IDEAL
CLASSIC SE15 FF SLIMLINE - (Appliance Overview)
Appliance Code: 41-395-42

Appliance Diagram


Appliance Overview diagram for Ideal Classic SE15 FF SlimlineClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 171375, OBSOLETE HEAT EXCHANGER ASSY KIT CLA FF50-60 OBSOLETE HEAT EXCHANGER ASSY KIT CLA FF50-60
Ideal part no. 171375
2   FLUE BAFFLE KIT CLA FF50-60
Ideal part no. 171382
3 Part number 171385, HOOK BOLT KIT CLA FF50-60 HOOK BOLT KIT CLA FF50-60
Ideal part no. 171385
4 Part number 171387, PIPE-PUMP FLOW KIT CLA FF PIPE-PUMP FLOW KIT CLA FF
Ideal part no. 171387		 £23.70
5   PIPE-RETURN PIPE ASSY KIT CLA FF50-60
Ideal part no. 171392		 £45.79
6   COLLECTOR HOOD KIT FF250 CLASS SLIMLINE
Ideal part no. 170871		 £41.14
6 Part number 170527, COLL HOOD ASSY CLASS NF 250 COLL HOOD ASSY CLASS NF 250
Ideal part no. 170527		 £47.30
7 Part number 171399, KIT COMBUSTION CHMB ASSY FF50-60 HE15-18 KIT COMBUSTION CHMB ASSY FF50-60 HE15-18
Ideal part no. 171399
8 Part number 171405, COMB CHAMB INSULATION KIT CLA FF50-60 COMB CHAMB INSULATION KIT CLA FF50-60
Ideal part no. 171405		 £19.92
9 Part number 171414, SIGHT GLASS ASSY KIT CLA FF SIGHT GLASS ASSY KIT CLA FF
Ideal part no. 171414		 £9.33
10 Part number 171415, OBSOLETE GAS MANIFOLD & GASKET KIT CLA FF OBSOLETE GAS MANIFOLD & GASKET KIT CLA FF
Ideal part no. 171415
11 Part number 171455, OBSOLETE AIR BOX & GASKET KIT CLA FF OBSOLETE AIR BOX & GASKET KIT CLA FF
Ideal part no. 171455
12 Part number 171961, MAIN BURNER KIT 50P-60P MAIN BURNER KIT 50P-60P
Ideal part no. 171961
12 Part number 171013, OBSOLETE MAIN BURNER FF250/260 SPARES KIT OBSOLETE MAIN BURNER FF250/260 SPARES KIT
Ideal part no. 171013
13   MAIN INJECTOR KIT CLA FF50P
Ideal part no. 171431		 £7.45
13 Part number 171426, MAIN INJECTOR KIT CLA FF50 MAIN INJECTOR KIT CLA FF50
Ideal part no. 171426
14 Part number 171437, PILOT BURNER INJECTOR SLG WAS KIT CLA FF PILOT BURNER INJECTOR SLG WAS KIT CLA FF
Ideal part no. 171437
14 Part number 171434, PILOT BURNER INJECTOR CLA FF30-80 PILOT BURNER INJECTOR CLA FF30-80
Ideal part no. 171434
14 Part number 171436, PILOT BURNER INJECTOR CLA FF PROPANE PILOT BURNER INJECTOR CLA FF PROPANE
Ideal part no. 171436		 £13.43
15 Part number 171440, PILOT BNR HEAD C/W INJ KIT CLA FF PROPANE PILOT BNR HEAD C/W INJ KIT CLA FF PROPANE
Ideal part no. 171440		 £29.00
15 Part number 171438, PILOT BNR HEAD C/W INJ KIT CLA FF30-80 PILOT BNR HEAD C/W INJ KIT CLA FF30-80
Ideal part no. 171438
16 Part number 171506, PILOT BURNER SHIELD KIT CLA FF PILOT BURNER SHIELD KIT CLA FF
Ideal part no. 171506
17 Part number 171441, GAS VALVE KIT CLASSIC GAS VALVE KIT CLASSIC
Ideal part no. 171441		 £155.53
17 Part number 172006, GAS VALVE GAS VALVE
Ideal part no. 172006		 £234.93
18 Part number 171442, IGNITION ELECTRODE KIT CLA FF IGNITION ELECTRODE KIT CLA FF
Ideal part no. 171442		 £27.65
19   CONTROLS BOX EARTHING HARNESS KIT CLA FF
Ideal part no. 171882		 £4.77
19   CONTROL BOX KIT CLA FF
Ideal part no. 171892		 £43.85
19 Part number 171894, OBSOLETE CONTROL BOX KIT(COMPLETE WITH PCB)CLA FF OBSOLETE CONTROL BOX KIT(COMPLETE WITH PCB)CLA FF
Ideal part no. 171894
20   MAINS SOCKET KIT CLA FF
Ideal part no. 171931		 £6.14
20   MAINS HARNESS KIT CLA FF
Ideal part no. 171880		 £11.92
20   MAINS CONNECTOR KIT CLA FF
Ideal part no. 171453		 £9.22
21 Part number 171877, POT HARNESS KIT(INCL NUT & WASHER)RD1 POT HARNESS KIT(INCL NUT & WASHER)RD1
Ideal part no. 171877		 £15.93
22 Part number 171448, THERMOSTAT POCKET KIT CLA FF THERMOSTAT POCKET KIT CLA FF
Ideal part no. 171448		 £70.41
