VAILLANT
ECOMAX 622/2E VU 226/2-C 2001-2007 - (04 Burner)
Appliance Code: 41-044-29

Appliance Diagram


04 Burner diagram for Vaillant Ecomax 622/2E VU 226/2-C 2001-2007Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 049345, Burner BURNER
Vaillant part no. 049345		 £102.19
2 Part number 981103, Gasket burner GASKET BURNER
Vaillant part no. 981103		 £8.62
3 Part number 105900, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 105900		 £6.66
4 Part number 0020026537, Nut, M6 (PK5) NUT, M6 (PK5)
Vaillant part no. 0020026537		 £6.66
5 Part number 161245, inspection glass INSPECTION GLASS
Vaillant part no. 161245		 £6.66
6 Part number 090709, Electrode ELECTRODE
Vaillant part no. 090709		 £22.46
7 Part number 980961, NOW USE 981330 gasket electrode NOW USE 981330 GASKET ELECTRODE
Vaillant part no. 980961
7 Part number 981330, gasket electrode GASKET ELECTRODE
Vaillant part no. 981330		 £6.21
8 Part number 118883, Flat head screw ISO 7045 FLAT HEAD SCREW ISO 7045
Vaillant part no. 118883
9 Part number 091551, ignition wire IGNITION WIRE
Vaillant part no. 091551		 £17.94
10 Part number 190235, Fan FAN
Vaillant part no. 190235		 £245.83
11 Part number 981104, Gasket GASKET
Vaillant part no. 981104		 £7.92
12 Part number 981045, Gasket GASKET
Vaillant part no. 981045		 £6.66
13 Part number 0020110996, Gas section GAS SECTION
Vaillant part no. 0020110996		 £176.01
14 Part number 981142, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981142		 £8.62
15 Part number 123434, Gas connection tube GAS CONNECTION TUBE
Vaillant part no. 123434		 £46.32
16 Part number 256135, Wiring harness WIRING HARNESS
Vaillant part no. 256135
17 Part number 210734, insulation INSULATION
Vaillant part no. 210734		 £29.12
18 Part number 116688, Air gas mixing tube AIR GAS MIXING TUBE
Vaillant part no. 116688		 £49.31
19 Part number 0020107727, NOW USE 981333 GASKET NOW USE 981333 GASKET
Vaillant part no. 0020107727
19 Part number 981333, seal heat exchanger door / mixing arm SEAL HEAT EXCHANGER DOOR / MIXING ARM
Vaillant part no. 981333		 £6.66
20 Part number 105836, Cylinder screw, (kit 2 x 4) CYLINDER SCREW, (KIT 2 X 4)
Vaillant part no. 105836		 £6.66
21 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.11
22 Part number 0020038679, Gasket kit GASKET KIT
Vaillant part no. 0020038679		 £19.11
23 Part number 139247, screw SCREW
Vaillant part no. 139247
24 Part number 118882, Flat head screw FLAT HEAD SCREW
Vaillant part no. 118882
25 Part number 145829, Air inlet pipe AIR INLET PIPE
Vaillant part no. 145829		 £41.04
26 Part number 981111, Gasket GASKET
Vaillant part no. 981111		 £6.66
27 Part number 235057, Throttle disc THROTTLE DISC
Vaillant part no. 235057		 £6.66
28 Part number 087195, NOW USE 0010048102 Bracket, Air Inlet Pipe NOW USE 0010048102 BRACKET, AIR INLET PIPE
Vaillant part no. 087195
28   RETAINER
Vaillant part no. 0010048102		 £5.19
29 Part number 235756, Screw, tapping (ST 4,8x19) SCREW, TAPPING (ST 4,8X19)
Vaillant part no. 235756		 £4.36
31 Part number 088134, flange FLANGE
Vaillant part no. 088134		 £97.18
