POTTERTON
TITANIUM 28 - (Hydraulics)
Appliance Code: 47-393-40

Appliance Diagram


Hydraulics diagram for Potterton Titanium 28Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

400 Part number 248723, NOW USE 7223558 HEAT EXCHANGER DHW NOW USE 7223558 HEAT EXCHANGER DHW
Potterton part no. 248723
400 Part number 7223558, PLATE HEAT EX 20 PLATES KIT PLATE HEAT EX 20 PLATES KIT
Potterton part no. 7223558		 £137.55
403 Part number 248049, GASKET - PLATE HEAT EXCHANGER GASKET - PLATE HEAT EXCHANGER
Potterton part no. 248049		 £5.78
404 Part number 5114767, SENSOR - HALL EFFECT SENSOR - HALL EFFECT
Potterton part no. 5114767		 £16.66
405 Part number 5114710, HYDRAULIC INLET ASSY HYDRAULIC INLET ASSY
Potterton part no. 5114710		 £102.10
406 Part number 248055, DRAIN TAP DRAIN TAP
Potterton part no. 248055		 £9.88
407 Part number 248056, SAFETY VALVE - 3 BAR (FEMALE) SAFETY VALVE - 3 BAR (FEMALE)
Potterton part no. 248056		 £14.76
408 Part number 5114699, GAS PIPE ASSY GAS PIPE ASSY
Potterton part no. 5114699		 £18.73
409 Part number 5114704, RETURN PIPE ASSY RETURN PIPE ASSY
Potterton part no. 5114704		 £30.18
410 Part number 247745, SEALING WASHER G. 3/4 SEALING WASHER G. 3/4
Potterton part no. 247745		 £3.16
411 Part number 5114771, GROMMET GROMMET
Potterton part no. 5114771		 £3.26
412 Part number 248054, PUMP CONNECTION ELEMENT PUMP CONNECTION ELEMENT
Potterton part no. 248054		 £6.31
413 Part number 248043, AIR VENT - AUTOMATIC AIR VENT - AUTOMATIC
Potterton part no. 248043		 £12.50
414 Part number 248044, O-RING - AIR VENT O-RING - AIR VENT
Potterton part no. 248044		 £3.16
415 Part number 248042, NOW USE 7722642 PUMP (15-60) - 105 NOW USE 7722642 PUMP (15-60) - 105
Potterton part no. 248042
415 Part number 26009031, SCREW M6 X 25MM SCREW M6 X 25MM
Potterton part no. 26009031		 £3.26
415 Part number 7722642, PUMP 15-60 105 PUMP 15-60 105
Potterton part no. 7722642		 £254.27
416 Part number 247429, O RING 22MM X 3MM O RING 22MM X 3MM
Potterton part no. 247429		 £3.16
417 Part number 248021, O RING 17.86 x 2.62 O RING 17.86 X 2.62
Potterton part no. 248021		 £3.16
418 Part number 5114730, PIPE PIPE
Potterton part no. 5114730		 £35.70
419 Part number 5114748, PRESSURE SWITCH PRESSURE SWITCH
Potterton part no. 5114748		 £19.79
420 Part number 248079, THERMOSTAT - LIMIT THERMOSTAT - LIMIT
Potterton part no. 248079		 £12.56
421 Part number 5114725, NTC SENSOR NTC SENSOR
Potterton part no. 5114725		 £11.06
422   KIT GAS VALVE
Potterton part no. 720301001		 £80.78
422   GAS VALVE ADAPTER
Potterton part no. 7213642		 £23.72
426 Part number 7216534, MOTOR BLACK/WHITE INC CLIP MOTOR BLACK/WHITE INC CLIP
Potterton part no. 7216534		 £46.67
427 Part number 5132456, NOW USE 7224764 VALVE-3 WAY OUTLET ASSEMBLY NOW USE 7224764 VALVE-3 WAY OUTLET ASSEMBLY
Potterton part no. 5132456
427 Part number 7224764, VALVE 3 WAY WITHOUT BYPASS KIT VALVE 3 WAY WITHOUT BYPASS KIT
Potterton part no. 7224764		 £113.96
428 Part number 248736, CLIP-RETAINING CLIP-RETAINING
Potterton part no. 248736		 £4.57
429 Part number 248069, GASKET GASKET
Potterton part no. 248069		 £3.34
430 Part number 247776, CLAMP - INPUT CABLE CLAMP - INPUT CABLE
Potterton part no. 247776		 £4.38
431 Part number 247996, PRESSURE SWITCH PIPE PRESSURE SWITCH PIPE
Potterton part no. 247996		 £6.07
432 Part number 5114690, FIXING CLIP FIXING CLIP
Potterton part no. 5114690		 £4.04
433 Part number 248000, WASHER - SEALING WASHER - SEALING
Potterton part no. 248000		 £3.16
435 Part number 607939, SCREW M3 X 8MM TAPTITE SCREW M3 X 8MM TAPTITE
Potterton part no. 607939		 £3.12
436 Part number 710115301, SCREW M5X14 HEX POZI SCREW M5X14 HEX POZI
Potterton part no. 710115301		 £2.55
438 Part number 0590430002, M4 X 30 POZI PAN HD SCREW M4 X 30 POZI PAN HD SCREW
Potterton part no. 0590430002		 £2.92
439   SCREW M4X12 ST/ST
Potterton part no. 0560449		 £3.12
440 Part number 062617, SCR-ST-No8x1/2 PAN POZ.TYPE B SCR-ST-NO8X1/2 PAN POZ.TYPE B
Potterton part no. 062617		 £3.16
441 Part number 248000, WASHER - SEALING WASHER - SEALING
Potterton part no. 248000		 £3.16
442 Part number 5114712, FLOW RESTRICTOR FLOW RESTRICTOR
Potterton part no. 5114712		 £7.74
