IDEAL
ELISE H15 - (Controls)
Appliance Code: 41-399-97

Appliance Diagram


Controls diagram for Ideal Elise H15Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

34 Part number 170928, CONTROLS HINGE KIT ICOS/CLASSIC M CONTROLS HINGE KIT ICOS/CLASSIC M
Ideal part no. 170928
£9.54
35 Part number 175430, USER CONTROL KIT - ELISE H USER CONTROL KIT - ELISE H
Ideal part no. 175430
£27.05
36 Part number 174486, PCB PRIMARY CONTROL KIT PCB PRIMARY CONTROL KIT
Ideal part no. 174486
£201.55
36 Part number 174980, PCB/USER RETRO KIT-HEAT ONLY HE V9 PCB/USER RETRO KIT-HEAT ONLY HE V9
Ideal part no. 174980
£359.21
38 Part number 173535, USER CONTROL HOUSING KIT - ICOS HE USER CONTROL HOUSING KIT - ICOS HE
Ideal part no. 173535
£29.96
39 Part number 173537, MAINS SWITCH KIT MAINS SWITCH KIT
Ideal part no. 173537
£17.21
54 Part number 171021, JUMPER LINK KIT ICOS/ICOS SYSTEM/CLASS M JUMPER LINK KIT ICOS/ICOS SYSTEM/CLASS M
Ideal part no. 171021
£9.63
