|
