REMEHA-COMMERCIAL
W40/60M ECO - (Exploded View)
Appliance Code: W40/60ECO

Appliance Diagram


Exploded View diagram for Remeha-Commercial W40/60m EcoClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   CABLE FLAT PRINT DISPLAY/PRINT INTERFACE
Remeha-Commercial part no. 51690
£32.69
0 Part number S49297, Flue gas temp. sensor NTC 12kohm 3% (blue dot-Eco boiler) FLUE GAS TEMP. SENSOR NTC 12KOHM 3% (BLUE DOT-ECO BOILER)
Remeha-Commercial part no. S49297
£31.23
0 Part number S56961, Cable set for fan and sensors (X16 - X2) CABLE SET FOR FAN AND SENSORS (X16 - X2)
Remeha-Commercial part no. S56961
£49.96
1 Part number 41671, (USE S41671)Sealing ring D=100mm for fluegas (USE S41671)SEALING RING D=100MM FOR FLUEGAS
Remeha-Broag part no. 41671

1 Part number S41671, Sealing Spigot D (100mm D:) SEALING SPIGOT D (100MM D:)
Remeha-Commercial part no. S41671
£17.74
4 Part number S45174, Valve multi block VR8615VA1012B VALVE MULTI BLOCK VR8615VA1012B
Remeha-Commercial part no. S45174
£346.31
5   FAN CONNECTION 60KW
Remeha-Commercial part no. 51942
£17.74
5 Part number S103212, Fan assembly EBM G1G 126 AC 13 Q30/W40/Selecta c/w X21 connector FAN ASSEMBLY EBM G1G 126 AC 13 Q30/W40/SELECTA C/W X21 CONNECTOR
Remeha-Commercial part no. S103212
£245.55
5 Part number S44644, Fan 60kW EBM G1G 144 FAN 60KW EBM G1G 144
Remeha-Commercial part no. S44644

5 Part number S54878, NOW USE S103212 Fan assembly EBM G1G 126 AC 13 Q30/W40/Selecta c/w X21 connector NOW USE S103212 FAN ASSEMBLY EBM G1G 126 AC 13 Q30/W40/SELECTA C/W X21 CONNECTOR
Remeha-Broag part no. S54878

6 Part number S45182, Gasket for flue fan (10 pcs.) GASKET FOR FLUE FAN (10 PCS.)
Remeha-Commercial part no. S45182
£24.33
7 Part number S45895, O-Ring 73x1.8mm (10 pcs) O-RING 73X1.8MM (10 PCS)
Remeha-Commercial part no. S45895
£35.49
8 Part number 44655, (USE S44655) Burner assembly 60kW (USE S44655) BURNER ASSEMBLY 60KW
Remeha-Broag part no. 44655

8 Part number S44655, Burner assembly 60kW BURNER ASSEMBLY 60KW
Remeha-Commercial part no. S44655
£2,913.90
8 Part number S46745, Sealing cord burner deck 40kW SEALING CORD BURNER DECK 40KW
Remeha-Commercial part no. S46745

8 Part number S46746, Seal burner deck cord (2 pieces) 60kW SEAL BURNER DECK CORD (2 PIECES) 60KW
Remeha-Commercial part no. S46746
£75.23
8 Part number S51485, Burner assembly 40kW (not 1:9) BURNER ASSEMBLY 40KW (NOT 1:9)
Remeha-Commercial part no. S51485
£1,870.95
9 Part number S46199, Burner Deck 60kW BURNER DECK 60KW
Remeha-Commercial part no. S46199
£615.99
9 Part number S51503, Burner deck 40kW (not 1:9) BURNER DECK 40KW (NOT 1:9)
Remeha-Commercial part no. S51503
£722.44
10 Part number S41601, Air vent 1/8" AIR VENT 1/8"
Remeha-Commercial part no. S41601
£54.35
11 Part number S37628, NEW PART NUMBER S62728 Vent auto air bleed device 3/8" for W40/60, Quinta, Gas6, Gas2000/3000, Selecta NEW PART NUMBER S62728 VENT AUTO AIR BLEED DEVICE 3/8" FOR W40/60, QUINTA, GAS6, GAS2000/3000, SELECTA
Remeha-Broag part no. S37628

11 Part number S62728, Auto Air Vent bleed device 3/8" AUTO AIR VENT BLEED DEVICE 3/8"
Remeha-Commercial part no. S62728
£44.14
12 Part number S56867, Heat Exchanger 40KW (Includes ALL seals and Insp Plate) HEAT EXCHANGER 40KW (INCLUDES ALL SEALS AND INSP PLATE)
Remeha-Commercial part no. S56867
£3,332.00
12 Part number S56868, Heat exchanger 60kW HEAT EXCHANGER 60KW
Remeha-Commercial part no. S56868
£3,603.59
13 Part number S44698, Temperature Sensor (flow And return) Elmwood NTC 12K/007 TEMPERATURE SENSOR (FLOW AND RETURN) ELMWOOD NTC 12K/007
Remeha-Commercial part no. S44698
£38.33
14 Part number S55807, Cable ignition c/w cap CABLE IGNITION C/W CAP
Remeha-Commercial part no. S55807

