VAILLANT
ECOTEC PLUS VU GB 1206/5-5 R2 2013-2014 - (04 Burner)
Appliance Code: 41-044-70 R2

Appliance Diagram


04 Burner diagram for Vaillant Ecotec Plus VU GB 1206/5-5 R2 2013-2014Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020143512, Gas control valve GAS CONTROL VALVE
Vaillant part no. 0020143512		 £472.21
2 Part number 0020143467, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 0020143467		 £18.24
3 Part number 0020143468, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020143468		 £6.73
4 Part number 0020143469, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020143469		 £6.91
5 Part number 0020143470, Gas pipe GAS PIPE
Vaillant part no. 0020143470		 £85.82
6 Part number 0020143458, Gas pipe GAS PIPE
Vaillant part no. 0020143458		 £111.01
7 Part number 0020140757, Fan FAN
Vaillant part no. 0020140757		 £866.71
8 Part number 0020143472, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020143472		 £6.91
10 Part number 0020143440, Electrode, Maintenance kit ELECTRODE, MAINTENANCE KIT
Vaillant part no. 0020143440		 £80.59
11 Part number 0020143441, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020143441		 £6.91
12 Part number 0020143442, Gasket GASKET
Vaillant part no. 0020143442		 £6.91
13 Part number 0020143444, Gasket GASKET
Vaillant part no. 0020143444		 £6.73
14 Part number 0020143445, Inspection glass INSPECTION GLASS
Vaillant part no. 0020143445		 £25.52
15 Part number 0020143446, Gasket GASKET
Vaillant part no. 0020143446		 £7.73
16 Part number 0020173386, Combustion chamber cover COMBUSTION CHAMBER COVER
Vaillant part no. 0020173386		 £244.31
17 Part number 0020173392, NOW USE 0020272056 Seal kit NOW USE 0020272056 SEAL KIT
Vaillant part no. 0020173392
17 Part number 0020272056, SEAL KIT SEAL KIT
Vaillant part no. 0020272056		 £91.38
17A Part number 0020188931, Gasket (Combustion chamber cover) GASKET (COMBUSTION CHAMBER COVER)
Vaillant part no. 0020188931		 £46.04
18 Part number 0020143478, Burner BURNER
Vaillant part no. 0020143478		 £487.32
19 Part number 0020143479, Cover plate COVER PLATE
Vaillant part no. 0020143479
20 Part number 0020143480, Pressure safeguard PRESSURE SAFEGUARD
Vaillant part no. 0020143480		 £91.75
21 Part number 0020143448, Transformer TRANSFORMER
Vaillant part no. 0020143448		 £10.60
22 Part number 0020136643, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020136643		 £6.86
23 Part number 0020143456, Temperature limiter TEMPERATURE LIMITER
Vaillant part no. 0020143456		 £30.67
24 Part number 0020143481, Support SUPPORT
Vaillant part no. 0020143481		 £6.91
25 Part number 0020143460, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 0020143460		 £6.73
26 Part number 0020143483, Air inlet duct AIR INLET DUCT
Vaillant part no. 0020143483		 £17.51
27 Part number 0020143484, Air inlet duct AIR INLET DUCT
Vaillant part no. 0020143484		 £51.62
28 Part number 0020160125, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020160125		 £6.91
29 Part number 0020135152, Washer, (PK10) WASHER, (PK10)
Vaillant part no. 0020135152		 £6.86
30 Part number 0020143461, Gasket GASKET
Vaillant part no. 0020143461		 £6.91
31 Part number 0020143491, Hose HOSE
Vaillant part no. 0020143491		 £8.68
33 Part number 0020143465, Wiring harness WIRING HARNESS
Vaillant part no. 0020143465		 £15.75
34 Part number 0020143464, Wiring harness WIRING HARNESS
Vaillant part no. 0020143464		 £25.34
35 Part number 0020144366, Washer (PK10) WASHER (PK10)
Vaillant part no. 0020144366		 £17.59
36 Part number 0020144367, Nut (PK10) NUT (PK10)
Vaillant part no. 0020144367		 £6.91
38 Part number 080075, Compression fitting 1 inch COMPRESSION FITTING 1 INCH
Vaillant part no. 080075		 £39.29
39 Part number 0020143523, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020143523		 £6.91
40 Part number 0020173393, Gasket GASKET
Vaillant part no. 0020173393		 £8.46
41 Part number 0020144366, Washer (PK10) WASHER (PK10)
Vaillant part no. 0020144366		 £17.59
42 Part number 0020144367, Nut (PK10) NUT (PK10)
Vaillant part no. 0020144367		 £6.91
