IDEAL
MEXICO SUPER 2 RS 80 - (Appliance Overview)
Appliance Code: 41-421-05

Appliance Diagram


Appliance Overview diagram for Ideal Mexico Super 2 RS 80Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 100355, L/STAT RANCO LM7 P9015 L/STAT RANCO LM7 P9015
Ideal part no. 100355		 £26.10
0   OBSOLETE MAGNETIC STRIP S/ADH 438X6.5MM
Ideal part no. 113011
0   H/WARE PK MEX RS/CF50-80
Ideal part no. 013916
0   OBSOLETE GAS VALVE 240V SOLENOID
Ideal part no. 065723
0   OBSOLETE FLUEWAY BAFFLE ASS:MX2 RS80
Ideal part no. 134345
0 Part number 132009, NOW USE 173228 T/CPL INTERRUPTER LD ASS-SENSOR NOW USE 173228 T/CPL INTERRUPTER LD ASS-SENSOR
Ideal part no. 132009
0   THERMO PHIAL BRKT MEX
Ideal part no. 057454
0   OBSOLETE GAS VALVE COVER 45900401-007B
Ideal part no. 003986
0 Part number 003147, SPLIT PIN 1/16 X 1 BRASS SPLIT PIN 1/16 X 1 BRASS
Ideal part no. 003147		 £2.76
0   OBSOLETE METRES 10MM. FIBREGLASS ROPE
Ideal part no. 077381
0 Part number 173228, ECO LEADS ASSY ECO LEADS ASSY
Ideal part no. 173228		 £51.27
1   OBSOLETE HT EXCH ASS:MX2 3 SCTN
Ideal part no. 135740
2   OBSOLETE END SECT W/RING MX2
Ideal part no. 079398
3   OBSOLETE CENTRE SECT MEX2
Ideal part no. 079399
4   OBSOLETE SET OF 4 O RINGS AND ALIGN RINGS
Ideal part no. 078277
6 Part number 055865, T/STAT POCKET ASS 6339004 T/STAT POCKET ASS 6339004
Ideal part no. 055865		 £25.42
7 Part number 057159, OBSOLETE DIST TUBE ASS MEX 50/80 OBSOLETE DIST TUBE ASS MEX 50/80
Ideal part no. 057159
8   OBSOLETE COMB CMBR ASSY MX2 RS 70/80
Ideal part no. 079352
9   OBSOLETE COMBU CHAMBER SIDE INSUL W/FXG
Ideal part no. 078285
10   OBSOLETE FRT INSL 10MM-COMB CHMB MEX
Ideal part no. 012967
11   OBSOLETE REAR INSL-COMB CHBR 5MM MEX
Ideal part no. 012968
12   OBSOLETE COLL HOOD ASS:MX2 RS50/80
Ideal part no. 135259
13   OBSOLETE C/O COVER ASS MEX2 60/80
Ideal part no. 045117
14   OBSOLETE FRT PLT BURNER ASS MX RS80
Ideal part no. 079743
15 Part number 079334, OBSOLETE SIGHT GLASS ASSEMBLY OBSOLETE SIGHT GLASS ASSEMBLY
Ideal part no. 079334
16   OBSOLETE GAS VALVE INLET PIPE ASS PTD:MX2 70-80
Ideal part no. 133723
17   OBSOLETE BNR MFLD ASS PTD MEX 2 70/80
Ideal part no. 133721
17   OBSOLETE BNR MANIFOLD ASS PTD MX 40-80
Ideal part no. 100598
18   OBSOLETE PLT PIPE ASSY MX2 RS60-80
Ideal part no. 079365
18   OBSOLETE PILOT PIPE ASS MX2 RS70/80
Ideal part no. 079751
18   OBSOLETE PILOT PIPE ASS MX2 RS40
Ideal part no. 079749
19 Part number 013857, MAIN BURNER AC19/123244 MAIN BURNER AC19/123244
Ideal part no. 013857
20   OBSOLETE INJECTOR BNR BRAY CAT 103 SIZE 2700
Ideal part no. 004704
21 Part number 079355, PILOT BNR ASSY Q385A-1020 PILOT BNR ASSY Q385A-1020
Ideal part no. 079355
22 Part number 003825, INJECTOR PILOT HONEYWELL 45900421-029 INJECTOR PILOT HONEYWELL 45900421-029
Ideal part no. 003825		 £5.68
23 Part number 079756, GAS VALVE ASS MX2 V4600 A1130 GAS VALVE ASS MX2 V4600 A1130
Ideal part no. 079756		 £229.28
23 Part number 078560, H/WELL VALVE 1049 C/W O RINGS H/WELL VALVE 1049 C/W O RINGS
Ideal part no. 078560
23 Part number 004997, GAS VALVE HONEYWELL V4700E1098U GAS VALVE HONEYWELL V4700E1098U
Ideal part no. 004997
24 Part number 003939, SPARK GENERATOR 60080/002 SPARK GENERATOR 60080/002
Ideal part no. 003939
25   H T LEAD ASSY 600MM LG MEX SUP
Ideal part no. 057254
26 Part number 003876, NOW USE Q309A2747 THERMOCOUPLE 750MM NOW USE Q309A2747 THERMOCOUPLE 750MM
Ideal part no. 003876
26 Part number Q309A2747, Q309A2747 - thermocouple Q309A2747 - THERMOCOUPLE
Baxi part no. Q309A2747		 £9.18
27   OBSOLETE GAS COCK ASSY 004913/918/919
Ideal part no. 077044
28   OBSOLETE CONTROL BOX MX2 40/125
Ideal part no. 134761
29   OBSOLETE PLASTIC CAN SUPPRESSOR STC NO
Ideal part no. 004033
30   OBSOLETE T/STAT BOX MEX 2
Ideal part no. 079358
31 Part number 110541, OBSOLETE T/STAT K36 REF P1317 MEX 2 OBSOLETE T/STAT K36 REF P1317 MEX 2
Ideal part no. 110541
32 Part number 013909, OBSOLETE CONTROL KNOB ASS T/STAT MX2 SUP OBSOLETE CONTROL KNOB ASS T/STAT MX2 SUP
Ideal part no. 013909
33   OBSOLETE JKT ASSY MEX 2 RS70/80
Ideal part no. 079360
34   OBSOLETE SD PNL PTD MEX 2 RS/CF40-100
Ideal part no. 134596
36   OBSOLETE JKT TOP PNL ASS MEX 2 RS40/100
Ideal part no. 134931
37   OBSOLETE UPR FRT PNL ASS:MX2 RS/CF70-80
Ideal part no. 135254
37   OBSOLETE UPR FRT PNL ASS:MX2 RS
Ideal part no. 101160
38   OBSOLETE CTRL PNL CVR PTD MEX 2
Ideal part no. 134207
39   OBSOLETE CONTROL PANEL FXGS (PAIR)
Ideal part no. 079363
41   OBSOLETE PROGRAMMER RWB 4 STELRAD
Ideal part no. 012698
42 Part number 057204, OBSOLETE AIR/FLUE DUCT ASS MEX RS80 OBSOLETE AIR/FLUE DUCT ASS MEX RS80
Ideal part no. 057204
43   OBSOLETE BOILER BASE PLATE MEX 40-100
Ideal part no. 134236