23 Part number 171881, PCB HARNESS KIT CLA FF PCB HARNESS KIT CLA FF
Ideal part no. 171881		 £9.42
23 Part number 173799, PCB 25E PCB 25E
Ideal part no. 173799		 £166.72
24 Part number 171454, PRESSURE SWITCH ASSY KIT CLA FF PRESSURE SWITCH ASSY KIT CLA FF
Ideal part no. 171454		 £90.08
25 Part number 171879, THERMOSTAT AND HARNESS KIT CLA FF THERMOSTAT AND HARNESS KIT CLA FF
Ideal part no. 171879		 £59.89
26 Part number 171504, POTENTIOMETER KNOB & CAP KIT CLA FF POTENTIOMETER KNOB & CAP KIT CLA FF
Ideal part no. 171504		 £7.89
28 Part number 171503, GAS VALVE HARNESS LEAD CLA FF GAS VALVE HARNESS LEAD CLA FF
Ideal part no. 171503
30 Part number 171463, FAN ASSY KIT CLA FF 30-60 FAN ASSY KIT CLA FF 30-60
Ideal part no. 171463		 £280.81
31   PRESS SWITCH/FAN/LIMIT STAT HARNESS SPARE
Ideal part no. 173355
32   PRESSURE SENSING PIPE (METAL) KIT CLA FF
Ideal part no. 171466		 £223.65
33 Part number 171468, PRESSURE SENSING PIPE KIT CLA FF PRESSURE SENSING PIPE KIT CLA FF
Ideal part no. 171468		 £16.44
37   OBSOLETE CONTROLS DOOR KIT (SILVER) SE FF
Ideal part no. 173587
37 Part number 173586, CONTROLS DOOR KIT SE FF (GREY) CONTROLS DOOR KIT SE FF (GREY)
Ideal part no. 173586		 £35.65
38 Part number 171478, CASING FIXING PACK KIT CLA FF CASING FIXING PACK KIT CLA FF
Ideal part no. 171478		 £16.19
39 Part number 171479, CASING SEAL & JKT SCREWS KIT CLA FF CASING SEAL & JKT SCREWS KIT CLA FF
Ideal part no. 171479		 £13.73
39 Part number 173588, OBSOLETE CASING SEAL KIT (SILVER) OBSOLETE CASING SEAL KIT (SILVER)
Ideal part no. 173588
40   OBSOLETE WALL MOUNTING PLATE ASSY KIT CLA FF
Ideal part no. 171480
41 Part number 171482, TERMINAL WALL PLATE KIT CLA FF TERMINAL WALL PLATE KIT CLA FF
Ideal part no. 171482
42 Part number 171927, GAS COCK ASSY KIT GAS COCK ASSY KIT
Ideal part no. 171927		 £43.36
43 Part number 171483, FLUE ELBOW ASSY KIT CLA FF FLUE ELBOW ASSY KIT CLA FF
Ideal part no. 171483
44 Part number 171484, PROGRAMMER ASSY KIT CLA FF PROGRAMMER ASSY KIT CLA FF
Ideal part no. 171484		 £259.34
45 Part number 171950, LIMIT STAT (LM7) LIMIT STAT (LM7)
Ideal part no. 171950		 £42.72
46 Part number 171485, BOILER HARDWARE PACK KIT 30-60 BOILER HARDWARE PACK KIT 30-60
Ideal part no. 171485		 £19.70
46   OBSOLETE BOILER HARDWARE PACK KIT 70-80-100
Ideal part no. 171486
47 Part number 171887, GASKET-GROMMET & BUSH KIT CLA FF GASKET-GROMMET & BUSH KIT CLA FF
Ideal part no. 171887		 £11.67
48 Part number 170719, OBSOLETE AIR DUCT SEALING PLT ASSY CLASSIC FF200 OBSOLETE AIR DUCT SEALING PLT ASSY CLASSIC FF200
Ideal part no. 170719
50   OBSOLETE JACKING SCREW CLA FF
Ideal part no. 171492
53   WALL MOUNTING TEMPLATE KIT CLA FF
Ideal part no. 171494		 £9.23
58 Part number 171496, SINGLE POLE HTG SWITCH-ON/OFF KIT CLA FF SINGLE POLE HTG SWITCH-ON/OFF KIT CLA FF
Ideal part no. 171496
59 Part number 173353, LIMIT THERMOSTAT SPARE LIMIT THERMOSTAT SPARE
Ideal part no. 173353		 £12.63
300 Part number 171505, SENSING POINT KIT CLA FF SENSING POINT KIT CLA FF
Ideal part no. 171505		 £10.11
300 Part number 171886, GENERAL FIXINGS KIT CLA FF GENERAL FIXINGS KIT CLA FF
Ideal part no. 171886		 £15.48
300 Part number 171896, SEALING ROPE KIT CLA FF 50/60 SEALING ROPE KIT CLA FF 50/60
Ideal part no. 171896
300 Part number 171897, SEALING ROPE KIT CLA FF 70/80/100 SEALING ROPE KIT CLA FF 70/80/100
Ideal part no. 171897		 £15.24
300 Part number 171895, SEALING ROPE KIT CLA FF 30/40 SEALING ROPE KIT CLA FF 30/40
Ideal part no. 171895
300 Part number 171951, FLUE EXT TUBE KIT FLUE EXT TUBE KIT
Ideal part no. 171951
