IDEAL
LOGIC + SYSTEM 18 - (Boiler Exploded View)
Appliance Code: 41-750-30

Appliance Diagram


Boiler Exploded View diagram for Ideal Logic + System 18Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

104 Part number 175923, CH RETURN VALVE PACK (IND) CH RETURN VALVE PACK (IND)
Ideal part no. 175923		 £26.17
105 Part number 175528, CH FLOW PACK CH FLOW PACK
Ideal part no. 175528		 £40.95
108 Part number 175670, PUMP HEAD KIT (AAC & AAB ONLY) PUMP HEAD KIT (AAC & AAB ONLY)
Ideal part no. 175670		 £211.22
108 Part number 176455, NOW USE 182357 PUMP HEAD KIT - GRUNDFOS 59200322 (ABS & ABY ONWARDS) NOW USE 182357 PUMP HEAD KIT - GRUNDFOS 59200322 (ABS & ABY ONWARDS)
Ideal part no. 176455
108 Part number 177925, PUMP HEAD KIT ErP 98927074 ( ACQ ONWARDS - 2015 ERP) PUMP HEAD KIT ERP 98927074 ( ACQ ONWARDS - 2015 ERP)
Ideal part no. 177925		 £285.72
108   PUMP HEAD KIT
Ideal part no. 182357		 £204.87
110 Part number 175804, KIT-AUTO AIR VENT WITH O RING 12.0113 (PRE ABY) KIT-AUTO AIR VENT WITH O RING 12.0113 (PRE ABY)
Ideal part no. 175804		 £48.00
110 Part number 176457, AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS) AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS)
Ideal part no. 176457		 £44.94
113 Part number 175413, PRESSURE RELIEF VALVE KIT (AAC & AAB ONLY) PRESSURE RELIEF VALVE KIT (AAC & AAB ONLY)
Ideal part no. 175413		 £16.43
113 Part number 176610, PRV KIT (ABS & ABY ONWARDS) PRV KIT (ABS & ABY ONWARDS)
Ideal part no. 176610		 £41.91
114 Part number 175545, PIPE - PRV OUTLET (AAC & AAB ONLY) PIPE - PRV OUTLET (AAC & AAB ONLY)
Ideal part no. 175545		 £18.16
114 Part number 177536, PIPE PRV OUTLET (ABS & ABY ONWARDS) PIPE PRV OUTLET (ABS & ABY ONWARDS)
Ideal part no. 177536		 £19.30
115 Part number 175546, PIPE - FLOW (AAC & AAB ONLY) PIPE - FLOW (AAC & AAB ONLY)
Ideal part no. 175546		 £41.98
115 Part number 175704, NOW USE 175546 PIPE - FLOW NOW USE 175546 PIPE - FLOW
Ideal part no. 175704
115 Part number 177537, PIPE FLOW (ABS & ABY ONWARDS) PIPE FLOW (ABS & ABY ONWARDS)
Ideal part no. 177537		 £33.72
116 Part number 175547, PIPE - RETURN (AAC & AAB ONLY) PIPE - RETURN (AAC & AAB ONLY)
Ideal part no. 175547		 £30.07
116 Part number 175705, NOW USE 175550 PIPE - RETURN NOW USE 175550 PIPE - RETURN
Ideal part no. 175705
116   PIPE RETURN ( ABS & ABY ONWARDS)
Ideal part no. 177538		 £34.50
117 Part number 175550, PIPE - EXPANSION VESSEL PIPE - EXPANSION VESSEL
Ideal part no. 175550		 £37.65
117   PIPE - EXPANSION VESSEL KIT
Ideal part no. 176000		 £29.95
117 Part number 176041, NOW USE 175550 PIPE - EXPANSION VESSEL KIT NOW USE 175550 PIPE - EXPANSION VESSEL KIT
Ideal part no. 176041
117 Part number 177539, HOSE EXPANSION VESSEL KIT (ABS & ABY ONWARDS) HOSE EXPANSION VESSEL KIT (ABS & ABY ONWARDS)
Ideal part no. 177539		 £33.83
118 Part number 176001, EXPANSION VESSEL KIT (AAC & AAB ONLY) EXPANSION VESSEL KIT (AAC & AAB ONLY)
Ideal part no. 176001		 £93.15
118 Part number 177540, EXPANSION VESSEL KIT (ABS & ABY ONWARDS) EXPANSION VESSEL KIT (ABS & ABY ONWARDS)
Ideal part no. 177540		 £103.92
120 Part number 175992, FLOW GROUP KIT LOGIC SYSTEM (AAB ONLY) FLOW GROUP KIT LOGIC SYSTEM (AAB ONLY)
