MYSON
MARATHON (LATER) 1500C 1997 - (Appliance Overview)
Appliance Code: 41-494-20

Appliance Diagram


Appliance Overview diagram for Myson Marathon (Later) 1500C 1997Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

10 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Main part no. 635506
11   OBSOLETE CASE DOOR ASSY
Main part no. 305A1408
13   OBSOLETE 8 X 1/2 STEEL SCREW
Main part no. 168S
27   OBSOLETE THERMOSTAT SOCKET/ SELECTOR SO
Main part no. 305A1412
30   NOW USE 231726 LEAD FOR PUMP OVERRUN STAT 231
Main part no. 305A1605
30   LEAD ASSEMBLY
Main part no. 231726		 £13.52
31   OBSOLETE PLUG RED 231769 PUMPED PRIMA
Main part no. 307A168
36   OBSOLETE CONTROL KNOB COMBI
Main part no. 309S371
55   OBSOLETE GASKET 231071
Main part no. 305C205
57   OBSOLETE STUD 231073
Main part no. B53017
59   OBSOLETE NUT M10 231075
Main part no. B53020
65   OBSOLETE SEALING STRIP ASSY FLUE
Main part no. 305A592
68   OBSOLETE THERMOSTAT POCKET
Main part no. B53736
70   OBSOLETE BURNER BOX ASSY 231626
Main part no. 305A731
75   OBSOLETE FLUE HOOD AND DRAUGHT DIVERTER
Main part no. 305A1644
83   OBSOLETE
Main part no. 305C760
87   OBSOLETE SPARK GENERATOR 231527
Main part no. 305S284
100   OBSOLETE PLUG AND LEAD ASSY 231567
Main part no. 305A008
104   OBSOLETE BURNER MANIFOLD 231656
Main part no. 305A741
106   OBSOLETE INJECTOR 231335
Main part no. 305S528
107   OBSOLETE BURNER INJECTOR WASHER 1 5MM 2
Main part no. 301C247
108   THERMOCOUPLE
Main part no. B51220
109   OBSOLETE COMPRESSION NUT THERMOCOUPLE
Main part no. 305C656
115   OBSOLETE PILOT BASE PLATE
Main part no. 307A516
117 Part number 402A2476, OBSOLETE ASSY.WINDOW OBSOLETE ASSY.WINDOW
Main part no. 402A2476
118 Part number 305S283, OBSOLETE SPARK ELECTRODE 231532 OBSOLETE SPARK ELECTRODE 231532
Main part no. 305S283
119   OBSOLETE SCREW
Main part no. 11/11592
126   OBSOLETE BURNER END PLATE AB20601
Main part no. 305S431
129   OBSOLETE END PLATE GASKET
Main part no. 305S432
132   OBSOLETE BURNER END PLATE
Main part no. 305S777
135   GASKET
Main part no. 305S778
135   GASKET BURNER END FOR 414572
Main part no. 906242
136   OBSOLETE FILTER
Main part no. 305S776
