ANDREWS
CLASSICFLO RSC 9/180 (ISSUE 4) - (Exploded View)
Appliance Code: CLASSICFLO RSC 9/180

Appliance Diagram


Exploded View diagram for Andrews Classicflo RSC 9/180 (Issue 4)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   PLENUM
Andrews part no. 7704029
£200.74
2   PLENUM COVER GASKET
Andrews part no. 7678672
£5.03
3   FLUE REDUCER
Andrews part no. 7704030
£46.56
4   FLUE BAFFLE
Andrews part no. 7704032
£40.45
5   COLDWATER INLET DIP TUBE BRASS
Andrews part no. 7721571
£114.49
6   ANODE/HOT WATER OUTLET BRASS
Andrews part no. 7721566
£113.64
7   OUTER DOOR
Andrews part no. 7703994
£235.99
8   INNER DOOR GASKET KIT
Andrews part no. 7703877
£70.37
9   GAS PILOT ASSEMBLY
Andrews part no. 7703881
£129.53
11   OUTER DOOR
Andrews part no. 7703876
£35.33
12   BRASS SENSOR WELL
Andrews part no. 7703875
£123.14
13   GAS VALVE BRACKET
Andrews part no. 7678973
£96.44
14   GAS VALVE
Andrews part no. 7678972
£820.15
15   INNER DOOR GASKET KIT
Andrews part no. 7724196
£44.19
16   KIT EXHAUSRT VENTING
Andrews part no. 7721606
£177.95
