| 0 | OBSOLETE INSTALLATION AND SERVICE INSTRUCTIONS Ferroli part no. 824600 |
|||
| 0 | OBSOLETE USERS INSTRUCTIONS Ferroli part no. 823600 |
|||
| 0 | OBSOLETE FLUE DUCT ASSEMBLY C/W TERMINAL - 3M Ferroli part no. 823124 |
|||
| 0 | OBSOLETE FLUE DUCT ASSEMBLY C/W TERMINAL - 2M Ferroli part no. 823114 |
|||
| 1 | OBSOLETE DATA BADGE Ferroli part no. 814590 |
|||
| 2 | OBSOLETE TEMPLATE Ferroli part no. 817600 |
|||
| 3 | OBSOLETE PLATE - SUPPORT Ferroli part no. 813530 |
|||
| 5 |  |
VALVE - SAFETY ( 15MM ) Ferroli part no. 36901310 |
£5.44 | |
| 7 | OBSOLETE RETURN & FLOW VALVE Ferroli part no. 811300 |
|||
| 9 |  |
NUT - 1/2" JIG VALVE Ferroli part no. 34007880 |
£2.52 | |
| 10 |  |
NUT - 3/4" JIG VALVE Ferroli part no. 34007430 |
£1.62 | |
| 13 |  |
WASHER - 3/4" CF4324 (K42) Ferroli part no. 30810710 |
£0.16 | |
| 14 |  |
WASHER - 1/2" CF4324 (K42) Ferroli part no. 30810850 |
£0.16 | |
| 15 | WASHER - MOUNTING PLATE Ferroli part no. 34504920 |
£0.20 | ||
| 16 | OBSOLETE WALL SCREW KIT Ferroli part no. 816980 |
|||
| 17 | NUT - M8 ( JIG VALVE ) Ferroli part no. 34502000 |
£0.16 | ||
| 18 | OBSOLETE INSULATION BUSHING SHORT - BLACK NYLON Ferroli part no. 814860 |
|||
| 20 | OBSOLETE VALVE - GAS ISOLATION Ferroli part no. 30811295 |
|||
| 21 | FRAME - BOILER Ferroli part no. 37103630 |
£34.41 | ||
| 22 |  |
PIN - SUPPORT Ferroli part no. 34008470 |
£1.05 | |
| 23 | BRACKET - EXPANSION VESSEL Ferroli part no. 31260620 |
£8.19 | ||
| 24 | BRACKET - EXPANSION VESSEL Ferroli part no. 31206460 |
£9.94 | ||
| 25 |  |
EXPANSION VESSEL - ( 7 LITRE) Ferroli part no. 39800960 |
£107.18 | |
| 26 |  |
GASKET - EXPANSION VESSEL Ferroli part no. 33700530 |
£0.33 | |
| 27 | PLATE - HEAT DEFLECTION Ferroli part no. 32908850 |
£11.10 | ||
| 28 | COVER - PCB Ferroli part no. 32908840 |
£13.06 | ||
| 29 | OBSOLETE PLATE - CONNECTOR BLOCK 77FF Ferroli part no. 817530 |
|||
| 31 | OBSOLETE WIRE CLAMPING - CARPANETO 3079 Ferroli part no. 814850 |
|||
| 32 | PCB - HOUSING Ferroli part no. 36504980 |
£23.11 | ||
| 33 | OBSOLETE BUSH - ROMA Ferroli part no. 811830 |
|||
| 34 | PANEL - SIDE Ferroli part no. 31135620 |
£11.87 | ||
| 36 | PANEL-FRONT Ferroli part no. 31135680 |
£23.76 | ||
| 38 |  |
PANEL - DROP DOWN "INNER" Ferroli part no. 31135740 |
£9.82 | |
| 39 |  |
PANEL - DROP DOWN "FRONT" Ferroli part no. 31135730 |
£6.48 | |
| 40 |  |
PANEL - BOTTOM Ferroli part no. 31135660 |
£10.63 | |
| 41 |  |
HINGE - R/H Ferroli part no. 34100520 |
£4.91 | |
| 42 | PANEL - DROP DOWN Ferroli part no. 38500010 |
£17.06 | ||
| 43 | KNOB - THERMOSTATIC Ferroli part no. 35001940 |
|||
| 45 |  |
HINGE - L/H Ferroli part no. 34100530 |
