GLOWWORM
HIDEAWAY 80CF 1985 AVA - (Appliance Overview)
Appliance Code: 41-313-25

Appliance Diagram


Appliance Overview diagram for Glowworm Hideaway 80CF 1985 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   BOILER SUB ASSY HA70/80CF
Glowworm part no. 2000800760
2 Part number 409233, PHIAL POCKET KIT PHIAL POCKET KIT
Glowworm part no. 409233
2 Part number 208390, NOW USE S208390 SPLIT PIN-1.6 X 25MM NOW USE S208390 SPLIT PIN-1.6 X 25MM
Glowworm part no. 208390
2 Part number S208390, Split pin - 1.6 X 25mm SPLIT PIN - 1.6 X 25MM
Glowworm part no. S208390
3   NOW USE S442103 DIP TUBE ASSY HA80-80B
Glowworm part no. 442103
3   DIP TUBE ASSY HA80-80B
Glowworm part no. S442103
4   PLUG -1 BSP TAPER - RECESSED
Glowworm part no. SK1092		 £5.15
5   OBSOLETE HEAT SHIELD KIT HA70-80B
Glowworm part no. 424707
6   NOW USE S212011 G/FIBRE ROPE-10X1292MM LOOP
Glowworm part no. 212011
6   G/FIBRE ROPE-10X1292MM LOOP
Glowworm part no. S212011
7 Part number 403215, NOW USE S403215 NUT-WING M5 ZP NOW USE S403215 NUT-WING M5 ZP
Glowworm part no. 403215
7 Part number S403215, Nut-wing M5 NUT-WING M5
Glowworm part no. S403215
8   OBSOLETE CTRL BOX ASSY-HA70>120B&C
Glowworm part no. 424659
9   NOW USE S202511 TSTAT-RANCO CL6 P0129-000
Glowworm part no. 202511
9 Part number S202511, Thermostat THERMOSTAT
Glowworm part no. S202511		 £139.08
10   NOW USE S204228 BUSH-RELIEF SR6N34
Glowworm part no. 204228
10   BUSH RELIEF
Glowworm part no. S204228
11 Part number 202019, OBSOLETE SOCKET-ELKAY 6603-2 OBSOLETE SOCKET-ELKAY 6603-2
Glowworm part no. 202019
11 Part number S202019, OBSOLETE Electrical Socket OBSOLETE ELECTRICAL SOCKET
Glowworm part no. S202019
12 Part number 202018, PLUG-ELKAY 6603-1 PLUG-ELKAY 6603-1
Glowworm part no. 202018
12 Part number S202018, Electrical Plug ELECTRICAL PLUG
Glowworm part no. S202018
13   CONTROL KNOB/CLIP
Glowworm part no. FF2228
14 Part number 900501, NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE
Glowworm part no. 900501
14 Part number 403095, OBSOLETE CLIP- D-SPIRE OBSOLETE CLIP- D-SPIRE
Glowworm part no. 403095
14   NOW USE S202606 ELECTRODE RETAINING NUT
Glowworm part no. 202606
14 Part number 202605, NOW USE S202605 ELECTRODE NOW USE S202605 ELECTRODE
Glowworm part no. 202605
14 Part number SWW4609, Ignition lead IGNITION LEAD
Glowworm part no. SWW4609
14   OBSOLETE SLEEVING-200MM LG
Glowworm part no. SWW1003
14   ELECTRODE RETAINING NUT
Glowworm part no. S202606		 £4.91
14 Part number S202605, ELECTRODE ELECTRODE
Glowworm part no. S202605		 £20.30
14 Part number S403095, D clip for control knob D CLIP FOR CONTROL KNOB
Glowworm part no. S403095
14 Part number S900501, Piezo generator PIEZO GENERATOR
Glowworm part no. S900501
15 Part number 2000800310, OBSOLETE Comb chamb door OBSOLETE COMB CHAMB DOOR
Glowworm part no. 2000800310
16   G/FIBRE ROPE-10DIAX572MM LG
Glowworm part no. 212012
16   G/FIBRE ROPE-10DIAX572MM LG
Glowworm part no. S212012
18   INSUL-6MM C/C SIDE
Glowworm part no. 210058
18   INSULATION-6MM-COMBUSTION CHAMBER SIDE
Glowworm part no. S210058
19   SCREW -M5
Glowworm part no. SK8209
