VAILLANT
ECOMAX 828/2E VUW 286/2-C 2001-2007 - (08 Connection Parts)
Appliance Code: 47-044-17

Appliance Diagram


08 Connection Parts diagram for Vaillant Ecomax 828/2E VUW 286/2-C 2001-2007Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 022736, Tube TUBE
Vaillant part no. 022736		 £30.77
2 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140		 £7.05
3 Part number 140015, Screw - De-aeration SCREW - DE-AERATION
Vaillant part no. 140015		 £6.66
4 Part number 080387, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 080387		 £12.57
5 Part number 0020052092, Clamp (PK2) CLAMP (PK2)
Vaillant part no. 0020052092		 £6.66
6 Part number 252805, Sensor - NTC SENSOR - NTC
Vaillant part no. 252805		 £22.68
6 Part number 733171, flat plug FLAT PLUG
Vaillant part no. 733171
7 Part number 022745, Connection tube CONNECTION TUBE
Vaillant part no. 022745		 £74.28
8 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
9 Part number 022739, Connection tube CONNECTION TUBE
Vaillant part no. 022739
10 Part number 981151, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981151		 £7.86
11 Part number 981234, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981234		 £7.05
12 Part number 160949, pump PUMP
Vaillant part no. 160949		 £147.54
13 Part number 118951, Pan head screw, M6x28,5 PAN HEAD SCREW, M6X28,5
Vaillant part no. 118951		 £4.92
14 Part number 022740, Connection tube CONNECTION TUBE
Vaillant part no. 022740
15 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £7.96
16 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
17 Part number 150238, automatic bypass valve AUTOMATIC BYPASS VALVE
Vaillant part no. 150238		 £32.27
18 Part number 252457, Diverter valve DIVERTER VALVE
Vaillant part no. 252457		 £139.42
19 Part number 140429, Actuator - diverter valve ACTUATOR - DIVERTER VALVE
Vaillant part no. 140429		 £57.18
20 Part number 022746, Connection tube CONNECTION TUBE
Vaillant part no. 022746
21 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
22 Part number 219622, Spring clamp (PK10) SPRING CLAMP (PK10)
Vaillant part no. 219622		 £9.49
23 Part number 022744, Connection tube CONNECTION TUBE
Vaillant part no. 022744		 £26.17
24 Part number 022743, Connection tube CONNECTION TUBE
Vaillant part no. 022743		 £30.71
25 Part number 194830, Impeller aqua sensor IMPELLER AQUA SENSOR
Vaillant part no. 194830		 £102.54
26 Part number 711933, Sensor, hall effect SENSOR, HALL EFFECT
Vaillant part no. 711933		 £22.46
27 Part number 256149, Wiring harness WIRING HARNESS
Vaillant part no. 256149
28 Part number 256137, cable tree CABLE TREE
Vaillant part no. 256137		 £126.82
29 Part number 136376, NOW USE 0010047543 nipple NOW USE 0010047543 NIPPLE
Vaillant part no. 136376
29   NIPPLE
Vaillant part no. 0010047543		 £1.60
30 Part number 074517, Filter FILTER
Vaillant part no. 074517		 £11.55
31 Part number 061707, automatic de-aerator AUTOMATIC DE-AERATOR
Vaillant part no. 061707		 £19.76
32 Part number 022640, Tube TUBE
Vaillant part no. 022640		 £29.58
33 Part number 160969, pump PUMP
Vaillant part no. 160969		 £186.53
34 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7.03
35 Part number 022669, Connection tube CONNECTION TUBE
Vaillant part no. 022669		 £29.58
36 Part number 022668, Tube TUBE
Vaillant part no. 022668		 £37.75
37 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.03
38 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154		 £6.69
39 Part number 022673, Tube (M12x1) TUBE (M12X1)
Vaillant part no. 022673		 £10.45
40 Part number 981146, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981146		 £6.69
41 Part number 014720, drain cock DRAIN COCK
Vaillant part no. 014720		 £51.58
42 Part number 095610, Tube, flexible TUBE, FLEXIBLE
Vaillant part no. 095610		 £17.58
43 Part number 981165, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981165		 £6.69
44 Part number 014676, Non-return valve NON-RETURN VALVE
Vaillant part no. 014676		 £19.20
45 Part number 022675, Tube TUBE
Vaillant part no. 022675
46 Part number 190728, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190728		 £28.14
47 Part number 022596, Tube (G 1/4) TUBE (G 1/4)
Vaillant part no. 022596		 £15.62
48 Part number 022597, Tube TUBE
Vaillant part no. 022597		 £10.13
49 Part number 190751, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 190751		 £81.42
50 Part number 014738, Drain cock (M12x1/G1/4) DRAIN COCK (M12X1/G1/4)
Vaillant part no. 014738		 £26.99
51 Part number 219636, Clip (PK2) CLIP (PK2)
Vaillant part no. 219636		 £7.05
52 Part number 113952, Tube TUBE
Vaillant part no. 113952		 £30.16
53 Part number 712087, pressure sensor PRESSURE SENSOR
Vaillant part no. 712087		 £22.89
