VAILLANT
ECOTEC PRO 28 VUW 286/3-3 R2 2008-2012 - (08a Connection Parts R2)
Appliance Code: 47-044-30 R2

Appliance Diagram


08a Connection Parts R2 diagram for Vaillant Ecotec Pro 28 VUW 286/3-3 R2 2008-2012Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   PRICE ON APPLICATION
Vaillant part no. 0000
2 Part number 193537, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 193537		 £9.48
3 Part number 103415, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 103415		 £7.67
4 Part number 103417, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 103417		 £9.86
5 Part number 178992, Clip, (PK10) CLIP, (PK10)
Vaillant part no. 178992		 £8.18
6   PRICE ON APPLICATION
Vaillant part no. 0000
7 Part number 193539, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 193539		 £16.67
8   PRICE ON APPLICATION
Vaillant part no. 0000
9 Part number 178993, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 178993		 £6.69
10 Part number 981149, Sealing ring, (PK10) SEALING RING, (PK10)
Vaillant part no. 981149		 £7.96
11 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694		 £7.03
12 Part number 181051, Expansion vessel 10 ltr. EXPANSION VESSEL 10 LTR.
Vaillant part no. 181051		 £135.15
13 Part number 193592, Sensor NTC (CH flow/CH return) SENSOR NTC (CH FLOW/CH RETURN)
Vaillant part no. 193592		 £9.67
14 Part number 193586, Harness HARNESS
Vaillant part no. 193586		 £29.00
15 Part number 180982, pressure Gauge PRESSURE GAUGE
Vaillant part no. 180982		 £17.94
16 Part number 981155, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981155		 £6.34
17 Part number 0020107709, Support SUPPORT
Vaillant part no. 0020107709		 £6.66
17 Part number 085751, NOW USE 0020107709 pressure gauge clip NOW USE 0020107709 PRESSURE GAUGE CLIP
Vaillant part no. 085751
19 Part number 0020025045, Connection tube CONNECTION TUBE
Vaillant part no. 0020025045		 £18.54
21 Part number 178983, NOW USE 0010030632 Pump NOW USE 0010030632 PUMP
Vaillant part no. 178983
21   PUMP, HIGH-EFFICIENCY (IF THIS IS THE REPLACEMENT PART THEN PART NUMBER 0010030691 - CABLE IS ALSO REQUIRED)
Vaillant part no. 0010030632		 £238.62
22 Part number 0020068956, Connection tube, (kit) CONNECTION TUBE, (KIT)
Vaillant part no. 0020068956		 £51.50
23   PRICE ON APPLICATION
Vaillant part no. 0000
23A Part number 0020068958, Connection tube CONNECTION TUBE
Vaillant part no. 0020068958		 £57.11
24 Part number 0020087657, ADAPTER ADAPTER
Vaillant part no. 0020087657		 £12.58
25 Part number 0020059717, sensor (water pressure) SENSOR (WATER PRESSURE)
Vaillant part no. 0020059717		 £25.74
25A   PRICE ON APPLICATION
Vaillant part no. 0000