20 Part number 208302, NOW USE S208302 SIGHT GLASS NOW USE S208302 SIGHT GLASS
Glowworm part no. 208302
20 Part number S208302, SIGHT GLASS SIGHT GLASS
Glowworm part no. S208302		 £6.61
21 Part number 208093, NOW USE S208093 GASKET-SIGHT GLASS NOW USE S208093 GASKET-SIGHT GLASS
Glowworm part no. 208093
21 Part number S208093, GASKET-SIGHT GLASS GASKET-SIGHT GLASS
Glowworm part no. S208093		 £6.61
22   OBSOLETE SIGHT GLASS COV(PC) CV/HABCBBU
Glowworm part no. 424508
23 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652
24   NOW USE S424785 LINTING BOX ASSY (SW) HA8C
Glowworm part no. 424785
24   LINTING BOX
Glowworm part no. S424785		 £29.54
25   OBSOLETE MAN.ASSY-PNTD-(203119) HA80
Glowworm part no. 442014
26   SCREW (M5X12MM)
Glowworm part no. SK9419
27 Part number 208294, NOW USE S208294 SCREW-M5X14MM+5DG MS PN NOW USE S208294 SCREW-M5X14MM+5DG MS PN
Glowworm part no. 208294
27 Part number S208294, Screw ( M5X14mm ) SCREW ( M5X14MM )
Glowworm part no. S208294		 £6.61
28   OBSOLETE GAS MANIFOLD BRKT (F) HA8C02BC
Glowworm part no. 424864
29   NOW USE S203053 INJECTOR 4.4MM DIA
Glowworm part no. 203053
29   INJECTOR
Glowworm part no. S203053		 £4.91
30   OBSOLETE LINTING BOX BRKT (PCF) HAC
Glowworm part no. 424782
31   NUT -SPIRE CAPT NO6
Glowworm part no. SK8270
32   NOW USE S203258 BURNER ASY-AC07/052026-PRE BED
Glowworm part no. 203258
32   BURNER
Glowworm part no. S203258		 £106.89
33   NOW USE S210059 INSUL-84X29X8MM G.FBR/C.FBR
Glowworm part no. 210059
33   INSULATION - 84X29X8MM
Glowworm part no. S210059		 £4.91
34   INSULATION -62X30.5X8MM
Glowworm part no. S210067		 £5.07
34   NOW USE S210067 INSUL-62X30.5X8MM G.FB/C.FB
Glowworm part no. 210067
35 Part number 208309, NOW USE S208309 PAPER FASTENER-TUCKER 063BS3 NOW USE S208309 PAPER FASTENER-TUCKER 063BS3
Glowworm part no. 208309
35 Part number S208309, Paper fastener PAPER FASTENER
Glowworm part no. S208309		 £4.91
36   OBSOLETE AIR BOX COVER (PCF) HA6802C
Glowworm part no. 424786
37   NOW USE S212031 O RING-33MM ID X 2MM SECT
Glowworm part no. 212031
37   O RING -33MM ID X 2MM SECT
Glowworm part no. S212031
38 Part number S900307, Gas Cock - flanged GAS COCK - FLANGED
Glowworm part no. S900307
38 Part number 900307, NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC
Glowworm part no. 900307
39 Part number 2000800001, Gas section GAS SECTION
Glowworm part no. 2000800001		 £107.59
41 Part number 203414, PILOT BRACKET PBRNR PILOT BRACKET PBRNR
Glowworm part no. 203414
41 Part number S203414, Bracket - Pilot BRACKET - PILOT
Glowworm part no. S203414
42 Part number S208238, Screw ( M5X8mm ) SCREW ( M5X8MM )
Glowworm part no. S208238		 £6.61
42 Part number 208238, NOW USE S208238 SCREW-M5X8MM MS PN REC NOW USE S208238 SCREW-M5X8MM MS PN REC
Glowworm part no. 208238
43 Part number SK6219, Nut NUT
Glowworm part no. SK6219
44 Part number 203508, PLT INJTR-0.27MM-SIT 0.977.113 PLT INJTR-0.27MM-SIT 0.977.113
Glowworm part no. 203508
44 Part number S203508, Injector, pilot INJECTOR, PILOT
Glowworm part no. S203508		 £15.68
45 Part number 2000800004, Pipe - Pilot PIPE - PILOT
Glowworm part no. 2000800004		 £10.94
