VAILLANT
MAG-SINE 325/9 TZWFH - (Accessories)
Appliance Code: 52-044-12

Appliance Diagram


Accessories diagram for Vaillant Mag-Sine 325/9 TZWFHClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE GAS REGULATOR
Vaillant part no. 085642
2 Part number 980902, packing ring PACKING RING
Vaillant part no. 980902		 £3.91
3 Part number 195044, OBSOLETE magneto housing OBSOLETE MAGNETO HOUSING
Vaillant part no. 195044
4 Part number 170327, magneto MAGNETO
Vaillant part no. 170327		 £15.31
5 Part number 982310, O-ring O-RING
Vaillant part no. 982310
6   OBSOLETE PACKING RING
Vaillant part no. 980916
8   OBSOLETE PACKING RING
Vaillant part no. 981624
9 Part number 091065, piezo ignition PIEZO IGNITION
Vaillant part no. 091065		 £12.45
9 Part number 91065, NOW USE 091065 piezo ignition NOW USE 091065 PIEZO IGNITION
Vaillant part no. 91065
10   THROTTLE GUIDE
Vaillant part no. 183501		 £17.89
11 Part number 982319, O-ring O-RING
Vaillant part no. 982319		 £5.13
12 Part number 118936, Cheese head screw KS/S CHEESE HEAD SCREW KS/S
Vaillant part no. 118936		 £5.13
13 Part number 980212, NOW USE 981162 packing ring NOW USE 981162 PACKING RING
Vaillant part no. 980212
13 Part number 981162, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981162		 £5.13
14 Part number 292211, binding ring BINDING RING
Vaillant part no. 292211		 £12.81
15 Part number 105812, cylinder screw CYLINDER SCREW
Vaillant part no. 105812		 £3.91
16 Part number 10347, diaphragm, cpl. DIAPHRAGM, CPL.
Vaillant part no. 10347
16 Part number 010347, Diaphragm DIAPHRAGM
Vaillant part no. 010347
17 Part number 0020028121, Water Filter WATER FILTER
Vaillant part no. 0020028121
17   WATER FILTER
Vaillant part no. 128516
18 Part number 012837, NOW USE 0020107791 venturi NOW USE 0020107791 VENTURI
Vaillant part no. 012837
18 Part number 0020107791, VENTURI VENTURI
Vaillant part no. 0020107791		 £6.66
19 Part number 012546, temperature selector TEMPERATURE SELECTOR
Vaillant part no. 012546		 £11.10
19 Part number 12546, NOW USE 012546 temperature selector NOW USE 012546 TEMPERATURE SELECTOR
Vaillant part no. 12546
20 Part number 981175, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981175
21 Part number 981159, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981159		 £6.66
22 Part number 010050, screw SCREW
Vaillant part no. 010050		 £6.66
22 Part number 10050, NOW USE 010050 SCREW NOW USE 010050 SCREW
Vaillant part no. 10050
23 Part number 012946, Water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 012946		 £6.66
23 Part number 12946, NOW USE 012946 water quantity regulator, cpl. NOW USE 012946 WATER QUANTITY REGULATOR, CPL.
Vaillant part no. 12946
24 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
25 Part number 203038, OBSOLETE piston (grey) OBSOLETE PISTON (GREY)
Vaillant part no. 203038
26 Part number 982484, O-ring O-RING
Vaillant part no. 982484
27 Part number 60036, NOW USE 060036 spring lock washer NOW USE 060036 SPRING LOCK WASHER
Vaillant part no. 60036
27 Part number 060036, spring lock washer SPRING LOCK WASHER
Vaillant part no. 060036		 £3.91
28 Part number 0020107732, BUTTON (KNOB) BUTTON (KNOB)
Vaillant part no. 0020107732		 £3.91
28 Part number 143980, NOW USE 0020107732 knob NOW USE 0020107732 KNOB
Vaillant part no. 143980
29 Part number 981152, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981152		 £7.03
