BUDERUS
LOGANO G125-40 SE GB 30009033 - (Installation Materials)
Appliance Code: 30009033

Appliance Diagram


Installation Materials diagram for Buderus Logano G125-40 SE GB 30009033Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  CABLE ENTRY GASKET BE
Worcester part no. 8718585048
£42.06
1 Part number 63002998, O RING 92X3 O RING 92X3
Worcester part no. 63002998
£17.54
2   SMALL PARTS RANGE FOR SE/LE-A
Worcester part no. 5884542
£16.28
3   INSTALLATION MATERIAL SE
Worcester part no. 63030030
£39.99
4 Part number 8718584683, CYLINDER HEAD SCREW DIN7984 M8X25 8.8 A3 CYLINDER HEAD SCREW DIN7984 M8X25 8.8 A3
Worcester part no. 8718584683
£15.19
5   PIN THREADED DIN916 M6X8 (3X)
Worcester part no. 7747029978
£14.60
6 Part number 8718584650, CABLE FEED D 14/4mm CABLE FEED D 14/4MM
Worcester part no. 8718584650
£8.32
7   SCREW PAN HEAD ISO7380 M5X12 (5X)
Worcester part no. 7747029976
£15.20
8 Part number 7747029974, SCREW PAN HEAD ISO7380 M5X20 (5X) SCREW PAN HEAD ISO7380 M5X20 (5X)
Worcester part no. 7747029974
£16.07
9   SCREW PAN HEAD ISO7380 M5X8 (5X)
Worcester part no. 7747029977
£14.61
10   SCREW CHEESE HEAD DIN 7984 M5X45 (5)
Worcester part no. 7747029973
£14.61
11 Part number 5883175, PAN HEAD SCREW DIN7985-M4X50-5.8 PAN HEAD SCREW DIN7985-M4X50-5.8
Worcester part no. 5883175
£0.78