£4.91 | |
| 48 |  |
GAUGE - TEMPERATURE / PRESSURE Ferroli part no. 39800300 |
£46.33 | |
| 49 |  |
GENERATOR - SPARK Ferroli part no. 39801150 |
||
| 52 |  |
PCB - VMF6.1 Ferroli part no. 39802540 |
£510.84 | |
| 54 | OBSOLETE CONNECTOR BLOCK - 160 ST 77FF Ferroli part no. 814460 |
|||
| 55 |  |
CONNECTOR BLOCK OK.432/3 77FF Ferroli part no. 36503870 |
£2.80 | |
| 56 | OBSOLETE SUPPORT - ELECTRIC BOX Ferroli part no. 817500 |
|||
| 57 | ROOM SEALED COMPARTMENT Ferroli part no. 37511450 |
£34.70 | ||
| 58 | OBSOLETE TEST POINT - PRESSURE SWITCH Ferroli part no. 34008543 |
|||
| 59 |  |
TEST POINT - "GAS/AIR" Ferroli part no. 39801090 |
£4.39 | |
| 59 |  |
NOW USE 39801090 TEST POINT - Ferroli part no. 33400280 |
||
| 60 | OBSOLETE NUT 1/8IN RING Ferroli part no. 818430 |
|||
| 61 |  |
GASKET - COMBUSTION CHAMBER (10MM X10MM) Ferroli part no. 39800530 |
£17.57 | |
| 65 | OBSOLETE DAMPER - COMPLETE 76/77 600-800 Ferroli part no. 814360 |
|||
| 66 | OBSOLETE BUSH Ferroli part no. 811190 |
|||
| 67 | OBSOLETE NUT Ferroli part no. 811229 |
|||
| 68 |  |
FAN ASSEMBLY Ferroli part no. 39800440 |
£143.44 | |
| 71 | OBSOLETE INSULATION - BACK Ferroli part no. 814030 |
|||
| 71 | OBSOLETE INSULATION - SIDE 77FF Ferroli part no. 815280 |
|||
| 71 | COMBUSTION CHAMBER - UPPER Ferroli part no. 37401770 |
£19.76 | ||
| 72 | INSULATION - COMBUSTION CHAMBER PANEL Ferroli part no. 35315300 |
£4.88 | ||
| 72 | PANEL - COMBUSTION CHAMBER Ferroli part no. 37400910 |
£22.74 | ||
| 73 | COLLAR - FLUE Ferroli part no. 32112860 |
£4.43 | ||
| 74 |  |
HEAT EXCHANGER Ferroli part no. 39802170 |
£450.14 | |
| 75 |  |
PLATE - PILOT ( TUBE & THERMO ) Ferroli part no. 31207270 |
£1.67 | |
| 76 | PACKING - PILOT TUBE / THERMO Ferroli part no. 35001750 |
£5.01 | ||
| 77 | SMOKE BOX - ( CF ) Ferroli part no. 37510530 |
£30.85 | ||
| 78 | SPRING - SMOKE BOX Ferroli part no. 34403030 |
£2.40 | ||
| 79 | OBSOLETE SPRING STRIP Ferroli part no. 811350 |
|||
| 80 |  |
WASHER - PRESSURE GAUGE Ferroli part no. 33700381 |
£0.71 | |
| 81 | PLATE - SUPPORT Ferroli part no. 31206420 |
£3.84 | ||
| 82 |  |
AIR PRESSURE SWITCH Ferroli part no. 39800140 |
£40.76 | |
| 83 | INJECTOR - AIR PRESSURE SWITCH (0.65MM) Ferroli part no. 34008770 |
£1.64 | ||
| 84 |  |
TUBE - SILICONE (APS) 10MM CLEAR Ferroli part no. 36503390 |
£7.22 | |
| 86 | NOW USE 39806250 SIGHT GLASS - BURNER INSPECTION E50 Ferroli part no. 35315240 |
|||
| 86 | GASKET KIT - BURNER COVER Ferroli part no. 39806250 |
£27.53 | ||
| 87 | SHROUD - SIGHT INSPECTION GLASS COVER E50 Ferroli part no. 34100431 |
£1.96 | ||
| 88 |  |
NOW USE 39800540 GAS VALVE - V8600N Ferroli part no. 800540 |
