ARISTON
ACO 35 PLUS R8202956-01EN - EDITION 01 - 30/01/2006 - (Jig And Pipes)
Appliance Code: 47-116-46

Appliance Diagram


Jig And Pipes diagram for Ariston ACO 35 Plus R8202956-01EN - Edition 01 - 30/01/2006Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

901 Part number 61303031, WATER FLOW & RETURN SERVI. TAP WATER FLOW & RETURN SERVI. TAP
Ariston part no. 61303031
£13.19
902 Part number 61303034, WATER TAP WATER TAP
Ariston part no. 61303034
£13.19
903 Part number 61303032, GAS SERVICE TAP GAS SERVICE TAP
Ariston part no. 61303032
£13.19
910 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Ariston part no. 60061855-14
£0.60
911 Part number 60061855-19, SHEET GASKET D: 24-17-1.5 SHEET GASKET D: 24-17-1.5
Ariston part no. 60061855-19
£0.69
912 Part number 60022835-01, SHEET GASKET D: 24-18.2-1.5 SHEET GASKET D: 24-18.2-1.5
Ariston part no. 60022835-01
£0.62
913 Part number 60061854-11, SHEET GASKET D: 14.8-10.3-1.5 SHEET GASKET D: 14.8-10.3-1.5
Ariston part no. 60061854-11
£0.58
914   WATER FILTER
Ariston part no. 61303153
£1.60
915 Part number 573543, TAP (M-M 3/8 ) TAP (M-M 3/8 )
Ariston part no. 573543
£10.80
915 Part number 990742, NOW USE 573543 TAP (M/M 3/8 - C.H. FLOW) NOW USE 573543 TAP (M/M 3/8 - C.H. FLOW)
Ariston part no. 990742

916 Part number 65102016, TAP (M/M 3/8 ) TAP (M/M 3/8 )
Ariston part no. 65102016
£22.21
922   GASKETS SET
Ariston part no. 60000221
£4.95
931   JIG PLATE
Ariston part no. 61310480
£10.90
938   PRESSURE REDUCING VALVE (3.5BAR)
Ariston part no. 573359
£195.26
940 Part number 60000220, TUNDISH TUNDISH
Ariston part no. 60000220
£34.58
941   DOUILLE RACCORDEMENT SOUPAPE
Ariston part no. 60000219
£15.78
942 Part number 990737, FILLING LOOP PIPE FILLING LOOP PIPE
Ariston part no. 990737
£10.71