30 Part number 981161, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981161		 £6.66
31   OBSOLETE DRAIN NIPPLE
Vaillant part no. 010118
32   OBSOLETE UNIVERSAL BURNER
Vaillant part no. 041148
33 Part number 040171, OBSOLETE burner chamber group, left OBSOLETE BURNER CHAMBER GROUP, LEFT
Vaillant part no. 040171
34   OBSOLETE BURNER CHAMBER GROUP, RIGHT
Vaillant part no. 040172
35   OBSOLETE COVER PLATE
Vaillant part no. 070456
36   OBSOLETE
Vaillant part no. 284407
37   OBSOLETE BURNER NOZZLE
Vaillant part no. 040084
38 Part number 980285, packing ring PACKING RING
Vaillant part no. 980285		 £3.91
39   NOW USE 049806 THROTTLE JET 4 X 3.40
Vaillant part no. 49806
39   THROTTLE JET 4 X 3.40
Vaillant part no. 049806
40 Part number 042667, OBSOLETE pilot burner, cpl. OBSOLETE PILOT BURNER, CPL.
Vaillant part no. 042667
42 Part number 192119, protection sheet PROTECTION SHEET
Vaillant part no. 192119		 £10.48
43   NOW USE 040523 NUT
Vaillant part no. 40523
43   NUT
Vaillant part no. 040523		 £3.91
44 Part number 040516, air filter AIR FILTER
Vaillant part no. 040516
44 Part number 40516, air filter AIR FILTER
Vaillant part no. 40516
46 Part number 042816, NOW USE 0020078902 pilot burner nozzle (D= 0.30 mm) NOW USE 0020078902 PILOT BURNER NOZZLE (D= 0.30 MM)
Vaillant part no. 042816
46 Part number 0020078902, Injector INJECTOR
Vaillant part no. 0020078902		 £6.66
47 Part number 981145, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981145		 £6.66
47 Part number 980225, NOW USE 981145 packing ring NOW USE 981145 PACKING RING
Vaillant part no. 980225
50 Part number 182618, OBSOLETE screw M10x1 OBSOLETE SCREW M10X1
Vaillant part no. 182618
51   NOW USE 089549 CONNECTION LINE
Vaillant part no. 89549
51 Part number 089549, connection line CONNECTION LINE
Vaillant part no. 089549		 £3.91
52 Part number 171140, thermo-couple THERMO-COUPLE
Vaillant part no. 171140
53 Part number 980766, NOW USE 0010027618 seal NOW USE 0010027618 SEAL
Vaillant part no. 980766
53   GASKET, (X5)
Vaillant part no. 0010027618		 £5.80
54 Part number 060018, screw SCREW
Vaillant part no. 060018		 £6.66
54 Part number 60018, NOW USE 060018 screw NOW USE 060018 SCREW
Vaillant part no. 60018
56   NOW USE 080093 DOUBLE NUT
Vaillant part no. 80093
56   DOUBLE NUT
Vaillant part no. 080093		 £7.37
58 Part number 0020107726, BUSH BUSH
Vaillant part no. 0020107726		 £5.13
58 Part number 173713, NOW USE 0020107726 locking nut NOW USE 0020107726 LOCKING NUT
Vaillant part no. 173713
59   OBSOLETE CAP
Vaillant part no. 072345
61 Part number 980763, packing ring PACKING RING
Vaillant part no. 980763		 £5.55
62   OBSOLETE FLUE BEND
Vaillant part no. 116623
63 Part number 492032, Washer WASHER
Vaillant part no. 492032		 £5.63
64   OBSOLETE PACKING RING
Vaillant part no. 981814
65 Part number 235738, Tapping screw TAPPING SCREW
Vaillant part no. 235738
66 Part number 235727, screw SCREW
Vaillant part no. 235727		 £5.13
67   OBSOLETE SEALING PROFILE
Vaillant part no. 282815
68 Part number 280204, OBSOLETE clip OBSOLETE CLIP
Vaillant part no. 280204
70 Part number 282249, INSPECTION WINDOW RING INSPECTION WINDOW RING
Vaillant part no. 282249		 £3.91
71 Part number 981746, packing ring PACKING RING
Vaillant part no. 981746		 £3.91
72 Part number 161225, OBSOLETE Inspection glass OBSOLETE INSPECTION GLASS
Vaillant part no. 161225
