VOKERA
LINEA 28 MARK 3 (SER # REF CONTAINS ‘X’) - (Combustion Chamber)
Appliance Code: 47-094-28 MK 3

Appliance Diagram


Combustion Chamber diagram for Vokera Linea 28 Mark 3 (Ser # Ref Contains ‘X’)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

4 Part number 01005272, Air Pressure Switch Rep 7070/8195/9232 AIR PRESSURE SWITCH REP 7070/8195/9232
Vokera part no. 01005272
£58.89
5 Part number 1457, Silicone tube (1 Metre) SILICONE TUBE (1 METRE)
Vokera part no. 1457
£2.12
6 Part number 8086, Brass Cap BRASS CAP
Vokera part no. 8086
£2.51
7 Part number 10026933, Block with combustion analysis check BLOCK WITH COMBUSTION ANALYSIS CHECK
Vokera part no. 10026933
£9.45
8 Part number 8083, Fan Flue Tube FAN FLUE TUBE
Vokera part no. 8083
£11.84
12 Part number 7315, Clamp CLAMP
Vokera part no. 7315
£1.61
14 Part number 7817, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 7817
£14.33
17 Part number 10023183, Fan/Flue Connector (Includes Venturi's) FAN/FLUE CONNECTOR (INCLUDES VENTURI'S)
Vokera part no. 10023183
£49.56
19 Part number 5911, Fan Assembly FAN ASSEMBLY
Vokera part no. 5911
£127.40
20   HOOD ASSEMBLY
Vokera part no. 1842

23 Part number 6028, Combustion Chamber COMBUSTION CHAMBER
Vokera part no. 6028
£22.81
24 Part number 5316, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5316
£15.98
25 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271
£9.55
27 Part number 5269, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5269
£15.98
27 Part number 5315, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5315
£15.04
30   SCREW
Vokera part no. 5080
£0.21
50 Part number 1870, M12 to Fan Wiring M12 TO FAN WIRING
Vokera part no. 1870
£26.85
51 Part number 10020529, M3 to Heat thermistor, High limit stat, Burner stat & Analogue PD switch Wiring M3 TO HEAT THERMISTOR, HIGH LIMIT STAT, BURNER STAT & ANALOGUE PD SWITCH WIRING
Vokera part no. 10020529
£50.08
52   AIR BAFFLE
Vokera part no. 5951

53   AIR BAFFLE
Vokera part no. 5951

54 Part number 5909, Combustion Chamber Front (Metal) COMBUSTION CHAMBER FRONT (METAL)
Vokera part no. 5909
£10.93
