WORCESTER
CAMRAY EXTERNAL SYS 18/25 7716100127 - (RD Burner)
Appliance Code: 7716100127

Appliance Diagram


RD Burner diagram for Worcester Camray External Sys 18/25 7716100127Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 3006552, ELECTRODE CLAMP (10 PCS) ELECTRODE CLAMP (10 PCS)
Riello part no. 3006552		 £19.47
0   NOZZLE DANFOSS 0.75 80 DEG ES
Worcester part no. 87161093870		 £16.60
0 Part number 87161405540, NIPPLE 1/4" CONICAL X 1/4" CONICAL (BEFORE FD008) NIPPLE 1/4" CONICAL X 1/4" CONICAL (BEFORE FD008)
Worcester part no. 87161405540		 £19.47
0 Part number 87161427690, WASHER COPPER 1/4" WASHER COPPER 1/4"
Worcester part no. 87161427690		 £2.45
0   NOZZLE DANFOSS 0.60 80 DEG ES
Worcester part no. 87161566700		 £22.48
0 Part number 87161566710, NOZZLE DANFOSS 0.55 80 DEG EH NOZZLE DANFOSS 0.55 80 DEG EH
Worcester part no. 87161566710		 £19.89
1   RUBBER GASKET WITH HOLES
Riello part no. 3008512		 £10.56
2   6 POLE SOCKET
Riello part no. 3020428		 £28.59
3   BURNER TUBE T2 SH 18/25
Worcester part no. 87161127800		 £41.74
4 Part number 3008860, ELECTRODE GROUP ELECTRODE GROUP
Riello part no. 3008860		 £21.14
5 Part number 3008875, ELECTRODE CLAMP ELECTRODE CLAMP
Riello part no. 3008875		 £8.20
6 Part number 3008861, NOZZLE HOLDER NOZZLE HOLDER
Riello part no. 3008861		 £14.87
7 Part number 3008862, COLLAR COLLAR
Riello part no. 3008862		 £43.03
8 Part number 3008794, HIGH VOLTAGE LEAD (6 PCS) HIGH VOLTAGE LEAD (6 PCS)
Riello part no. 3008794		 £11.58
9 Part number 3008647, AIR DAMPER ASSEMBLY AIR DAMPER ASSEMBLY
Riello part no. 3008647		 £79.92
10 Part number 3005788, FAN FAN
Riello part no. 3005788		 £19.20
11 Part number 3007541, NOW USE 20132553 PHOTO CELL NOW USE 20132553 PHOTO CELL
Riello part no. 3007541
11   PHOTODIODE ANA REP 3008471,3007541, 3062784
Riello part no. 20132553		 £36.47
12 Part number 20071576, CAPACITOR CAPACITOR
Riello part no. 20071576		 £30.32
12 Part number 3002837, NOW USE 20071576 CAPACITOR NOW USE 20071576 CAPACITOR
Riello part no. 3002837
13 Part number 3007871, NEEDLE VALVE NEEDLE VALVE
Riello part no. 3007871		 £27.29
14 Part number 20032135, PRESSURE REGULATOR PRESSURE REGULATOR
Riello part no. 20032135		 £4.89
15   AIR DAMPER
Riello part no. 3020309		 £29.61
16 Part number 20030953, RIELLO - OIL PUMP RIELLO - OIL PUMP
Riello part no. 20030953		 £125.51
18 Part number 3020436, PUMP FILTER 3020436 RDB 3008653 PUMP FILTER 3020436 RDB 3008653
Riello part no. 3020436		 £8.40
19 Part number 3009046, CONNECTOR (BOULTERS) CONNECTOR (BOULTERS)
Riello part no. 3009046		 £3.66
20 Part number 20022604, OIL HOSE HNBR 600mm OIL HOSE HNBR 600MM
Riello part no. 20022604		 £20.38
20 Part number 87161153120, OIL HOSE HNBR 900mm (AFTER FD009) OIL HOSE HNBR 900MM (AFTER FD009)
Worcester part no. 87161153120		 £21.86
21   TUBE
Worcester part no. 87161093320		 £28.82
22 Part number 3008876, PRESSURE GAUGE EXTENSION (RDB) PRESSURE GAUGE EXTENSION (RDB)
Riello part no. 3008876		 £14.98
23 Part number 3000443, COUPLING (10PCS) COUPLING (10PCS)
Riello part no. 3000443		 £7.74
24 Part number 3008648, COIL COIL
Riello part no. 3008648		 £21.09
25 Part number 3002836, NOW USE 20071577 RDB MOTOR C/W CAPACITOR NOW USE 20071577 RDB MOTOR C/W CAPACITOR
Riello part no. 3002836
25 Part number 20071577, Motor C/W Capacitor MOTOR C/W CAPACITOR
Riello part no. 20071577		 £124.05
26 Part number 3008649, PROTECTION PROTECTION
Riello part no. 3008649		 £11.09
26   NOW USE 3008649 PROTECTION COVER (AFTER FD009)
Worcester part no. 87161093330
27 Part number 3008652, CONTROL BOX 535 SE/LD CONTROL BOX 535 SE/LD
Riello part no. 3008652		 £125.32
28 Part number 3008851, H T LEADS ( WAS 3008877) H T LEADS ( WAS 3008877)
Riello part no. 3008851		 £7.35
30 Part number 3008878, SEAL KIT SEAL KIT
Riello part no. 3008878		 £9.42
33   AIR DIRECTION PLATE
Worcester part no. 87161127790		 £7.73
34 Part number 87161152260, RESTRICTING WASHER & CIRCLIP KIT RESTRICTING WASHER & CIRCLIP KIT
Worcester part no. 87161152260		 £10.59
35 Part number 3006384, FRONT PIECE FRONT PIECE
Riello part no. 3006384		 £13.18
36 Part number 3008879, COVER COVER
Riello part no. 3008879		 £39.19
