VAILLANT
COMBI COMPACT FF VCW 282 E 1988-1995 - (08b Acc.-Connection Parts)
Appliance Code: 47-044-18

Appliance Diagram


08b Acc.-Connection Parts diagram for Vaillant Combi Compact FF VCW 282 E 1988-1995Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 080177, nut NUT
Vaillant part no. 080177
£6.66
2 Part number 080184, Compression ring, 20 mm COMPRESSION RING, 20 MM
Vaillant part no. 080184
£6.66
3 Part number 114838, Hexagonal nut G 3/4 HEXAGONAL NUT G 3/4
Vaillant part no. 114838

4 Part number 081714, NOW USE 0020107747 cold water connection valve NOW USE 0020107747 COLD WATER CONNECTION VALVE
Vaillant part no. 081714

4 Part number 0020107747, Valve VALVE
Vaillant part no. 0020107747
£43.86
5 Part number 981605, Washer WASHER
Vaillant part no. 981605

6 Part number 950057, upper part of valve UPPER PART OF VALVE
Vaillant part no. 950057

7 Part number 143981, knob KNOB
Vaillant part no. 143981

9 Part number 981161, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981161
£6.66
10 Part number 981152, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981152
£7.03
11 Part number 980410, olive OLIVE
Vaillant part no. 980410

12 Part number 111328, Sleeve nut SLEEVE NUT
Vaillant part no. 111328
£5.63
13 Part number 981166, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981166
£6.66
14 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015
£6.66
15 Part number 190721, pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190721
£32.54
17 Part number 080945, OBSOLETE cold water connection OBSOLETE COLD WATER CONNECTION
Vaillant part no. 080945

18 Part number 081144, Tube (warm water connection) TUBE (WARM WATER CONNECTION)
Vaillant part no. 081144
£13.29
19 Part number 080537, nut NUT
Vaillant part no. 080537
£4.36
