VAILLANT
ECOTEC PLUS VU GB 1006/5-5 R2 2013-2014 - (16 Pump)
Appliance Code: 41-044-69 R2

Appliance Diagram


16 Pump diagram for Vaillant Ecotec Plus VU GB 1006/5-5 R2 2013-2014Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 193543, cap, cpl. CAP, CPL.
Vaillant part no. 193543
£4.45
1 Part number 0020143538, Tube TUBE
Vaillant part no. 0020143538
£174.05
2 Part number 0020174846, Pressure relief valve, 6 bar PRESSURE RELIEF VALVE, 6 BAR
Vaillant part no. 0020174846
£49.95
3 Part number 0020143503, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 0020143503
£11.30
4 Part number 0020143539, NOW USE 0020240341 Pump NOW USE 0020240341 PUMP
Vaillant part no. 0020143539

4 Part number 0020143541, Pump, HE PUMP, HE
Vaillant part no. 0020143541
£842.35
4 Part number 0020240341, Pump PUMP
Vaillant part no. 0020240341
£414.47
5 Part number 0020143542, Tube TUBE
Vaillant part no. 0020143542
£37.21
6 Part number 0020143526, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 0020143526
£6.71
7 Part number 106350, drain cock DRAIN COCK
Vaillant part no. 106350
£7.61
8 Part number 0020143471, Tube TUBE
Vaillant part no. 0020143471
£98.36
11 Part number 0020059560, Isolation Valve ISOLATION VALVE
Vaillant part no. 0020059560
£143.78
13 Part number 0020143526, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 0020143526
£6.71
