IDEAL
INDEPENDENT C30 - (Controls)
Appliance Code: 47-348-69

Appliance Diagram


Controls diagram for Ideal Independent C30Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

301 Part number 175626, BOX FIXINGS HINGE & SPRING KIT BOX FIXINGS HINGE & SPRING KIT
Ideal part no. 175626		 £23.20
302 Part number 175933, KIT - BCC COMBI 30 (PRE ZH) KIT - BCC COMBI 30 (PRE ZH)
Ideal part no. 175933		 £25.28
302 Part number 175935, KIT - PRIMARY PCB (AAB ONLY) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM) KIT - PRIMARY PCB (AAB ONLY) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM)
Ideal part no. 175935		 £200.14
302 Part number 176400, KIT - BCC COMBI 30 (ZH ONWARDS) KIT - BCC COMBI 30 (ZH ONWARDS)
Ideal part no. 176400		 £25.28
302 Part number 176592, BCC LOGIC COMBI 30P KIT (LPG) BCC LOGIC COMBI 30P KIT (LPG)
Ideal part no. 176592		 £25.28
302 Part number 177550, PRIMARY PCB KIT I10 (ABK ONWARDS) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM) PRIMARY PCB KIT I10 (ABK ONWARDS) (A BCC CARD MUST BE PURCHASED WITH THIS ITEM)
Ideal part no. 177550		 £206.54
303 Part number 175588, CUI BOARD KIT CUI BOARD KIT
Ideal part no. 175588		 £87.40
306 Part number 175591, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ideal part no. 175591		 £23.26
307 Part number 175592, ELECTRODE - DETECTION ELECTRODE - DETECTION
Ideal part no. 175592		 £16.88
308 Part number 175593, IGNITOR UNIT (PRE ADP) IGNITOR UNIT (PRE ADP)
Ideal part no. 175593		 £35.17
309 Part number 175594, THERMISTOR - NO FLOW THERMISTOR - NO FLOW
Ideal part no. 175594		 £10.81
312 Part number 175597, HARNESS - EARTH HT (PRE ADP) HARNESS - EARTH HT (PRE ADP)
Ideal part no. 175597		 £6.34
313 Part number 175598, IGNITION LEAD IGNITION LEAD
Ideal part no. 175598		 £16.74
314   CONTROL BOX LENS
Ideal part no. 175599		 £19.42
315 Part number 175600, HARNESS - CUI TO PRIMARY (AAO ONWARDS) HARNESS - CUI TO PRIMARY (AAO ONWARDS)
Ideal part no. 175600		 £17.36
317 Part number 175644, HARNESS - MAINS VOLTAGE HARNESS - MAINS VOLTAGE
Ideal part no. 175644		 £48.61
317 Part number 177552, HARNESS MAINS VOLTAGE HARNESS MAINS VOLTAGE
Ideal part no. 177552		 £50.09
317 Part number 177898, HARNESS MAINS ErP COMBI COMBI+ CODE HARNESS MAINS ERP COMBI COMBI+ CODE
Ideal part no. 177898		 £48.52
318 Part number 175602, HARNESS - LOW VOLTAGE HARNESS - LOW VOLTAGE
Ideal part no. 175602		 £37.15
318 Part number 176430, HARNESS LOW VOLTAGE COMBI (ZH ONWARDS) HARNESS LOW VOLTAGE COMBI (ZH ONWARDS)
Ideal part no. 176430		 £36.01
318 Part number 177554, HARNESS SAFETY EXTRA LOW VOLTAGE HARNESS SAFETY EXTRA LOW VOLTAGE
Ideal part no. 177554		 £25.70
318 Part number 177900, HARNESS SELV ErP COMBI & CODE HARNESS SELV ERP COMBI & CODE
Ideal part no. 177900		 £30.60
320 Part number 175604, HARNESS - DETECTION earth lead no longer required HARNESS - DETECTION EARTH LEAD NO LONGER REQUIRED
Ideal part no. 175604		 £14.54
324   CONTROL BOX LID KIT
Ideal part no. 175623		 £29.07
325   CONTROL BOX FRONT
Ideal part no. 175559		 £59.75
325 Part number 175909, CONTROL BOX FRONT KIT INDEPENDENT CONTROL BOX FRONT KIT INDEPENDENT
Ideal part no. 175909		 £64.38
328 Part number 175627, PCB FUSE PCB FUSE
Ideal part no. 175627		 £3.79
330 Part number 175902, MECHANICAL TIMER 24HR MECHANICAL TIMER 24HR
Ideal part no. 175902		 £61.16
331 Part number 175903, HARNESS - MECHANICAL TIMER HARNESS - MECHANICAL TIMER
Ideal part no. 175903		 £7.04
331 Part number 177555, HARNESS OPENTHERM ABK Onwards HARNESS OPENTHERM ABK ONWARDS
Ideal part no. 177555		 £9.06
