POTTERTON
PROMAX COMBI 24 ERP (SERIAL NO ENDING DC) - (Combustion Box)
Appliance Code: 47-393-47 DC

Appliance Diagram


Combustion Box diagram for Potterton Promax Combi 24 ERP (Serial No Ending DC)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

200 Part number 720851201, FLUE ADAPTER FLUE ADAPTER
Potterton part no. 720851201		 £29.30
200A Part number 062617, SCR-ST-No8x1/2 PAN POZ.TYPE B SCR-ST-NO8X1/2 PAN POZ.TYPE B
Potterton part no. 062617		 £3.16
201 Part number 5112397, WASHER DIA 60 OUTLET BEND WASHER DIA 60 OUTLET BEND
Potterton part no. 5112397		 £5.88
202 Part number 5112398, WASHER DIA100 OUTER ADAPT SEAL WASHER DIA100 OUTER ADAPT SEAL
Potterton part no. 5112398		 £5.88
203 Part number 5113313, TAP ADAPTER TAP ADAPTER
Potterton part no. 5113313		 £4.57
204 Part number 5113314, O RING O RING
Potterton part no. 5113314		 £3.16
205 Part number 5112370, GASKET ADAPTER GASKET ADAPTER
Potterton part no. 5112370		 £4.57
208 Part number 5114766, IGNITOR IGNITOR
Potterton part no. 5114766		 £20.02
209 Part number 5114691, EXPANSION VESSEL 8L EXPANSION VESSEL 8L
Potterton part no. 5114691		 £77.67
209A Part number 248000, WASHER - SEALING WASHER - SEALING
Potterton part no. 248000		 £3.16
209B Part number 223966, NUT-LOCK-M14 X 1-BRASS NUT-LOCK-M14 X 1-BRASS
Potterton part no. 223966		 £3.12
209C   BRACKET - EXPANSION VESSEL
Potterton part no. 7686348		 £0.62
210 Part number 5114774, GASKET WITH DOUBLE LIP GASKET WITH DOUBLE LIP
Potterton part no. 5114774		 £3.26
211 Part number 5118375, DRIP TRAY/REDUCER DIA 80/60 DRIP TRAY/REDUCER DIA 80/60
Potterton part no. 5118375		 £20.11
212   COMBUSTION CHAMBER ASSY
Potterton part no. 5118374		 £90.93
213 Part number 5114693, COMBUSTION CHAMBER FRONT COMBUSTION CHAMBER FRONT
Potterton part no. 5114693		 £35.70
213A Part number 062617, SCR-ST-No8x1/2 PAN POZ.TYPE B SCR-ST-NO8X1/2 PAN POZ.TYPE B
Potterton part no. 062617		 £3.16
217 Part number 248192, STUD - FRONT PANEL STUD - FRONT PANEL
Potterton part no. 248192		 £3.26
217 Part number 635431, NUT FULL M4 HEX. MS NICK.PLT NUT FULL M4 HEX. MS NICK.PLT
Potterton part no. 635431		 £3.12
218 Part number 5114735, MOUNTING PANEL - HYDRAULICS MOUNTING PANEL - HYDRAULICS
Potterton part no. 5114735		 £23.74
219 Part number 5118378, CONDENSATE BODY CONDENSATE BODY
Potterton part no. 5118378		 £18.11
220   KIT - PIPE SILICONE
Potterton part no. 7648873		 £28.90
221 Part number 5114763, FLEXIBLE DISCHARGE PIPE SIPHON FLEXIBLE DISCHARGE PIPE SIPHON
Potterton part no. 5114763		 £11.95
222 Part number 5118972, CONDENSE SIPHON PLUG ASSEMBLY CONDENSE SIPHON PLUG ASSEMBLY
Potterton part no. 5118972		 £11.16
223 Part number 7210676, NOW USE 7787376 ELBOW - CONDENSATE PIPE NOW USE 7787376 ELBOW - CONDENSATE PIPE
Potterton part no. 7210676
223   NOW USE 7787376 KIT ELBOW CONDENSATE WHITE
Potterton part no. 7648751
223   ELBOW - CONDENSATE PIPE
Potterton part no. 7787376		 £11.60
226 Part number 5118377, FLUE SECURING BRKT FLUE SECURING BRKT
Potterton part no. 5118377
227 Part number 5118376, TRAY DRAIN PIPE TRAY DRAIN PIPE
Potterton part no. 5118376		 £39.25
228   HT EXCH BRKT 4E-24-28KW
Potterton part no. 720758701		 £29.83