Ideal part no. 175992		 £96.39
120   FLOW GROUP KIT (ABY ONWARDS)
Ideal part no. 177716		 £92.75
121   BY-PASS PIPE KIT (AAB ONLY)
Ideal part no. 176003		 £77.24
121 Part number 177715, BY PASS KIT 99104550 (ABS ONWARDS) BY PASS KIT 99104550 (ABS ONWARDS)
Ideal part no. 177715		 £65.50
131 Part number 175596, WATER PRESSURE TRANSDUCER (PRE ABU) WATER PRESSURE TRANSDUCER (PRE ABU)
Ideal part no. 175596		 £31.32
131 Part number 176480, WATER PRESSURE SWITCH-GRUNDFOS 59200312 (ABU ONWARDS) WATER PRESSURE SWITCH-GRUNDFOS 59200312 (ABU ONWARDS)
Ideal part no. 176480		 £41.27
135 Part number 175679, PRESSURE GAUGE KIT PRESSURE GAUGE KIT
Ideal part no. 175679		 £19.92
136 Part number 175703, PIPE - PRV Drain pipe - external PIPE - PRV DRAIN PIPE - EXTERNAL
Ideal part no. 175703		 £36.65
203 Part number 175526, GAS COCK VALVE PACK GAS COCK VALVE PACK
Ideal part no. 175526		 £20.23
204 Part number 175561, PIPE - GAS INLET (AAV & AAB ONLY) PIPE - GAS INLET (AAV & AAB ONLY)
Ideal part no. 175561		 £22.05
204 Part number 175710, NOW USE 175561 PIPE - GAS INLET NOW USE 175561 PIPE - GAS INLET
Ideal part no. 175710
204 Part number 177543, PIPE GAS INLET (ABS & ABY ONWARDS) PIPE GAS INLET (ABS & ABY ONWARDS)
Ideal part no. 177543		 £29.63
205 Part number 175562, GAS VALVE KIT (PRE ABS) GAS VALVE KIT (PRE ABS)
Ideal part no. 175562		 £203.49
205 Part number 176590, GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET) GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET)
Ideal part no. 176590		 £149.94
205 Part number 177544, GAS VALVE KIT (ABS & ABY ONWARDS) GAS VALVE KIT (ABS & ABY ONWARDS)
Ideal part no. 177544		 £114.65
205 Part number 177582, GAS VALVE KIT (LPG) (ABK ONWARDS) GAS VALVE KIT (LPG) (ABK ONWARDS)
Ideal part no. 177582		 £135.14
206 Part number 175563, PIPE - GAS INJECTOR (AAC & AAB ONLY) PIPE - GAS INJECTOR (AAC & AAB ONLY)
Ideal part no. 175563		 £15.75
206 Part number 175711, NOW USE 175563 PIPE - GAS INJECTOR NOW USE 175563 PIPE - GAS INJECTOR
Ideal part no. 175711
206 Part number 177545, PIPE GAS INJECTOR (ABS & ABY ONWARDS) PIPE GAS INJECTOR (ABS & ABY ONWARDS)
Ideal part no. 177545		 £18.42
211 Part number 175566, INJECTOR ASSEMBLY KIT 24KW INJECTOR ASSEMBLY KIT 24KW
Ideal part no. 175566		 £30.63
211 Part number 175613, INJECTOR ASSEMBLY KIT 30KW (AAC ONLY) INJECTOR ASSEMBLY KIT 30KW (AAC ONLY)
Ideal part no. 175613		 £30.47
211 Part number 176591, INJECTOR & HOUSING KIT (LPG) INJECTOR & HOUSING KIT (LPG)
Ideal part no. 176591		 £31.48
211 Part number 177546, INJECTOR ASSEMBLY KIT 24KW INJECTOR ASSEMBLY KIT 24KW
Ideal part no. 177546		 £31.82
211 Part number 177547, INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS) INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS)
Ideal part no. 177547		 £31.07
214 Part number 175567, VENTURI VENTURI
Ideal part no. 175567		 £25.49
215 Part number 175569, FAN KIT FAN KIT
Ideal part no. 175569		 £166.14
217 Part number 175571, BURNER KIT BURNER KIT
Ideal part no. 175571		 £109.53
218 Part number 175572, GASKET - BURNER GASKET - BURNER
Ideal part no. 175572		 £20.59
