VAILLANT
MAG CAR 11-2/0 2006-2007 - (07B Casing Parts)
Appliance Code: 11-2/0

Appliance Diagram


07B Casing Parts diagram for Vaillant Mag Car 11-2/0 2006-2007Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 108567, Support SUPPORT
Vaillant part no. 108567		 £6.71
1 Part number 108535, Front panel FRONT PANEL
Vaillant part no. 108535		 £135.11
2 Part number 108536, Side panel, right SIDE PANEL, RIGHT
Vaillant part no. 108536		 £41.18
2   SIDE PANEL, LEFT
Vaillant part no. 108541		 £100.17
3 Part number 108533, Covering plate COVERING PLATE
Vaillant part no. 108533		 £44.36
4 Part number 078543, Knob KNOB
Vaillant part no. 078543		 £22.48
5 Part number 108550, Inspection glass INSPECTION GLASS
Vaillant part no. 108550		 £6.71
6 Part number 108559, Sealing SEALING
Vaillant part no. 108559		 £6.71
7   GASKET
Vaillant part no. 108573		 £6.71
8 Part number 108572, Front panel, burner chamber FRONT PANEL, BURNER CHAMBER
Vaillant part no. 108572		 £53.06
9   GASKET (PK3)
Vaillant part no. 108551		 £6.71
10 Part number 0020073877, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020073877		 £6.71
11   PLUG (PK2)
Vaillant part no. 108630		 £6.71
