WORCESTER
GREENSTAR LIFE GR8300IW 50R NG - (Connections)
Appliance Code: 41-406-94

Appliance Diagram


Connections diagram for Worcester Greenstar Life GR8300IW 50R NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 87161155350, WASHER SET-MOUNTING SET WASHER SET-MOUNTING SET
Worcester part no. 87161155350		 £5.68
1   MOUNTING PLATE
Worcester part no. 87186634810		 £108.03
3 Part number 87133057650, SET OF NUTS SET OF NUTS
Worcester part no. 87133057650		 £11.85
4 Part number 87377030440, CONNECTOR CONNECTOR
Worcester part no. 87377030440		 £24.26
6 Part number 87161094290, GAS COCK GAS COCK
Worcester part no. 87161094290		 £17.38
7   FLOW PIPE
Worcester part no. 87186642480		 £59.75
8   RETURN
Worcester part no. 87186642450		 £70.86
9 Part number 29144114200, SCREW (10X) M5X12 SCREW (10X) M5X12
Worcester part no. 29144114200		 £2.95
10   WASHER (10X)
Worcester part no. 87377048990		 £7.19
12 Part number 87101030430, FIBRE WASHER 23.9 X 17.2 X 1.5 FIBRE WASHER 23.9 X 17.2 X 1.5
Worcester part no. 87101030430		 £2.84
