VOKERA
VIBE 25A ERP REV 4 (06/2016) - (Hydraulics 1)
Appliance Code: 41-094-85 REV 4

Appliance Diagram


Hydraulics 1 diagram for Vokera Vibe 25A ERP Rev 4 (06/2016)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

6 Part number 10024641, By-pass casing BY-PASS CASING
Vokera part no. 10024641		 £14.95
7 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552		 £7.77
9 Part number 10027768, Heating manifold & Cartridge HEATING MANIFOLD & CARTRIDGE
Vokera part no. 10027768		 £64.72
10 Part number 10025305, 3 way valve cartridge (1ST VERSION) 3 WAY VALVE CARTRIDGE (1ST VERSION)
Vokera part no. 10025305		 £67.91
12 Part number 10025450, Fixing fork wrench FIXING FORK WRENCH
Vokera part no. 10025450		 £15.13
22 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364		 £22.49
27 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789		 £24.62
47 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643		 £10.94
48 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646		 £7.85
63 Part number 20025755, Copper Pipe from Safety Valve COPPER PIPE FROM SAFETY VALVE
Vokera part no. 20025755		 £10.93
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026		 £0.39
266 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237		 £0.88
288 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757		 £0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165
343 Part number 2216, Manifold Plug MANIFOLD PLUG
Vokera part no. 2216		 £3.01
353 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824		 £1.60
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958		 £0.98
435 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059		 £11.53
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062		 £2.26
440   AUTOMATIC BY-PASS PLUG
Vokera part no. 10024645		 £4.76
441 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063		 £0.98
442 Part number 10025065, O ring O RING
Vokera part no. 10025065		 £1.91
443 Part number 10025064, O ring O RING
Vokera part no. 10025064		 £5.30
444 Part number 10025066, Washer WASHER
Vokera part no. 10025066		 £3.27
619 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181		 £9.83
