IDEAL
HE C28 - (Controls)
Appliance Code: 47-348-36

Appliance Diagram


Controls diagram for Ideal HE C28Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

25 Part number 173884, DOOR DOOR
Ideal part no. 173884		 £13.74
26 Part number 173885, FASCIA FASCIA
Ideal part no. 173885		 £34.11
27 Part number 173886, KNOB POTENTIOMETER KNOB POTENTIOMETER
Ideal part no. 173886
28   PANEL - CONTROLS COVER
Ideal part no. 173887
29   PANEL - CONTROLS SUPPORT
Ideal part no. 173888		 £21.03
30   PANEL - USER WIRING COVER
Ideal part no. 173889		 £6.99
31 Part number 173890, OBSOLETE BOARD - PRIMARY CONTROLS OBSOLETE BOARD - PRIMARY CONTROLS
Ideal part no. 173890
33 Part number 173892, GAUGE - PRESSURE GAUGE - PRESSURE
Ideal part no. 173892
34   LENS - CLEAR
Ideal part no. 173893		 £3.81
35 Part number 173894, BOARD - SECONDARY EXPANSION BOARD - SECONDARY EXPANSION
Ideal part no. 173894		 £46.76
36 Part number 173161, MAINS SWITCH MAINS SWITCH
Ideal part no. 173161		 £5.74
