ARISTON
ACO 35 PLUS R8202956-01EN - EDITION 01 - 30/01/2006 - (Chassis Casing)
Appliance Code: 47-116-46

Appliance Diagram


Chassis Casing diagram for Ariston ACO 35 Plus R8202956-01EN - Edition 01 - 30/01/2006Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

802   CASING
Ariston part no. 60000217
£108.21
803   PROTECTING PLATE
Ariston part no. 61303185
£54.02
804 Part number 60056676-06, EXPANSION VESSEL 7L EXPANSION VESSEL 7L
Ariston part no. 60056676-06
£142.17
805 Part number 61306594, FLEXIBLE PIPE KIT FLEXIBLE PIPE KIT
Ariston part no. 61306594
£27.32
806   FACIA
Ariston part no. 60000218
£17.50
807 Part number 61308868, SHEET GASKET D: 12-6-2 SHEET GASKET D: 12-6-2
Ariston part no. 61308868
£0.67
808 Part number 61009834-14, O-RING 8.9X2.7 O-RING 8.9X2.7
Ariston part no. 61009834-14
£0.50
809 Part number 61010005, CLIP CLIP
Ariston part no. 61010005
£1.53
810   SUPPORT BRACKET
Ariston part no. 61305617
£3.09
811 Part number 61010648, TAPPING SCREW CBLSX D: 6.3-13 TAPPING SCREW CBLSX D: 6.3-13
Ariston part no. 61010648
£0.44
812 Part number 61010847, TAPPING SCREW CBLSX D:4.2-12.5 TAPPING SCREW CBLSX D:4.2-12.5
Ariston part no. 61010847
£0.81
813 Part number 61010125, TAPPING SCREW CBLSX D: 4.2-9.5 TAPPING SCREW CBLSX D: 4.2-9.5
Ariston part no. 61010125
£0.42
815   HOOKING BRACKET
Ariston part no. 61314757
£21.27
816   SPACER
Ariston part no. 61314844
£5.07
817   CONNECTION BOX - ROOM THERMOS.
Ariston part no. 61316129
£13.73
818 Part number 61010127, TAPPING SCREW CBLSX D: 6.3-19 TAPPING SCREW CBLSX D: 6.3-19
Ariston part no. 61010127
£2.84
819   TAPPING SCREW CBLSX D: 6.3-19
Ariston part no. 61014516
£0.54
820   STUD
Ariston part no. 60000205
£4.86
