VOKERA
EXCEL 25 REV 6 (06/2016) - (Hydraulics 1)
Appliance Code: 47-364-12 REV 6

Appliance Diagram


Hydraulics 1 diagram for Vokera Excel 25 Rev 6 (06/2016)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 8036, Domestic Heat Exchanger (with 4 x 7999 O DOMESTIC HEAT EXCHANGER (WITH 4 X 7999 O
Vokera part no. 8036
£127.41
2 Part number 10030114, NOW USE 10024640 Connection NOW USE 10024640 CONNECTION
Vokera part no. 10030114

2 Part number 10024640, Connection CONNECTION
Vokera part no. 10024640
£11.50
4 Part number 10025056, Non return valve NON RETURN VALVE
Vokera part no. 10025056
£5.11
6 Part number 10024641, By-pass casing BY-PASS CASING
Vokera part no. 10024641
£14.95
7 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552
£7.77
9 Part number 10026508, Htg manifold & cartridge (3 P V kit) 1ST VERSION HTG MANIFOLD & CARTRIDGE (3 P V KIT) 1ST VERSION
Vokera part no. 10026508
£77.17
9 Part number 20021496, 3 way htg manifold & cartridge 3 WAY HTG MANIFOLD & CARTRIDGE
Vokera part no. 20021496
£78.60
10 Part number 10025305, 3 way valve cartridge (1ST VERSION) 3 WAY VALVE CARTRIDGE (1ST VERSION)
Vokera part no. 10025305
£67.91
10 Part number 20043594, 3 way valve cartridge Rep 20017597 3 WAY VALVE CARTRIDGE REP 20017597
Vokera part no. 20043594
£44.96
11 Part number 20017594, Actuator/Motorised valve ACTUATOR/MOTORISED VALVE
Vokera part no. 20017594
£59.42
11 Part number 20024841, 3-Way Valve Motor (ORANGE LABEL) 3-WAY VALVE MOTOR (ORANGE LABEL)
Vokera part no. 20024841
£34.32
12 Part number 10025450, Fixing fork wrench FIXING FORK WRENCH
Vokera part no. 10025450
£15.13
13 Part number 10025449, Curved Locking Pin (1ST VERSION) CURVED LOCKING PIN (1ST VERSION)
Vokera part no. 10025449
£2.39
13 Part number 20017598, Square Locking Pin (COMPACT VERSION) SQUARE LOCKING PIN (COMPACT VERSION)
Vokera part no. 20017598
£1.44
22 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364
£22.49
24 Part number 10026043, Flow governor 8 Litres Per Min (White) FLOW GOVERNOR 8 LITRES PER MIN (WHITE)
Vokera part no. 10026043
£6.24
25   NOW USE 10025839 PIPE
Vokera part no. 20011423

25   PIPE
Vokera part no. 10025839
£17.46
26 Part number 10022349, DHW Actuator replaces 10020330 DHW ACTUATOR REPLACES 10020330
Vokera part no. 10022349
£33.95
26 Part number 20073700, NOW USE 10022349 ACTUATOR NOW USE 10022349 ACTUATOR
Vokera part no. 20073700

27 Part number 1592, 3/4" Heat water cock 3/4" HEAT WATER COCK
Vokera part no. 1592
£16.13
28 Part number 20025758, Copper Pipe (L Shape) COPPER PIPE (L SHAPE)
Vokera part no. 20025758
£8.94
29 Part number 20025756, Copper Tail 15mm COPPER TAIL 15MM
Vokera part no. 20025756
£6.90
30 Part number 1888, Water supply stop cock WATER SUPPLY STOP COCK
Vokera part no. 1888
£20.79
37 Part number 10025840, Pipe PIPE
Vokera part no. 10025840
£12.94
47 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643
£10.94
48 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646
£7.85
58 Part number 20025757, Copper Tail 22mm COPPER TAIL 22MM
Vokera part no. 20025757
£8.07
63 Part number 20025755, Copper Pipe from Safety Valve COPPER PIPE FROM SAFETY VALVE
Vokera part no. 20025755
£10.93
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

343 Part number 2216, Manifold Plug MANIFOLD PLUG
Vokera part no. 2216
£3.01
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958
£0.98
433 Part number 10024986, Locking Pin LOCKING PIN
Vokera part no. 10024986
£0.98
434 Part number 10024985, Nipple NIPPLE
Vokera part no. 10024985
£11.88
435 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059
£11.53
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062
£2.26
438 Part number 10024988, O ring O RING
Vokera part no. 10024988
£0.81
439 Part number 10025067, O ring O RING
Vokera part no. 10025067
£2.61
441 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063
£0.98
442 Part number 10025065, O ring O RING
Vokera part no. 10025065
£1.91
443 Part number 10025064, O ring O RING
Vokera part no. 10025064
£5.30
444 Part number 10025066, Washer WASHER
Vokera part no. 10025066
£3.27
521 Part number 10027351, Thermistor/NTC Sensor THERMISTOR/NTC SENSOR
Vokera part no. 10027351
£7.96
619 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181
£9.83
700 Part number 20017596, CN4 to Motorised Valve CN4 TO MOTORISED VALVE
Vokera part no. 20017596
£36.90
