VAILLANT
MAG 275/9 XW 1994-1997 - (01 Gas Water Section)
Appliance Code: 275/9 XW

Appliance Diagram


01 Gas Water Section diagram for Vaillant Mag 275/9 XW 1994-1997Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   PRICE ON APPLICATION
Vaillant part no. 0000
2   PRICE ON APPLICATION
Vaillant part no. 0000
3 Part number 195044, OBSOLETE magneto housing OBSOLETE MAGNETO HOUSING
Vaillant part no. 195044
4 Part number 170327, magneto MAGNETO
Vaillant part no. 170327		 £15,31
5 Part number 982310, O-ring O-RING
Vaillant part no. 982310
6   OBSOLETE PACKING RING
Vaillant part no. 980916
7   OBSOLETE PILOT GAS HOUSING
Vaillant part no. 043407
8   OBSOLETE PACKING RING
Vaillant part no. 981624
9 Part number 091074, piezo ignition PIEZO IGNITION
Vaillant part no. 091074		 £31,92
10 Part number 082460, OBSOLETE flange OBSOLETE FLANGE
Vaillant part no. 082460
11 Part number 982319, O-ring O-RING
Vaillant part no. 982319		 £5,13
12 Part number 118936, Cheese head screw KS/S CHEESE HEAD SCREW KS/S
Vaillant part no. 118936		 £5,13
14 Part number 292211, binding ring BINDING RING
Vaillant part no. 292211		 £12,81
15 Part number 105812, cylinder screw CYLINDER SCREW
Vaillant part no. 105812		 £3,91
16 Part number 010347, Diaphragm DIAPHRAGM
Vaillant part no. 010347
17 Part number 0020028121, Water Filter WATER FILTER
Vaillant part no. 0020028121
18 Part number 012854, venturi VENTURI
Vaillant part no. 012854		 £5,13
19 Part number 012546, temperature selector TEMPERATURE SELECTOR
Vaillant part no. 012546		 £11,10
20 Part number 981175, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981175
21 Part number 981159, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981159		 £6,86
22 Part number 010050, screw SCREW
Vaillant part no. 010050		 £6,86
23 Part number 012946, Water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 012946		 £6,86
24 Part number 981163, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981163		 £7,24
25 Part number 203030, piston (yellow) PISTON (YELLOW)
Vaillant part no. 203030		 £6,86
26 Part number 982484, O-ring O-RING
Vaillant part no. 982484
28 Part number 013512, water valve - lower part WATER VALVE - LOWER PART
Vaillant part no. 013512		 £22,31
29 Part number 060036, spring lock washer SPRING LOCK WASHER
Vaillant part no. 060036		 £3,91
30 Part number 0020107732, BUTTON (KNOB) BUTTON (KNOB)
Vaillant part no. 0020107732		 £3,91
31 Part number 981141, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981141		 £6,86
32 Part number 981143, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981143		 £6,86
33 Part number 115507, Retaining washer RETAINING WASHER
Vaillant part no. 115507		 £3,91
34 Part number 213448, lever LEVER
Vaillant part no. 213448		 £3,91
35   OBSOLETE BUSH
Vaillant part no. 124889
36   OBSOLETE SCREW
Vaillant part no. 133924
39 Part number 215604, gas block / top housing GAS BLOCK / TOP HOUSING
Vaillant part no. 215604		 £35,90
40 Part number 183566, OBSOLETE throttle guide OBSOLETE THROTTLE GUIDE
Vaillant part no. 183566
42 Part number 107831, pin PIN
Vaillant part no. 107831		 £29,34
43 Part number 104289, OBSOLETE spring OBSOLETE SPRING
Vaillant part no. 104289
51   STUFFING BOX
Vaillant part no. 012149		 £8,96
52 Part number 105740, cylinder screw CYLINDER SCREW
Vaillant part no. 105740