||
| 88 |  |
GAS VALVE - ( V8600N ) Ferroli part no. 39800540 |
£367.82 | |
| 88 | SOLENOID - 24 VOLT V804A Ferroli part no. 39408220 |
£125.36 | ||
| 88 |  |
FROLI 39408290 MODUREG Ferroli part no. 39408290 |
£86.30 | |
| 89 |  |
GASKET (10) - GAS VALVE Ferroli part no. 39801070 |
£7.00 | |
| 89 | NOW USE 39801070 GASKET - GAS VALVE Ferroli part no. 35100342 |
|||
| 90 | PIPE - GAS VALVE TO MANIFOLD Ferroli part no. 38436563 |
|||
| 91 | OBSOLETE FRAME - BURNER Ferroli part no. 818050 |
|||
| 92 | FROLI 810930 MANIFOLD COMPLETE Ferroli part no. 38440930 |
£21.87 | ||
| 93 |  |
NOW USE 39810140 BURNER BAR Ferroli part no. 37607090 |
||
| 93 |  |
BURNER BAR Ferroli part no. 39810140 |
£18.27 | |
| 94 |  |
INJECTOR - MAIN (2.10-NG) Ferroli part no. 34005850 |
£1.93 | |
| 95 |  |
GASKET -INJECTOR Ferroli part no. 33700480 |
£1.39 | |
| 96 | BURNER BAR - C/W PILOT BRACKET Ferroli part no. 37607900 |
£14.83 | ||
| 97 | COMBUSTION CHAMBER Ferroli part no. 37400880 |
£20.72 | ||
| 98 |  |
PILOT - SUPPLY TUBE ALU F2 68-102 T 6MM Ferroli part no. 34223230 |
£2.09 | |
| 99 |  |
NOW USE 39803010 THERMOCOUPLE Ferroli part no. 36702070 |
||
| 99 |  |
THERMOCOUPLE Ferroli part no. 39803010 |
£22.26 | |
| 100 |  |
ELECTRODE - IGNITION Ferroli part no. 39800280 |
£24.14 | |
| 101 | PILOT ASSEMBLY Ferroli part no. 39801900 |
£24.04 | ||
| 101 | NOW USE 39801900 PILOT ASSEMBLE Ferroli part no. 36702180 |
|||
| 102 |  |
NOW USE 39803550 INJECTOR - PILOT (0.33-NG) Ferroli part no. 33700570 |
||
| 102 |  |
INJECTOR - PILOT (0.33-NG) Ferroli part no. 39803550 |
£7.41 | |
| 103 |  |
LEAD - ELECTRODE Ferroli part no. 39801190 |
£8.68 | |
| 104 | PLATE - PILOT COVER Ferroli part no. 32112690 |
£7.71 | ||
| 105 | OBSOLETE SPY HOLE FLAP FOR PILOT 77FF Ferroli part no. 811710 |
|||
| 106 |  |
WIRE - ECO SPLIT WIRE Ferroli part no. 38314061 |
£10.17 | |
| 107 | TUBE - MODULATING Ferroli part no. 38436920 |
£8.21 | ||
| 108 | OBSOLETE GASKET - O-RING 112 77FF Ferroli part no. 810520 |
|||
| 109 |  |
MICROSWITCH - IGNITION Ferroli part no. 39801370 |
£40.97 | |
| 110 | PIPE - GAS INLET Ferroli part no. 38440962 |
£4.47 | ||
| 111 | OBSOLETE CLEANING ROD Ferroli part no. 818780 |
|||
| 112 | OBSOLETE GASKET - SHROUD BURNER Ferroli part no. 810650 |
|||
| 113 | BRACKET - COMBUSTION CHAMBER Ferroli part no. 31207480 |
£10.11 | ||
| 114 | OBSOLETE HOOD - FLUE/AIR INTAKE Ferroli part no. 811210 |
|||
| 115 |  |
NOW USE 39800520 GASKET - SQUARE Ferroli part no. 35100550 |
||
| 115 | GASKET KIT - SQUARE & ROUND Ferroli part no. 39800520 |
£19.65 | ||
| 116 | GASKET KIT - SQUARE & ROUND Ferroli part no. 39800520 |
£19.65 | ||
| 116 |  |
