VAILLANT
COMBI COMPACT FF VCW 242 E 1988-1995 - (08a Connection Piping)
Appliance Code: 47-044-13

Appliance Diagram


08a Connection Piping diagram for Vaillant Combi Compact FF VCW 242 E 1988-1995Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 109914, Plug PLUG
Vaillant part no. 109914
£17.92
2 Part number 088906, flow switch conduction FLOW SWITCH CONDUCTION
Vaillant part no. 088906

3 Part number 088912, Flow switch conduction, cpl. FLOW SWITCH CONDUCTION, CPL.
Vaillant part no. 088912

4 Part number 084263, Flow switch conduction, cpl. FLOW SWITCH CONDUCTION, CPL.
Vaillant part no. 084263
£23.05
5 Part number 084266, Flow switch conduction, cpl. FLOW SWITCH CONDUCTION, CPL.
Vaillant part no. 084266
£21.04
6 Part number 084245, Flow switch conduction, cpl. FLOW SWITCH CONDUCTION, CPL.
Vaillant part no. 084245
£12.02
7 Part number 088939, flow switch conduction FLOW SWITCH CONDUCTION
Vaillant part no. 088939
