VAILLANT
ECOTEC PLUS VU GB 446/5-5 H - (05 Gas Section)
Appliance Code: 41-694-28

Appliance Diagram


05 Gas Section diagram for Vaillant Ecotec Plus VU GB 446/5-5 HClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

01 Part number 0020268767, AIR INLET DUCT AIR INLET DUCT
Vaillant part no. 0020268767
£23.15
02 Part number 0020135151, Support air inlet duct SUPPORT AIR INLET DUCT
Vaillant part no. 0020135151
£6.66
03 Part number 0020135152, Washer, (PK10) WASHER, (PK10)
Vaillant part no. 0020135152
£6.66
04 Part number 0020133833, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 0020133833
£6.66
05 Part number 981111, Gasket GASKET
Vaillant part no. 981111
£6.66
06 Part number 0020268755, FAN FAN
Vaillant part no. 0020268755
£198.86
07 Part number 981104, Gasket GASKET
Vaillant part no. 981104
£7.92
08 Part number 0020268756, VENTURI VENTURI
Vaillant part no. 0020268756
£25.09
09 Part number 0020268760, O RING (10X) O RING (10X)
Vaillant part no. 0020268760
£14.21
10 Part number 0020268759, GAS PIPE, GAS CONTROL VALVE GAS PIPE, GAS CONTROL VALVE
Vaillant part no. 0020268759
£33.02
11 Part number 0020268761, CLIP (X10) CLIP (X10)
Vaillant part no. 0020268761
£12.04
12 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140
£7.05
13 Part number 0020268758, GAS CONTROL VALVE GAS CONTROL VALVE
Vaillant part no. 0020268758
£84.06
14 Part number 0020213915, Spark generator SPARK GENERATOR
Vaillant part no. 0020213915
£10.49
15 Part number 108628, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 108628
£6.66
16 Part number 509685, Screw, (PK10) SCREW, (PK10)
Vaillant part no. 509685
£6.66
17 Part number 0020268757, SUPPORT, GAS CONTROL VALVE SUPPORT, GAS CONTROL VALVE
Vaillant part no. 0020268757
£15.62