NOW USE 39800520 GASKET - ROUND Ferroli part no. 35100560 |
||
| 117 | OBSOLETE OUTER AIR INTAKE DUCT 100MM X 690MM LONG Ferroli part no. 810013 |
|||
| 117 | OBSOLETE OUTER AIR INTAKE DUCT 100MM X 2M LONG Ferroli part no. 810014 |
|||
| 117 | OBSOLETE DUCT 100MM X 3M LONG - AIR INTAKE OUTER Ferroli part no. 810015 |
|||
| 118 | OBSOLETE DUCT 60MM X 3M LONG - FLUE INNER Ferroli part no. 810012 |
|||
| 118 | OBSOLETE INNER FLUE DUCT 60MM X 2M LONG Ferroli part no. 810011 |
|||
| 118 | BURNER - KIT C/W SEAL Ferroli part no. 39810010 |
£59.87 | ||
| 119 | OBSOLETE TERMINAL 77FF Ferroli part no. 800570 |
|||
| 120 | OBSOLETE SEAL - FLUE Ferroli part no. 35100620 |
|||
| 121 | OBSOLETE SPRING Ferroli part no. 810290 |
|||
| 122 |  |
THERMOSTAT - 100C LIMIT Ferroli part no. 39800170 |
£8.13 | |
| 124 |  |
THERMOSTAT - 88 DEG CH LIMIT Ferroli part no. 39800160 |
£7.38 | |
| 125 | NUT - 1.1/2 PUMP CONNECTION Ferroli part no. 34008800 |
£11.11 | ||
| 126 | OBSOLETE PIPE - PUMP Ferroli part no. 34008530 |
|||
| 127 | OBSOLETE NUT M6 Ferroli part no. 811070 |
|||
| 128 | CAP - HEAT EXCHANGER VENT Ferroli part no. 34008550 |
£2.40 | ||
| 129 |  |
SPHERE Ferroli part no. 34008560 |
£0.82 | |
| 131 |  |
AUTO AIR VENT Ferroli part no. 39801160 |
£18.60 | |
| 132 |  |
SAFETY VALVE - 3 BAR Ferroli part no. 39800130 |
£17.25 | |
| 134 |  |
PUMP ASSEMBLY - GRUNDFOS Ferroli part no. 39800600 |
£170.87 | |
| 135 | OBSOLETE PIPE - RETURN CH Ferroli part no. 38439063 |
|||
| 136 | GASKET - PUMP Ferroli part no. 35100160 |
£0.65 | ||
| 138 | OBSOLETE PIPE - OUTLET DHW Ferroli part no. 38436544 |
|||
| 139 |  |
THERMOSTAT - 70 DEG DHW LIMIT Ferroli part no. 39801000 |
£7.48 | |
| 141 |  |
WASHER - 11MM X 6.6MM (STEEL) Ferroli part no. 33700890 |
£0.38 | |
| 142 | OBSOLETE PIPE - FLOW METER TO HX Ferroli part no. 38443200 |
|||
| 144 | O-RING - SENSOR Ferroli part no. 35100530 |
£1.09 | ||
| 145 | OBSOLETE PIPE - EXPANSION VESSEL Ferroli part no. 38436860 |
|||
| 146 |  |
SENSOR - 1K PTC DHW / CH (WET) Ferroli part no. 39800310 |
£16.49 | |
| 148 |  |
FILTER - DHW FLOW SWITCH Ferroli part no. 39800240 |
£8.65 | |
| 150 |  |
RESTRICTOR - FLOW ( 11/LPM) Ferroli part no. 39801220 |
£21.22 | |
| 151 | PIPE - COLD WATER INLET Ferroli part no. 38436601 |
£10.59 | ||
| 152 |  |
FLOW METER - PADDLE Ferroli part no. 39800120 |
£82.83 | |
| 153 | FROLI 38436551 PIPE - FLOW (CH) 77FF Ferroli part no. 38436551 |
£26.95 | ||
| 154 | KNOB - EXTENSION Ferroli part no. 35001840 |
£3.15 | ||
| 155 | OBSOLETE PLATE - 2 PIPE FLUE/AIR ADAPTER Ferroli part no. 825080 |
|||
| 157 | SCREW - TWO PIPE PLATE Ferroli part no. 34502300 |
£0.72 | ||
