GLOWWORM
ULTRACOM 2 35 STORE 2011 2015 - (07 Electronics)
Appliance Code: 47-019-15

Appliance Diagram


07 Electronics diagram for Glowworm Ultracom 2 35 Store 2011 2015Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   SCREW - IGN FLAME ELEC (PK50)
Glowworm part no. 2000801960		 £5.13
1 Part number S5490600, Screw (pk50) SCREW (PK50)
Glowworm part no. S5490600		 £14.38
2 Part number A000035144, ignition transformer IGNITION TRANSFORMER
Glowworm part no. A000035144		 £38.23
3 Part number 0020125458, CABLE ELECTRONICS CABLE ELECTRONICS
Glowworm part no. 0020125458		 £4.17
4 Part number 0020105963, Button RESET BUTTON RESET
Glowworm part no. 0020105963		 £6.61
4 Part number 0020125461, NOW USE 0020105963 BUTTON RESET NOW USE 0020105963 BUTTON RESET
Glowworm part no. 0020125461
5 Part number 0020105922, Instrument panel INSTRUMENT PANEL
Glowworm part no. 0020105922		 £33.57
5 Part number 0020125430, NOW USE 0020105922 INSTRUMENT PANEL NOW USE 0020105922 INSTRUMENT PANEL
Glowworm part no. 0020125430
6 Part number 0020084490, Electrical conduit (x5) ELECTRICAL CONDUIT (X5)
Glowworm part no. 0020084490		 £6.61
6   CABLE SUPPORT
Glowworm part no. 801686		 £3.61
7 Part number 0020097304, Plug 6 wires (PK5) PLUG 6 WIRES (PK5)
Glowworm part no. 0020097304		 £30.99
8 Part number 0020097302, Plug 2 wires (PK5) PLUG 2 WIRES (PK5)
Glowworm part no. 0020097302		 £9.70
9 Part number 0020125460, Power cable with ON/OFF switch POWER CABLE WITH ON/OFF SWITCH
Glowworm part no. 0020125460		 £18.45
10 Part number 0020097250, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097250		 £6.39
11 Part number 0020105960, Button ON/OFF BUTTON ON/OFF
Glowworm part no. 0020105960		 £6.61
11 Part number 0020125462, NOW USE 0020105960 BUTTON ON/ OFF NOW USE 0020105960 BUTTON ON/ OFF
Glowworm part no. 0020125462
12 Part number 0020105958, Display DISPLAY
Glowworm part no. 0020105958		 £61.79
13 Part number 0020105933, HARNESS HARNESS
Glowworm part no. 0020105933		 £59.28
14 Part number 0020125459, NOW USE 0020255376 Electronics NOW USE 0020255376 ELECTRONICS
Glowworm part no. 0020125459
14   PCB
Glowworm part no. 0020255376		 £165.38
15 Part number 2000801935, NOW USE S5739800 ntc with clip d=18mm 10kOhm NOW USE S5739800 NTC WITH CLIP D=18MM 10KOHM
Glowworm part no. 2000801935
15 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
16 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.09
17   CONTROL BOX
Glowworm part no. 0020125463		 £21.59
18 Part number 0020097303, Plug 5 wires PLUG 5 WIRES
Glowworm part no. 0020097303		 £6.61
