WORCESTER
LOGAMAX PLUS GB162 45KW - (Heat Exchanger)
Appliance Code: 7746901511

Appliance Diagram


Heat Exchanger diagram for Worcester Logamax Plus GB162 45kWClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 8718600839, Burner housing 35-45kW BURNER HOUSING 35-45KW
Worcester part no. 8718600839
£181.30
3 Part number 8718600207, Burner 35-45kW BURNER 35-45KW
Worcester part no. 8718600207
£345.94
4 Part number 8718600209, Gas-air distributor with sealing 35-45kW GAS-AIR DISTRIBUTOR WITH SEALING 35-45KW
Worcester part no. 8718600209
£57.82
5 Part number 7746900596, Sealing burner/gas/air supply (5x) SEALING BURNER/GAS/AIR SUPPLY (5X)
Worcester part no. 7746900596
£24.95
6 Part number 7101484, SCREW M5X16 (10X) SCREW M5X16 (10X)
Worcester part no. 7101484
£5.75
7 Part number 7101428, NOW USE 873890323 AUTOMATIC AIR VENT NOW USE 873890323 AUTOMATIC AIR VENT
Worcester part no. 7101428

7 Part number 873890323, AUTOMATIC AIR VENT AUTOMATIC AIR VENT
Worcester part no. 873890323
£35.89
8 Part number 7101430, CLIP CLIP
Worcester part no. 7101430
£3.49
9 Part number 73986, SCREW 6,3X19 (10X) SCREW 6,3X19 (10X)
Worcester part no. 73986
£5.89
10 Part number 7736700318, GLOW IGNITOR/ION.ELECTRODE SET 15-45 KW GLOW IGNITOR/ION.ELECTRODE SET 15-45 KW
Worcester part no. 7736700318
£64.22
18 Part number 7098986, O-RING 3,53X29,74 (10X) O-RING 3,53X29,74 (10X)
Worcester part no. 7098986
£17.06
19 Part number 7101370, CLIP CLIP
Worcester part no. 7101370
£8.96
20 Part number 7101534, O-RING 9,19X2,62 (10X) O-RING 9,19X2,62 (10X)
Worcester part no. 7101534
£19.82
21 Part number 7101532, SAFETY SENSOR SAFETY SENSOR
Worcester part no. 7101532
£42.47
22 Part number 7736700368, Heat exchanger 45kW HEAT EXCHANGER 45KW
Worcester part no. 7736700368
£1,465.10
