VAILLANT
TURBOMAX PRO 24E VUW 242/2-3 R3 2004-2008 - (12 Control Box R3)
Appliance Code: 47-044-10-R3

Appliance Diagram


12 Control Box R3 diagram for Vaillant Turbomax Pro 24E VUW 242/2-3 R3 2004-2008Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 136894, front cover (grey) FRONT COVER (GREY)
Vaillant part no. 136894
£94.40
1A Part number 136894, front cover (grey) FRONT COVER (GREY)
Vaillant part no. 136894
£94.40
2 Part number 088734, lock LOCK
Vaillant part no. 088734
£22.21
4 Part number 136882, back panel BACK PANEL
Vaillant part no. 136882
£21.29
5 Part number 114286, Knobs, green, kit of 3 KNOBS, GREEN, KIT OF 3
Vaillant part no. 114286
£17.58
5 Part number 114288, Knobs, grey, kit of 3 KNOBS, GREY, KIT OF 3
Vaillant part no. 114288
£11.36
7 Part number 077978, Cover display (grey) COVER DISPLAY (GREY)
Vaillant part no. 077978

8 Part number 132925, Securing fastener (PK10) SECURING FASTENER (PK10)
Vaillant part no. 132925
£11.38
9 Part number 101271, Pressure gauge PRESSURE GAUGE
Vaillant part no. 101271
£38.09
10 Part number 287450, Transformer TRANSFORMER
Vaillant part no. 287450
£30.00
11 Part number 0020034604, Printed circuit board PRINTED CIRCUIT BOARD
Vaillant part no. 0020034604
£258.01
12 Part number 256097, Wiring harness WIRING HARNESS
Vaillant part no. 256097
£65.94
13 Part number 219629, Clip (PK5) CLIP (PK5)
Vaillant part no. 219629
£10.04
14 Part number 077958, covering plate COVERING PLATE
Vaillant part no. 077958

16 Part number 0020130491, Cover control slot, grey COVER CONTROL SLOT, GREY
Vaillant part no. 0020130491
£6.66
