VAILLANT
COMPACT BF VCW GB 221T - (01B Water Valve From 05/95)
Appliance Code: 47-044-14

Appliance Diagram


01B Water Valve From 05/95 diagram for Vaillant Compact BF VCW GB 221TClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 011299, Water valve WATER VALVE
Vaillant part no. 011299
£149.10
2 Part number 012162, Stuffing box (PK5) STUFFING BOX (PK5)
Vaillant part no. 012162

2 Part number 013061, Water valve, upper part WATER VALVE, UPPER PART
Vaillant part no. 013061
£13.99
3 Part number 010359, Diaphragm DIAPHRAGM
Vaillant part no. 010359
£10.13
4   PRICE ON APPLICATION
Vaillant part no. 0000

5 Part number 118959, lens head screw LENS HEAD SCREW
Vaillant part no. 118959
£5.13
6 Part number 012554, OBSOLETE temperature selector OBSOLETE TEMPERATURE SELECTOR
Vaillant part no. 012554

7 Part number 981175, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981175

8 Part number 125117, handle HANDLE
Vaillant part no. 125117
£5.13
9 Part number 105744, Cheese head screw CHEESE HEAD SCREW
Vaillant part no. 105744
£3.91
10   PRICE ON APPLICATION
Vaillant part no. 0000

11 Part number 109918, plug PLUG
Vaillant part no. 109918

12 Part number 982484, O-ring O-RING
Vaillant part no. 982484

13 Part number 012954, water quantity regulator, cpl. WATER QUANTITY REGULATOR, CPL.
Vaillant part no. 012954
£3.91
14 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163
£7.03
15   PRICE ON APPLICATION
Vaillant part no. 0000

16 Part number 981159, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981159
£6.66
17 Part number 012629, NOW USE 0020107722 pressure relief valve, cpl. NOW USE 0020107722 PRESSURE RELIEF VALVE, CPL.
Vaillant part no. 012629

17 Part number 0020107722, Valve VALVE
Vaillant part no. 0020107722
£7.61
18 Part number 010050, screw SCREW
Vaillant part no. 010050
£6.66
19 Part number 012819, venturi VCW 242 E D=2.80 mm VENTURI VCW 242 E D=2.80 MM
Vaillant part no. 012819
£3.91
20 Part number 0020028121, Water Filter WATER FILTER
Vaillant part no. 0020028121

21 Part number 981141, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981141
£6.66
22 Part number 981143, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981143
£6.66