15 Part number S30153, Cap brown ionisation CAP BROWN IONISATION
Remeha-Commercial part no. S30153
£24.13
16 Part number S45004, Glass inspection c/w gasket 32x32x3mm and screws GLASS INSPECTION C/W GASKET 32X32X3MM AND SCREWS
Remeha-Commercial part no. S45004
£48.55
17 Part number S54338, W40/60 series Electrode Ignition/Ionisation crni inc Gasket W40/60 SERIES ELECTRODE IGNITION/IONISATION CRNI INC GASKET
Remeha-Commercial part no. S54338
£38.33
18 Part number S41676, Seal black cord 12mm. (lower inspection hatch) SEAL BLACK CORD 12MM. (LOWER INSPECTION HATCH)
Remeha-Commercial part no. S41676
£13.54
19 Part number S52061, Control unit mcba 1460d m CONTROL UNIT MCBA 1460D M
Remeha-Commercial part no. S52061
£599.76
20 Part number S42754, PCB display PCB DISPLAY
Remeha-Commercial part no. S42754
£98.07
21 Part number S51103, Sealing Ring 44 x 32 x 4 Pack of 5 SEALING RING 44 X 32 X 4 PACK OF 5
Remeha-Commercial part no. S51103
£5.94
21 Part number S6710, Gasket 044x032x2mm (pump union) GASKET 044X032X2MM (PUMP UNION)
Remeha-Commercial part no. S6710
£12.86
23   SYPHON ELBOW 90 DEGR. 32X1,9
Remeha-Commercial part no. 30537
£4.20
23 Part number 45885, (REPLACED BY S45885) Syphon assembly (REPLACED BY S45885) SYPHON ASSEMBLY
Remeha-Broag part no. 45885

23 Part number S45885, Syphon Assembly - W40/60 SYPHON ASSEMBLY - W40/60
Remeha-Commercial part no. S45885
£92.69
24 Part number S43561, Fuses glass 2 Amp Slow Pack of 10 FUSES GLASS 2 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43561
£31.23
24 Part number S43562, Fuses glass 3.15 Amp Slow Pack of 10 FUSES GLASS 3.15 AMP SLOW PACK OF 10
Remeha-Commercial part no. S43562
£42.71
24 Part number S43563, Fuses glass 2 Amp fast Pack of 10 FUSES GLASS 2 AMP FAST PACK OF 10
Remeha-Commercial part no. S43563
£22.71
25 Part number S53282, Switch On/Off 40c1350al with cap SWITCH ON/OFF 40C1350AL WITH CAP
Remeha-Commercial part no. S53282
£28.39
26   PUMP CABLE ASSEMBLY L=450
Remeha-Commercial part no. 37753
£15.72
27 Part number 33232, OBSOLETE Drain cock -¢" OBSOLETE DRAIN COCK -¢"
Remeha-Broag part no. 33232

28 Part number 47175, Pressure gauge -+" (USE S47175) PRESSURE GAUGE -+" (USE S47175)
Remeha-Broag part no. 47175

28 Part number S47175, Pressure gauge -+" PRESSURE GAUGE -+"
Remeha-Commercial part no. S47175
£33.95
29 Part number S51836, Inspection Plate 40KW INSPECTION PLATE 40KW
Remeha-Commercial part no. S51836
£152.14
29 Part number S51836, Inspection Plate 40KW INSPECTION PLATE 40KW
Remeha-Commercial part no. S51836
£152.14
29 Part number S51837, Inspection plate 60kW - Support S55990 & Seal S53145 also req INSPECTION PLATE 60KW - SUPPORT S55990 & SEAL S53145 ALSO REQ
Remeha-Commercial part no. S51837
£194.45
30 Part number S53144, Seal for inspection hatch 40kw SEAL FOR INSPECTION HATCH 40KW
Remeha-Commercial part no. S53144
£44.14
30 Part number S53145, Seal for inspection hatch 60kw SEAL FOR INSPECTION HATCH 60KW
Remeha-Commercial part no. S53145
£47.13
31   CASING RIGHT SIDE
Remeha-Commercial part no. 51610
£59.10
32   CASING LEFT SIDE
Remeha-Commercial part no. 51612
£61.61
33   CASING FRONT 40KW
Remeha-Commercial part no. 50812
£124.99
33   CASING FRONT 60KW
Remeha-Commercial part no. 50813
£144.60
34   SLEEVE FRONT CASING
Remeha-Commercial part no. 50811
£8.99
35 Part number S45874, Gasket for injector (10 pcs) GASKET FOR INJECTOR (10 PCS)
Remeha-Commercial part no. S45874
£20.58
36 Part number S54540, Valve Flap gas/air 40kW (Spring Loaded Damper W40M ECO only) VALVE FLAP GAS/AIR 40KW (SPRING LOADED DAMPER W40M ECO ONLY)
Remeha-Commercial part no. S54540
£167.48
36 Part number S54541, Valve Flap gas/air 60kW (Spring Loaded Damper W60 M Eco only) VALVE FLAP GAS/AIR 60KW (SPRING LOADED DAMPER W60 M ECO ONLY)
Remeha-Commercial part no. S54541
£146.19
38 Part number S51874, Transformer 230v/26v 45va (W60) TRANSFORMER 230V/26V 45VA (W60)
Remeha-Commercial part no. S51874
£303.74
40   SWITCH
Remeha-Commercial part no. 50669
£7.05
41   CABLE 14 WIRED L=200 (BOILER PUMP)
Remeha-Commercial part no. 42700
£15.72
