GLOWWORM
MICRON 50FF EARLY - (10A Hydraulics)
Appliance Code: 41-047-48

Appliance Diagram


10A Hydraulics diagram for Glowworm Micron 50FF EarlyClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

19 Part number SK8112, Nut - spire capt no8 NUT - SPIRE CAPT NO8
Glowworm part no. SK8112

33 Part number 2000802764, Screw (PK2) SCREW (PK2)
Glowworm part no. 2000802764
£6.61
33   NOW USE 2000802764 SCREW-NO.8 X 1/2 REC
Glowworm part no. S208393

50 Part number S212128, Washer sealing 15X7X2mm WASHER SEALING 15X7X2MM
Glowworm part no. S212128

121 Part number 0020020744, expansion vessel EXPANSION VESSEL
Glowworm part no. 0020020744
£102.11
121   NOW USE 0020020744 EXP VESSEL MICRON SS KIT 30/60
Glowworm part no. 2000801312

121 Part number 801666, NOW USE 0020020744 EXPANSION VESSEL 8 LT NOW USE 0020020744 EXPANSION VESSEL 8 LT
Glowworm part no. 801666

122   OUTER CASE
Glowworm part no. 2000458257

122   NOW USE 2000458257 OUTER CASE MICRON SS KIT 30/60
Glowworm part no. 2000801313

123   REAR SURR SIDE MICSS KIT
Glowworm part no. 2000801314

124   STRIKER
Glowworm part no. 2000801315

125   LATCH
Glowworm part no. S801316

127   SCREW ( NO.10 X 1 1/2 )
Glowworm part no. S208225

128   SCREW - NO 6 X 5/16
Glowworm part no. SFF0653

129   WASHER
Glowworm part no. SK6297

130   OBSOLETE P.V.SUPP BRKT MIC SS KIT 30/60
Glowworm part no. 2000801317

131   RETURN PIPE
Glowworm part no. 2000801318
£16.65
132   FLOW PIPE
Glowworm part no. 801319

133   FLOW PIPE (PUMP)
Glowworm part no. 2000801320

134 Part number S212143, Washer 18x15x2mm WASHER 18X15X2MM
Glowworm part no. S212143

143   OBSOLETE WALL FRAME MICRON SS KIT 30/60
Glowworm part no. 2000801322

144   SPACE BRACKET
Glowworm part no. 2000801323

146 Part number S212253, Washer hose sealing 1.5mm WASHER HOSE SEALING 1.5MM
Glowworm part no. S212253
