WORCESTER
15/19-OOO-GB UTILITY 7716100039 - (Heat Exchanger)
Appliance Code: 7716100039

Appliance Diagram


Heat Exchanger diagram for Worcester 15/19-OOO-GB Utility 7716100039Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 87161210870, INSULATION JACKET INSULATION JACKET
Worcester part no. 87161210870		 £31.43
1 Part number 87161213640, PJ15/19-OOO HEAT EXCHANGER SPARE ASSY. PJ15/19-OOO HEAT EXCHANGER SPARE ASSY.
Worcester part no. 87161213640
3 Part number 87161422430, HEAT EXCHANGER BASE INSULATION HEAT EXCHANGER BASE INSULATION
Worcester part no. 87161422430		 £15.94
8 Part number 87161053600, THERMOSTAT POCKET THERMOSTAT POCKET
Worcester part no. 87161053600		 £24.04
9 Part number 87161550470, STEEL SPLIT PIN 45mm X 1.5mm STEEL SPLIT PIN 45MM X 1.5MM
Worcester part no. 87161550470		 £2.95
10 Part number 87161202610, ACCESS LID ASSEMBLY ACCESS LID ASSEMBLY
Worcester part no. 87161202610		 £27.54
11 Part number 87161409030, ROPE-THERMOSEAL TYPE4 13mm DIA ROPE-THERMOSEAL TYPE4 13MM DIA
Worcester part no. 87161409030		 £6.71
12 Part number 29150110100, NUT M10 NUT M10
Worcester part no. 29150110100		 £2.95
13 Part number 29160118960, WASHER M10 WASHER M10
Worcester part no. 29160118960		 £1.99
14 Part number 87161011040, 4" FLUE RING KIT 4" FLUE RING KIT
Worcester part no. 87161011040		 £8.27
15 Part number 87161153060, SCREW (10X) 8X1/2" AFTER FD992 SCREW (10X) 8X1/2" AFTER FD992
Worcester part no. 87161153060		 £3.59
16 Part number 87161482040, NUT CAPTIVE NO:8 NUT CAPTIVE NO:8
Worcester part no. 87161482040		 £4.24
17   NO 8 OPEN CAPTIVE NUT - BRONZE
Worcester part no. 87161405140		 £17.15
18 Part number 87161401170, PLUG 1/8 PLAIN SOLID PLUG 1/8 PLAIN SOLID
Worcester part no. 87161401170		 £3.98
20 Part number 87161011070, FLUE BLANKING PLATE KIT FLUE BLANKING PLATE KIT
Worcester part no. 87161011070		 £8.75
21   GASKET
Worcester part no. 87161407360		 £3.71
22 Part number 29150110060, NUT M5 NUT M5
Worcester part no. 29150110060		 £2.56
23 Part number 29160110120, WASHER M5 FLAT WASHER M5 FLAT
Worcester part no. 29160110120		 £0.75
24 Part number 87161405080, SCREW 1/4 X 5/8 HEX HEAD SET SCREW 1/4 X 5/8 HEX HEAD SET
Worcester part no. 87161405080		 £18.67
25   THERMOPLASTIC RUBBER PLUG
Worcester part no. 87161405110		 £18.89
26 Part number 29160110150, WASHER M8 FORM A MS ZINC PLATE WASHER M8 FORM A MS ZINC PLATE
Worcester part no. 29160110150		 £1.99
27 Part number 87161405100, NUT 1/4" WING CHROME PLATED NUT 1/4" WING CHROME PLATED
Worcester part no. 87161405100		 £19.69
28 Part number 87161409020, GASKET BURNER SEAL GASKET BURNER SEAL
Worcester part no. 87161409020		 £5.26
29 Part number 87161053050, BURNER 15/19 6-WAY ASSEMBLY BURNER 15/19 6-WAY ASSEMBLY
Worcester part no. 87161053050
34 Part number 29100911970, SCREW MACHINE M6X16mm SLOTTED BEFORE FD782 SCREW MACHINE M6X16MM SLOTTED BEFORE FD782
Worcester part no. 29100911970		 £18.96
35 Part number 29100011910, SCREW M6X10mm BZP SLT P/H M/S SCREW M6X10MM BZP SLT P/H M/S
Worcester part no. 29100011910		 £2.00
36   GASKET FLUE RING
Worcester part no. 87161422260		 £3.36
