BAXI
28 COMBI ERP (SERIAL NO. ENDING IN BC ISSUE 2) - (Heat Exchanger)
Appliance Code: 47-077-05 BC

Appliance Diagram


Heat Exchanger diagram for Baxi 28 Combi Erp (Serial No. Ending IN BC Issue 2)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

300 Part number 5122147, 4 ELEMENT EXCHANGER 4 ELEMENT EXCHANGER
Baxi part no. 5122147		 £407.44
301 Part number 5114776, GASKET GASKET
Baxi part no. 5114776		 £6.52
302 Part number 5114747, NTC SENSOR NTC SENSOR
Baxi part no. 5114747		 £15.58
303 Part number 5114686, INSULATION PANEL INSULATION PANEL
Baxi part no. 5114686		 £26.24
304 Part number 5114755, COMB. CHAMBER GASKET COMB. CHAMBER GASKET
Baxi part no. 5114755		 £15.61
305 Part number 5114750, COMB. CHAMBER UPPER COVER COMB. CHAMBER UPPER COVER
Baxi part no. 5114750		 £39.25
305   NUT WITH FLANGE M6
Baxi part no. 710116001		 £2.24
306 Part number 5122149, 4 ELEMENT BURNER 4 ELEMENT BURNER
Baxi part no. 5122149		 £62.64
307 Part number 5114751, BURNER GASKET BURNER GASKET
Baxi part no. 5114751		 £3.26
308 Part number 5114769, AIR/GAS COVER ASSY AIR/GAS COVER ASSY
Baxi part no. 5114769		 £35.08
309 Part number 5114758, FAN GASKET FAN GASKET
Baxi part no. 5114758		 £5.88
310 Part number 5114682, PRESSURE SENSING VENTURI PRESSURE SENSING VENTURI
Baxi part no. 5114682		 £52.94
311 Part number 5121447, FAN FAN
Baxi part no. 5121447		 £157.89
312 Part number 5114701, LEAD - IGNITION LEAD - IGNITION
Baxi part no. 5114701		 £14.36
313 Part number 5114770, EARTH/IGNITOR CABLE EARTH/IGNITOR CABLE
Baxi part no. 5114770		 £4.57
314 Part number 5114749, FLAME SENSING CABLE FLAME SENSING CABLE
Baxi part no. 5114749		 £13.82
315 Part number 720222801, KIT - ELECTRODE IGNITION KIT - ELECTRODE IGNITION
Baxi part no. 720222801		 £25.98
316 Part number 720222901, KIT - ELECTRODE IONISATION KIT - ELECTRODE IONISATION
Baxi part no. 720222901		 £24.16
317 Part number 5114772, GASKET - ELECTRODE GASKET - ELECTRODE
Baxi part no. 5114772		 £3.26
318 Part number 5114752, ELECTRODE GASKET ELECTRODE GASKET
Baxi part no. 5114752		 £3.26
319 Part number 5114727, INJECTOR D.7,5 INJECTOR D.7,5
Baxi part no. 5114727		 £9.51
320 Part number 5129198, VIEWING WINDOW ASSY VIEWING WINDOW ASSY
Baxi part no. 5129198		 £31.29
321 Part number 5114759, GASKET GASKET
Baxi part no. 5114759		 £4.00
322 Part number 5115060, REAR INSULATION REAR INSULATION
Baxi part no. 5115060		 £9.51
323   4 ELEMENT GAS EXT
Baxi part no. 5122150		 £70.35
324 Part number 7212904, KIT AIR VENT PLUG AND CLIP KIT AIR VENT PLUG AND CLIP
Baxi part no. 7212904		 £14.83
325   4 ELEMENTS SHIM
Baxi part no. 5122148		 £16.83
326 Part number 7648326, KIT PRESSURE COMBI SYS ERP KIT PRESSURE COMBI SYS ERP
Baxi part no. 7648326		 £38.90
327   KIT - SCREW M2.5X6 POZI FL
Baxi part no. 7648883		 £2.86
328   KIT - BRACKET PRESSURE SWITCH
Baxi part no. 7648888		 £13.70
