POTTERTON
COMBI 36 - (Hydraulics)
Appliance Code: 47-393-67

Appliance Diagram


Hydraulics diagram for Potterton Combi 36Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

401   PLATE HEAT EXCHANGER (16 PLATES)
Potterton part no. 7715760
£71.23
402   KIT GASKET SET INC SCREWS
Potterton part no. 7683967
£3.94
403 Part number 7216534, MOTOR BLACK/WHITE INC CLIP MOTOR BLACK/WHITE INC CLIP
Potterton part no. 7216534
£46.67
404 Part number 248736, CLIP-RETAINING CLIP-RETAINING
Potterton part no. 248736
£4.57
405   KIT DIVERTER VALVE ASSEMBLY
Potterton part no. 7683969
£108.32
406 Part number 720789201, NTC SENSOR NTC SENSOR
Potterton part no. 720789201
£18.62
406A Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Potterton part no. 7211908
£3.14
407 Part number 710115301, SCREW M5X14 HEX POZI SCREW M5X14 HEX POZI
Potterton part no. 710115301
£2.55
408   KIT GAS PIPE ASSEMBLY
Potterton part no. 7683970
£46.52
409   NOZZLE INCL WASHER 36KW NG
Potterton part no. 7715905
£12.63
410 Part number 7683968, KIT GAS VALVE 22V ASSEMBLY KIT GAS VALVE 22V ASSEMBLY
Potterton part no. 7683968
£98.33
411   GASKET GAS VALVE SIT 848
Potterton part no. 7214350
£7.11
412   G3/4 FIBRE WASHER
Potterton part no. 720910201
£15.79
413   SEAL & FIXING SPRING - GAS PIPE
Potterton part no. 7683971
£7.41
414   PIPE - EXPANSION VESSEL
Potterton part no. 7715761
£18.14
415   KIT O-RINGS X2 EXPAN VESSEL
Potterton part no. 7683973
£7.41
416 Part number 5114748, PRESSURE SWITCH PRESSURE SWITCH
Potterton part no. 5114748
£19.79
417   HALL SENSOR
Potterton part no. 720788201
£29.30
418   RETURN BLOCK - 15L/36KW
Potterton part no. 7715762
£79.97
419   DHW CARTRIDGE - 15L
Potterton part no. 7715773
£39.53
420 Part number 7683976, KIT PRESSURE RELIEF VALVE KIT PRESSURE RELIEF VALVE
Potterton part no. 7683976
£20.33
421   KIT PRV PIPE
Potterton part no. 7683977
£22.62
422   KIT CONNECTIONS PACK - COMBI
Potterton part no. 7686321
£102.78
423 Part number 720782801, SEAL HYDRO GROUP SEAL HYDRO GROUP
Potterton part no. 720782801
£10.53
424   NOW USE 7855245 KIT GRUNDFOS PUMP ASSEMBLED
Potterton part no. 7684006

424   KIT GRUNDFOS PUMP UPM4
Potterton part no. 7855245
£163.34
425 Part number 7686336, KIT PUMP HEAD KIT PUMP HEAD
Potterton part no. 7686336

426 Part number 720777601, AIR VENT VALVE AIR VENT VALVE
Potterton part no. 720777601
£31.80
427 Part number 248000, WASHER - SEALING WASHER - SEALING
Potterton part no. 248000
£3.16
428   CQI RIGID FILLING LOOP
Potterton part no. 720808301
£77.84
