ARISTON
ACO 35 PLUS R8202956-01EN - EDITION 01 - 30/01/2006 - (Hot Water Tank)
Appliance Code: 47-116-46

Appliance Diagram


Hot Water Tank diagram for Ariston ACO 35 Plus R8202956-01EN - Edition 01 - 30/01/2006Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

601   HOT WATER TANK 45L
Ariston part no. 61317027		 £571.01
601 Part number 61317346, GASKET GASKET
Ariston part no. 61317346		 £31.96
603 Part number 61314258, THERMISTOR THERMISTOR
Ariston part no. 61314258		 £13.80
604 Part number 61010050, CLIP CLIP
Ariston part no. 61010050		 £3.87
605 Part number 61307589, CLIP (TO 03/06) CLIP (TO 03/06)
Ariston part no. 61307589		 £2.72
606 Part number 61010572, OVERHEAT THERMOSTAT 100C OVERHEAT THERMOSTAT 100C
Ariston part no. 61010572		 £6.87
607   INSULATION-W/WATER HEAT EXCH.
Ariston part no. 61303156		 £2.72
608   HEATING FLOW BEND
Ariston part no. 61314700		 £17.62
609 Part number 61302409-01, SANITARY HEAT EXCHANGER (16 P.) SANITARY HEAT EXCHANGER (16 P.)
Ariston part no. 61302409-01		 £112.94
609 Part number 61314111, NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16 NOW USE 61302409-01 WATER / WATER HEAT EXCHANGER 16
Ariston part no. 61314111
610   HEATING FLOW BEND
Ariston part no. 61314831		 £11.86
611 Part number 61002249, LIP SEAL x1 LIP SEAL X1
Ariston part no. 61002249		 £1.88
612 Part number 61016206-02, PIN PIN
Ariston part no. 61016206-02		 £5.40
613 Part number 61302492, INTERFACE SYSTEM - EXCHANGER INTERFACE SYSTEM - EXCHANGER
Ariston part no. 61302492		 £6.76
614 Part number 61303369, SUPPORT SUPPORT
Ariston part no. 61303369		 £5.91
615 Part number 61302631, SCREW HSX M 5-8 SCREW HSX M 5-8
Ariston part no. 61302631		 £0.62
617 Part number 61302533, TOP INTERFACE SYSTEM ASSY TOP INTERFACE SYSTEM ASSY
Ariston part no. 61302533		 £19.27
618 Part number 61302622, LIP SEAL LIP SEAL
Ariston part no. 61302622		 £4.46
621 Part number 61306596, BOTTOM INTERFACE SYSTEM ASSY BOTTOM INTERFACE SYSTEM ASSY
Ariston part no. 61306596		 £38.91
622   WASHER
Ariston part no. 61304158		 £0.66
623 Part number 61010131, SCREW HX M 5-12 SCREW HX M 5-12
Ariston part no. 61010131		 £0.42
624 Part number 61303238, CUPEL CUPEL
Ariston part no. 61303238		 £2.66
625 Part number 61303237, CLIP CLIP
Ariston part no. 61303237		 £5.98
627   FLOW TUBE
Ariston part no. 61314693		 £15.27
628 Part number 60024164-51, O-RING D: 17-4 O-RING D: 17-4
Ariston part no. 60024164-51		 £1.18
629   TUBE EAU FROIDE SANITAIRE
Ariston part no. 60000210		 £16.21
632 Part number 61303236, SCREW HSX M 5-80 SCREW HSX M 5-80
Ariston part no. 61303236		 £1.42
635 Part number 61305099, HOT WATER BEND HOT WATER BEND
Ariston part no. 61305099		 £14.90
636 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Ariston part no. 60061855-14		 £0.60
641   CONNECTING PIPE
Ariston part no. 61010430		 £3.27
642 Part number 61316921, EXPANSION VESSEL 2L EXPANSION VESSEL 2L
Ariston part no. 61316921		 £124.80
643 Part number 60031139, LOCK NUT 1/2" LOCK NUT 1/2"
Ariston part no. 60031139		 £2.27
644   FLEXIBLE PIPE KIT
Ariston part no. 61314703		 £12.12
645   PIN
Ariston part no. 61303316		 £3.71
646 Part number 61010012, CLIP CLIP
Ariston part no. 61010012		 £1.53
647 Part number 61308091, O-RING 17.86X2.62 O-RING 17.86X2.62
Ariston part no. 61308091		 £1.31
648   VALVE TUBE
Ariston part no. 61313758		 £13.55
649   PRESSURE RELIEF VALVE 7 BARS
Ariston part no. 61314112		 £30.71
650   VALVE TUBE
Ariston part no. 60000206		 £57.94
652   GASKET
Ariston part no. 61012487		 £3.80
653   CONNECTION
Ariston part no. 61012470		 £12.37
654   NUT 1/2"
Ariston part no. 61012781		 £9.59
655   PIPE (D.H.W. EXPANSION VESSEL)
Ariston part no. 60000211		 £18.31
656 Part number 61305179, PIN PIN
Ariston part no. 61305179		 £1.66
657 Part number 573140, NOW USE 969046 TEMPERATURE/PRESSURE RELIEF VALVE(7 BAR) NOW USE 969046 TEMPERATURE/PRESSURE RELIEF VALVE(7 BAR)
Ariston part no. 573140
657 Part number 969046, TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08) TEMPERATURE+PRESSURE RELIEF VALVE (FROM 04/08)
Ariston part no. 969046		 £76.84
