FERROLI
OPTIMA 201 - (Appliance Overview)
Appliance Code: OPT 201

Appliance Diagram


Appliance Overview diagram for Ferroli Optima 201Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

5   PANEL - SIDE
Ferroli part no. 39800680		 £12.05
7   BRACKET - EXPANSION VESSEL
Ferroli part no. 31206150		 £6.35
10   OBSOLETE SUPPORT - ELECTRIC BOX
Ferroli part no. 817500
11   BURNER BAR - C/W PILOT BRACKET
Ferroli part no. 37607900		 £14.83
12   COMBUSTION CHAMBER
Ferroli part no. 37400880		 £20.72
13   OBSOLETE SPY HOLE FLAP FOR PILOT 77FF
Ferroli part no. 811710
14   PLATE - PILOT COVER
Ferroli part no. 32112690		 £7.71
14   COLLAR - FLUE PIPE
Ferroli part no. 32113360
15   OBSOLETE DRAUGHT DIVERTER COVER
Ferroli part no. 812680
16   OBSOLETE FRAME - BURNER
Ferroli part no. 818050
17   OBSOLETE COMBUSTION CHAMBER SUPPORT
Ferroli part no. 814040
19 Part number 39801090, TEST POINT - "GAS/AIR" TEST POINT - "GAS/AIR"
Ferroli part no. 39801090		 £4.39
19 Part number 33400280, NOW USE 39801090 TEST POINT - NOW USE 39801090 TEST POINT -
Ferroli part no. 33400280
21 Part number 33700381, WASHER - PRESSURE GAUGE WASHER - PRESSURE GAUGE
Ferroli part no. 33700381		 £0.71
22 Part number 30810850, WASHER - 1/2" CF4324 (K42) WASHER - 1/2" CF4324 (K42)
Ferroli part no. 30810850		 £0.16
23 Part number 30810710, WASHER - 3/4" CF4324 (K42) WASHER - 3/4" CF4324 (K42)
Ferroli part no. 30810710		 £0.16
24 Part number 33700480, GASKET -INJECTOR GASKET -INJECTOR
Ferroli part no. 33700480		 £1.39
25 Part number 33700530, GASKET - EXPANSION VESSEL GASKET - EXPANSION VESSEL
Ferroli part no. 33700530		 £0.33
26 Part number 33700660, INJECTOR - PILOT (0.20-LPG) INJECTOR - PILOT (0.20-LPG)
Ferroli part no. 33700660		 £3.64
26 Part number 33700570, NOW USE 39803550 INJECTOR - PILOT (0.33-NG) NOW USE 39803550 INJECTOR - PILOT (0.33-NG)
Ferroli part no. 33700570
26 Part number 39803550, INJECTOR - PILOT (0.33-NG) INJECTOR - PILOT (0.33-NG)
Ferroli part no. 39803550		 £7.41
27   INJECTOR - MAIN (1.30-LPG)
Ferroli part no. 34005870		 £2.12
27 Part number 34005850, INJECTOR - MAIN (2.10-NG) INJECTOR - MAIN (2.10-NG)
Ferroli part no. 34005850		 £1.93
28   CAP - DHW ( FEMALE 1/2" )
Ferroli part no. 34007320		 £3.84
29 Part number 34007430, NUT - 3/4" JIG VALVE NUT - 3/4" JIG VALVE
Ferroli part no. 34007430		 £1.62
30 Part number 34007880, NUT - 1/2" JIG VALVE NUT - 1/2" JIG VALVE
Ferroli part no. 34007880		 £2.52
31 Part number 39800240, FILTER - DHW FLOW SWITCH FILTER - DHW FLOW SWITCH
Ferroli part no. 39800240		 £8.65
34   CAP - HEAT EXCHANGER VENT
Ferroli part no. 34008550		 £2.40
35 Part number 34008560, SPHERE SPHERE
Ferroli part no. 34008560		 £0.82
38 Part number 34100520, HINGE - R/H HINGE - R/H
Ferroli part no. 34100520		 £4.91
39 Part number 34100530, HINGE - L/H HINGE - L/H
Ferroli part no. 34100530		 £4.91
40   PIPE - PILOT
Ferroli part no. 34221310		 £18.33
42   SPRING - SMOKE BOX
Ferroli part no. 34403030		 £2.40
47   KNOB - THERMOSTATIC
Ferroli part no. 35001940
48   KNOB - EXTENSION
Ferroli part no. 35001840		 £3.15
52 Part number 39803860, FAN ASSEMBLY FAN ASSEMBLY
Ferroli part no. 39803860		 £172.53
53   GASKET - PUMP
Ferroli part no. 35100160		 £0.65
54   PIPE - GAS VALVE TO MANIFOLD
Ferroli part no. 38436563
56   O-RING - 22MM ( 3062 )
Ferroli part no. 35100430		 £1.52
58   OBSOLETE INSULATION - BACK
Ferroli part no. 814030
59   SIGHT GLASS - 50MM X 30MM X 3.3MM
Ferroli part no. 35315250		 £2.25
60   OBSOLETE INSULATION - SIDE 77FF
Ferroli part no. 815280
61   INSULATION - COMBUSTION CHAMBER PANEL
Ferroli part no. 35315300		 £4.88
62 Part number 39801230, SELECTOR SWITCH - 3 POSITION SELECTOR SWITCH - 3 POSITION
Ferroli part no. 39801230		 £17.31
63 Part number 801870, Now use 39808000 GAS VALVE NOW USE 39808000 GAS VALVE
Ferroli part no. 801870
63 Part number 39808000, GAS VALVE - ( VK4105G ) GAS VALVE - ( VK4105G )
