80IC FSP GB (NOVATHERM) LPG 7713244852 - (Casing)
Appliance Code: 47-311-46

Appliance Diagram


Casing diagram for Worcester 80IC FSP GB (Novatherm) LPG 7713244852Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT SHELL
Worcester part no. 87054212040
2 Part number 87056000030, OBSERVATION WINDOW OBSERVATION WINDOW
Worcester part no. 87056000030
£15.42
3   SHIELD
Worcester part no. 87055064770
£33.93
4   COVER
Worcester part no. 87105061130
£4.67
5   WATER FLOW SELECTOR HANDLE
Worcester part no. 87020001720
£13.80
6   SCREW NO. 10 X 22MM (10X)
Worcester part no. 29106124350
£0.59
7 Part number 87102030390, GROMMET SET GROMMET SET
Worcester part no. 87102030390
£9.51
8   WASHER SET
Worcester part no. 87047010140
£63.37
9   SUPPORT
Worcester part no. 87080060560
£123.28
10   SCREW (10X)
Worcester part no. 87434010190
£0.79
11   HOLDING BRACKET
Worcester part no. 87013020990
£13.12
12 Part number 87034030120, NOW USE 87134030390SCREW M4,8X9,5 (10X) NOW USE 87134030390SCREW M4,8X9,5 (10X)
Worcester part no. 87034030120

12 Part number 87134030390, SCREW 4.8 X 30MM SET OF 3 SCREW 4.8 X 30MM SET OF 3
Worcester part no. 87134030390
£4.61
13   INLET AIR COVER
Worcester part no. 87080060220
£3.36
14   PIPE - EXHAUST UNION
Worcester part no. 87057050040
£50.33
15   CLIP
Worcester part no. 87113010360
£19.69
16   SCREW
Worcester part no. 87134010580
£0.10
17   HOSE
Worcester part no. 87007030690

18   NOW USE 87161165450 EXPANSION VESSEL 8L
Worcester part no. 87054070010

18 Part number 87161165450, EXPANSION VESSEL 8L EXPANSION VESSEL 8L
Worcester part no. 87161165450
£93.04
19   DISTRIBUTOR
Worcester part no. 87057000330
20 Part number 87302039980, WASHER (10X) WASHER (10X)
Worcester part no. 87302039980
£3.36
21 Part number 87185050140, AUTOMATIC PURGER AUTOMATIC PURGER
Worcester part no. 87185050140
£32.54
21 Part number 87185050280, NOW USE 87185050140 Automatic purger NOW USE 87185050140 AUTOMATIC PURGER
Worcester part no. 87185050280

22 Part number 87174010220, SAFETY VALVE SAFETY VALVE
Worcester part no. 87174010220