73   OBSOLETE DISC
Vaillant part no. 950242
74 Part number 235748, Tapping screw ISO 7049 TAPPING SCREW ISO 7049
Vaillant part no. 235748		 £5.13
76   OBSOLETE SEALING PROFILE
Vaillant part no. 282836
78 Part number 0020085467, Gasket GASKET
Vaillant part no. 0020085467		 £6.54
78 Part number 980765, NOW USE 0020085467 grommet NOW USE 0020085467 GROMMET
Vaillant part no. 980765
79   OBSOLETE PACKING RING
Vaillant part no. 980832
80 Part number 105804, cylinder screw CYLINDER SCREW
Vaillant part no. 105804		 £5.13
81   OBSOLETE PUSH BUTTON
Vaillant part no. 285517
82 Part number 75544, NOW USE 075544 covering plate NOW USE 075544 COVERING PLATE
Vaillant part no. 75544
82 Part number 075544, covering plate COVERING PLATE
Vaillant part no. 075544		 £3.91
84   WARM WATER TUBE
Vaillant part no. 083965
84   WARM WATER TUBE
Vaillant part no. 83965
86   OBSOLETE GAS FILTER
Vaillant part no. 108921
87   SEALING RING
Vaillant part no. 981756		 £5.13
88   PLUG
Vaillant part no. 137262		 £9.76
89 Part number 82741, NOW USE 082741 gas shut-off valve NOW USE 082741 GAS SHUT-OFF VALVE
Vaillant part no. 82741
89 Part number 082741, gas shut-off valve VC221T H, 110T H VC 182 E H, VC 242 E H, VC 282 E H GAS SHUT-OFF VALVE VC221T H, 110T H VC 182 E H, VC 242 E H, VC 282 E H
Vaillant part no. 082741
90   OBSOLETE TUBE
Vaillant part no. 137439
91 Part number 981169, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981169		 £6.66
92 Part number 950088, rose ROSE
Vaillant part no. 950088		 £6.66
94   OBSOLETE WARM WATER CONNECTION
Vaillant part no. 081156
95 Part number 950017, Cap CAP
Vaillant part no. 950017		 £6.66
96   OBSOLETE COLD WATER CONNECTION VALVE
Vaillant part no. 081726
98 Part number 981605, Washer WASHER
Vaillant part no. 981605
99 Part number 950057, upper part of valve UPPER PART OF VALVE
Vaillant part no. 950057
100 Part number 143981, knob KNOB
Vaillant part no. 143981
165 Part number 114848, Hexagon nut HEXAGON NUT
Vaillant part no. 114848		 £3.91
166   OBSOLETE WALL CASE INNER PART
Vaillant part no. 073112
166   OBSOLETE
Vaillant part no. 073126
166   OBSOLETE WALL CASE INNER PART
Vaillant part no. 073114
166   OBSOLETE WALL CASE INNER PART
Vaillant part no. 073116
166   OBSOLETE WALL CASE INNER PART
Vaillant part no. 073110
167   OBSOLETE SUPPORT
Vaillant part no. 086527
168   OBSOLETE DISC
Vaillant part no. 191350
169   OBSOLETE NUT
Vaillant part no. 212718
170   OBSOLETE SUPPORT
Vaillant part no. 086103
171   OBSOLETE SCREW
Vaillant part no. 202612
172   NUT
Vaillant part no. 950237		 £3.91
174   OBSOLETE DISC
Vaillant part no. 284030
175   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145575
175   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145574
175   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145576
176   OBSOLETE OUTER PART - 130MM
Vaillant part no. 073020
176   OBSOLETE WALL CASE EXTERIOR PART
Vaillant part no. 073021
176   OBSOLETE WALL CASE EXTERIOR PART
Vaillant part no. 073019
177   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145518
177   OBSOLETE FLUE EXTENSION DUCT
Vaillant part no. 145516
179   BUSH
Vaillant part no. 124835		 £3.91
180   OBSOLETE SAFETY DISC
Vaillant part no. 115520
181   OBSOLETE SEALING PROFILE
Vaillant part no. 282822
182   OBSOLETE SNAP NUT
Vaillant part no. 158209
183   OBSOLETE WASHER
Vaillant part no. 286401
