HEATRAE SADIA
PREMIER PLUS INDIRECT SOLAR ERP 250L - (Exploded View)
Appliance Code: Premier plus ID solar 250L

Appliance Diagram


Exploded View diagram for Heatrae Sadia Premier Plus Indirect Solar Erp 250LClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 95606984, Immersion heater (lower) IMMERSION HEATER (LOWER)
Heatrae Sadia part no. 95606984		 £27.21
2 Part number 95606986, Immersion heater (upper) IMMERSION HEATER (UPPER)
Heatrae Sadia part no. 95606986		 £22.52
3 Part number 7702935, GASKET IH GASKET IH
Heatrae Sadia part no. 7702935		 £7.46
4 Part number 95607869, Immersion heater BACK NUT IMMERSION HEATER BACK NUT
Heatrae Sadia part no. 95607869		 £27.45
5 Part number 95607861, KEY SPANNER KEY SPANNER
Heatrae Sadia part no. 95607861		 £6.27
6 Part number 95605838, TUNDISH TUNDISH
Heatrae Sadia part no. 95605838		 £43.92
7 Part number 95605897, COLD WATER COMBINATION VLV COMP COLD WATER COMBINATION VLV COMP
Heatrae Sadia part no. 95605897		 £147.43
8   EXPANSION VALVE 6 BAR
Heatrae Sadia part no. 7036062		 £62.03
9 Part number 7034468, COLD WATER COMBINATION VLV COMP COLD WATER COMBINATION VLV COMP
Heatrae Sadia part no. 7034468		 £156.40
10 Part number 95605810, Temperature and Pressure Relief Valve TEMPERATURE AND PRESSURE RELIEF VALVE
Heatrae Sadia part no. 95605810		 £90.86
11 Part number 95607863, EXPANSION VESSEL 12 LITRE EXPANSION VESSEL 12 LITRE
Heatrae Sadia part no. 95607863		 £209.52
12 Part number 95607864, EXPANSION VESSEL 18 LT EXPANSION VESSEL 18 LT
Heatrae Sadia part no. 95607864		 £232.73
13 Part number 95607612, EXPANSION VESSEL 25L EXPANSION VESSEL 25L
Heatrae Sadia part no. 95607612		 £245.61
14 Part number 95605881, BLANKING PLUG BLANKING PLUG
Heatrae Sadia part no. 95605881		 £6.49
15 Part number 95607838, NUT AND OLIVE PACK NUT AND OLIVE PACK
Heatrae Sadia part no. 95607838		 £18.70
17 Part number 95612720, CONTROL ASSY STAT WIRE DIRECT CONTROL ASSY STAT WIRE DIRECT
Heatrae Sadia part no. 95612720		 £27.70
18 Part number 95612719, CONTROL ASSY STAT WIRE IND CONTROL ASSY STAT WIRE IND
Heatrae Sadia part no. 95612719		 £55.91
19 Part number 95607933, 6 way terminal block 6 WAY TERMINAL BLOCK
Heatrae Sadia part no. 95607933		 £5.82
20 Part number 95607932, NOW USE 95607113 3 way terminal block NOW USE 95607113 3 WAY TERMINAL BLOCK
Heatrae Sadia part no. 95607932
20   TERMINAL BLOCK 3 PORT 10MM CRS
Heatrae Sadia part no. 95607113		 £6.21
21 Part number 95605819, 22mm 2 PORT MOTORISED VALVE 22MM 2 PORT MOTORISED VALVE
Heatrae Sadia part no. 95605819		 £168.07
22   ELEMENT TAG
Heatrae Sadia part no. 95606993		 £2.59
23 Part number 95607064, POCKET TEMP PROBE SOLAR POCKET TEMP PROBE SOLAR
Heatrae Sadia part no. 95607064		 £17.79
24 Part number 95612698, THERMAL CUT OUT THERMAL CUT OUT
Heatrae Sadia part no. 95612698		 £68.75
25   CONTROL COVER ASSY
Heatrae Sadia part no. 90002515		 £9.77
26 Part number 95612702, WIRING CENTRE S/FIT HE WIRING CENTRE S/FIT HE
Heatrae Sadia part no. 95612702		 £60.58