46   OBSOLETE GAS VALVE ELBOW-ALTERNATIVES
Glowworm part no. 900400
46   OBSOLETE ELBOW - GAS VALVE
Glowworm part no. S900400
47 Part number S417019, Nut - Compression 4mm NUT - COMPRESSION 4MM
Glowworm part no. S417019
47 Part number 417019, NUT-COMP-4MM-SIT 0.958.030 NUT-COMP-4MM-SIT 0.958.030
Glowworm part no. 417019
48   OBSOLETE NUT-TUBING-4MM-SIT 0.958.013
Glowworm part no. 204157
48   OBSOLETE NUT-TUBING-4MM
Glowworm part no. S204157
49   OBSOLETE OLIVE 4MM
Glowworm part no. S204158
49   OBSOLETE OLIVE-4MM-SIT 0.957.009
Glowworm part no. 204158
51   OBSOLETE BSE PROTECT TRAY ASSY(SW) HA8C
Glowworm part no. 424713
52   NUT
Glowworm part no. SK6516
53   OBSOLETE CASING BRACKET (FORM) HABC
Glowworm part no. 424525
54   NUT - SPIRE CAPT NO8
Glowworm part no. SK9327		 £4.91
55 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
58   OBSOLETE FRONT PNL CLIP (PCF.PR) HABC
Glowworm part no. 424692
59   CLIP - EDGE CABLE
Glowworm part no. SK6899
60   OBSOLETE SIDE PANEL ASSY RH
Glowworm part no. 424561
60   OBSOLETE SIDE PANEL ASSY RH
Glowworm part no. S424561
61   OBSOLETE SIDE PANEL ASSY LH
Glowworm part no. 424567
62 Part number 424530, OBSOLETE LOUVRE-PNTD HABC OBSOLETE LOUVRE-PNTD HABC
Glowworm part no. 424530
63   OBSOLETE TOP PANEL-PNTD HA8C
Glowworm part no. 424718
64   OBSOLETE FRONT PANEL ASSY
Glowworm part no. 424719
65   OBSOLETE PLINTH FASCIA-PNTD-PH HA8BC
Glowworm part no. 424721
66 Part number SK6262, Shake proof washer (M5) SHAKE PROOF WASHER (M5)
Glowworm part no. SK6262
67   OBSOLETE SCREW-M5X16MM MS HX HD ZP
Glowworm part no. SK6533
68   OBSOLETE DOOR FACIA
Glowworm part no. 205107
69   OBSOLETE EXTRUSION-DOOR TRIM
Glowworm part no. 209056
70   WASHER
Glowworm part no. SK6297
71 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.61
72   OBSOLETE SCREW-M4X16MM MS PN REC ZP
Glowworm part no. SK6213
73 Part number SK6361, Shake proof washer (M4) SHAKE PROOF WASHER (M4)
Glowworm part no. SK6361
74   SCREW - M4X10MM
Glowworm part no. SK6359
75   OBSOLETE NUT-SPIRE CAPT NO8
Glowworm part no. 208303
76   OBSOLETE CONTROL BOX DOOR (NPF) HA802BC
Glowworm part no. 424661
77   OBSOLETE PLUG & CABLE ASSY
Glowworm part no. 424860
77   OBSOLETE PLUG + CABLE
Glowworm part no. S424860
78   OBSOLETE CONT.BOX SUPP.BRKT(NPF)HA802BC
Glowworm part no. 424844
79 Part number 208368, DOOR STUD-FOREST SBV 38471406 DOOR STUD-FOREST SBV 38471406
Glowworm part no. 208368
79 Part number S208368, Door stud DOOR STUD
Glowworm part no. S208368
120   SAFETY DEVICE
Glowworm part no. 2000800725
121   OBSOLETE KNURLED NUT
Glowworm part no. 208414
122   LEAD
Glowworm part no. SWX5100		 £9.63
123   OBSOLETE SCREW-M4 X 12MM REC PNSSM
Glowworm part no. 403170
123   OBSOLETE SCREW-M4 X 12MM REC PNSSM
Glowworm part no. S403170
124   OBSOLETE SCREW-M5 X 12MM HX HD ST/STEEL
Glowworm part no. 208528
125   OBSOLETE NUT-M4 HEX FULL SS
Glowworm part no. 208664
126   OBSOLETE NUT-M5 HEX FULL SS
Glowworm part no. 208667
127   INTERRUPTER
Glowworm part no. 202422
127 Part number S202422, INTERRUPTER INTERRUPTER
Glowworm part no. S202422
128   OBSOLETE FRONT PANEL ASSY - HA70-80
Glowworm part no. 425757