223 Part number 175576, FLUE MANIFOLD FLUE MANIFOLD
Ideal part no. 175576		 £39.29
224 Part number 175578, FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ) FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175578		 £41.38
224 Part number 176986, FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 176986		 £43.46
227 Part number 175581, CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ) CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175581		 £8.37
227 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983		 £7.10
228 Part number 175582, HOSE - CONDENSATE INTERNAL HOSE - CONDENSATE INTERNAL
Ideal part no. 175582		 £9.51
229 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23.10
230 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23.10
230 Part number 175584, OBSOLETE SIPHON TRAP CAP AND SEAL OBSOLETE SIPHON TRAP CAP AND SEAL
Ideal part no. 175584
231 Part number 175586, CONDENSATE OUTLET CONNECTION CONDENSATE OUTLET CONNECTION
Ideal part no. 175586		 £7.74
233 Part number 175640, FLUE SENSING NIPPLE KIT FLUE SENSING NIPPLE KIT
Ideal part no. 175640		 £27.87
301 Part number 175626, BOX FIXINGS HINGE & SPRING KIT BOX FIXINGS HINGE & SPRING KIT
Ideal part no. 175626		 £23.20
303 Part number 175978, CUI BOARD KIT 2 POTENTIOMETER CUI BOARD KIT 2 POTENTIOMETER
Ideal part no. 175978		 £104.03
304 Part number 175589, CONTROL THERMISTOR (FLOW/RETURN) pack of 2- Withdrawn : 16/01/2017 CONTROL THERMISTOR (FLOW/RETURN) PACK OF 2- WITHDRAWN : 16/01/2017
Ideal part no. 175589
304 Part number 176432, CONTROL THERMISTOR CONTROL THERMISTOR
Ideal part no. 176432		 £10.53
306 Part number 175591, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ideal part no. 175591		 £23.26
307 Part number 175592, ELECTRODE - DETECTION ELECTRODE - DETECTION
Ideal part no. 175592		 £16.88
308 Part number 175593, IGNITOR UNIT (PRE ADP) IGNITOR UNIT (PRE ADP)
Ideal part no. 175593		 £35.17
309 Part number 175594, THERMISTOR - NO FLOW THERMISTOR - NO FLOW
Ideal part no. 175594		 £10.81
313 Part number 175598, IGNITION LEAD IGNITION LEAD
Ideal part no. 175598		 £16.74
314   CONTROL BOX LENS
Ideal part no. 175599		 £19.42
324   CONTROL BOX LID KIT
Ideal part no. 175623		 £29.07
325   CONTROL BOX FRONT KIT
Ideal part no. 176027		 £45.13
401 Part number 175615, HEAT ENGINE KIT (AAC & AAB ONLY) HEAT ENGINE KIT (AAC & AAB ONLY)
Ideal part no. 175615		 £391.16
401 Part number 177566, HEAT ENGINE KIT (ABS & ABY ONWARDS) HEAT ENGINE KIT (ABS & ABY ONWARDS)
Ideal part no. 177566		 £416.91
503 Part number 175619, WALL MOUNTING BRACKET KIT WALL MOUNTING BRACKET KIT
Ideal part no. 175619		 £15.48
504   FRONT PANEL KIT LOGIC SYSTEM
Ideal part no. 176002		 £173.17
504   FRONT PANEL KIT LOGIC PLUS SYSTEM
Ideal part no. 176042		 £157.74
504   FRONT PANEL ASSEMBLY SYSTEM
Ideal part no. 177724		 £181.84
505   FASCIA KIT
Ideal part no. 176031		 £18.04
505   FASCIA KIT HEAT/SYSTEM
Ideal part no. 177757		 £18.12
506   BRACKET - GAS VALVE KIT (AAC & AAB ONLY)
Ideal part no. 175630		 £20.31
506   BRACKET GAS VALVE KIT (ABS & ABY ONWARDS)
Ideal part no. 177569		 £19.95
507   BRACKET - EXPANSION VESSEL
Ideal part no. 175631		 £19.55