Ferroli part no. 39808000		 £224.21
64 Part number 39800160, THERMOSTAT - 88 DEG CH LIMIT THERMOSTAT - 88 DEG CH LIMIT
Ferroli part no. 39800160		 £7.38
65 Part number 39800180, THERMOSTAT - 14 DEG FROST THERMOSTAT - 14 DEG FROST
Ferroli part no. 39800180		 £6.61
66 Part number 39800170, THERMOSTAT - 100C LIMIT THERMOSTAT - 100C LIMIT
Ferroli part no. 39800170		 £8.13
69 Part number 39804220, FLOW METER - STRAIGHT FLOW METER - STRAIGHT
Ferroli part no. 39804220		 £58.40
70   OBSOLETE CONNECTOR BLOCK - 160 ST 77FF
Ferroli part no. 814460
71 Part number 36503870, CONNECTOR BLOCK OK.432/3 77FF CONNECTOR BLOCK OK.432/3 77FF
Ferroli part no. 36503870		 £2.80
71   CLOCK-24 HOUR (LCD) (803040)
Ferroli part no. ZU01021XA		 £66.53
71 Part number 39803831, NOW USE ZU01021XA CLOCK-24 HOUR (LCD) (803840) NOW USE ZU01021XA CLOCK-24 HOUR (LCD) (803840)
Ferroli part no. 39803831
71 Part number 39803830, NOW USE ZU01021XA CLOCK - LCD (24 HOUR) NOW USE ZU01021XA CLOCK - LCD (24 HOUR)
Ferroli part no. 39803830
72   OBSOLETE INSULATION BUSHING SHORT - BLACK NYLON
Ferroli part no. 814860
73   PCB - HOUSING
Ferroli part no. 36504980		 £23.11
74   COVER - PCB
Ferroli part no. 32908840		 £13.06
75   OBSOLETE PLATE - CONNECTOR BLOCK 77FF
Ferroli part no. 817530
76 Part number 39800600, PUMP ASSEMBLY - GRUNDFOS PUMP ASSEMBLY - GRUNDFOS
Ferroli part no. 39800600		 £170.87
79 Part number 39801150, GENERATOR - SPARK GENERATOR - SPARK
Ferroli part no. 39801150
81 Part number 36702070, NOW USE 39803010 THERMOCOUPLE NOW USE 39803010 THERMOCOUPLE
Ferroli part no. 36702070
81 Part number 39803010, THERMOCOUPLE THERMOCOUPLE
Ferroli part no. 39803010		 £22.26
82   PILOT ASSEMBLY
Ferroli part no. 39801900		 £24.04
82   NOW USE 39801900 PILOT ASSEMBLE
Ferroli part no. 36702180
83 Part number 39800280, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ferroli part no. 39800280		 £24.14
84 Part number 39800960, EXPANSION VESSEL - ( 7 LITRE) EXPANSION VESSEL - ( 7 LITRE)
Ferroli part no. 39800960		 £107.18
86 Part number 39804000, GAS VALVE - ( V4600N ) GAS VALVE - ( V4600N )
Ferroli part no. 39804000		 £325.12
87 Part number 39410130, OBSOLETE MODUREG - GAS VALVE VE335A 4014 OBSOLETE MODUREG - GAS VALVE VE335A 4014
Ferroli part no. 39410130
88 Part number 39800130, SAFETY VALVE - 3 BAR SAFETY VALVE - 3 BAR
Ferroli part no. 39800130		 £17.25
89 Part number 39801160, AUTO AIR VENT AUTO AIR VENT
Ferroli part no. 39801160		 £18.60
90 Part number 39801250, RESTRICTOR - FLOW ( 7/LPM) RESTRICTOR - FLOW ( 7/LPM)
Ferroli part no. 39801250		 £5.91
92   FRAME - BOILER
Ferroli part no. 37103480		 £34.41
93   COMBUSTION CHAMBER - UPPER
Ferroli part no. 37401420		 £13.34
94 Part number 39800450, HEAT EXCHANGER HEAT EXCHANGER
Ferroli part no. 39800450		 £424.96
95   PANEL - COMBUSTION CHAMBER
Ferroli part no. 37400910		 £22.74
96   SMOKE BOX
Ferroli part no. 37500430		 £34.70
97 Part number 37607090, NOW USE 39810140 BURNER BAR NOW USE 39810140 BURNER BAR
Ferroli part no. 37607090
97 Part number 39810140, BURNER BAR BURNER BAR
Ferroli part no. 39810140		 £18.27
99   OBSOLETE WIRE - ECO SPLIT WIRE
Ferroli part no. 38307490
102 Part number 39800310, SENSOR - 1K PTC DHW / CH (WET) SENSOR - 1K PTC DHW / CH (WET)
Ferroli part no. 39800310		 £16.49
103 Part number 39801370, MICROSWITCH - IGNITION MICROSWITCH - IGNITION
Ferroli part no. 39801370		 £40.97
104 Part number 39803410, PCB - VMF7 PCB - VMF7
Ferroli part no. 39803410		 £279.91
106   FROLI 810930 MANIFOLD COMPLETE
Ferroli part no. 38440930		 £21.87
107   PIPE - EXPANSION VESSEL
Ferroli part no. 38439090		 £16.64
108   OBSOLETE PIPE - RETURN
Ferroli part no. 38405160
110   PIPE - GAS INLET
Ferroli part no. 38440950		 £11.57
112   OBSOLETE PIPE - GAS VALVE TO BURNER
Ferroli part no. 810328
113   PIPE - COLD WATER INLET
Ferroli part no. 38439080		 £16.64
115   OBSOLETE LOW WATER PRESSURE SENSOR - OPTIMA
Ferroli part no. 803930
