VAILLANT
VIH C 120/3 1995-1999 - (Exploded View)
Appliance Code: VIH C 120-3

Appliance Diagram


Exploded View diagram for Vaillant VIH C 120/3 1995-1999Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 114297, thermostat knob THERMOSTAT KNOB
Vaillant part no. 114297
2 Part number 060009, Screw SCREW
Vaillant part no. 060009		 £6.66
3   OBSOLETE COVER PLATE
Vaillant part no. 072385
4   OBSOLETE INSULATION CAP
Vaillant part no. 203887
5 Part number 101819, thermostat THERMOSTAT
Vaillant part no. 101819		 £48.14
6 Part number 060520, protection tube PROTECTION TUBE
Vaillant part no. 060520		 £10.65
7   CLIP (THERMOSTAT RETAINING)
Vaillant part no. 183563		 £3.91
8   T-PIECE (RP 1 X RP 1 X RP 1/2)
Vaillant part no. 492109		 £5.55
9   DE-AERATION SCREW
Vaillant part no. 177507
10   OBSOLETE DOUBLE NIPPLE
Vaillant part no. 136382
11 Part number 980603, Gasket 22mm GASKET 22MM
Vaillant part no. 980603
12 Part number 111244, sleeve nut SLEEVE NUT
Vaillant part no. 111244		 £3.91
13 Part number 0020107774, OBSOLETE FLANGE JOINT OBSOLETE FLANGE JOINT
Vaillant part no. 0020107774
14   OBSOLETE FLANGE
Vaillant part no. 089386
15   OBSOLETE CONNECTION TUBE
Vaillant part no. 083366
16 Part number 094030, tube, cpl. (L=690 mm, D=20 mm) TUBE, CPL. (L=690 MM, D=20 MM)
Vaillant part no. 094030		 £17.55
17   OBSOLETE CYLINDER SCREW
Vaillant part no. 490172
19 Part number 064505, immersion heater (UI 9 TC) IMMERSION HEATER (UI 9 TC)
Vaillant part no. 064505		 £159.97
21   OBSOLETE INSULATION CAP
Vaillant part no. 203842
22 Part number 0020107793, ANODE ANODE
Vaillant part no. 0020107793		 £39.68
23 Part number 083408, Compression fitting (R 1/2) COMPRESSION FITTING (R 1/2)
Vaillant part no. 083408
24 Part number 083408, Compression fitting (R 1/2) COMPRESSION FITTING (R 1/2)
Vaillant part no. 083408
25 Part number 083408, Compression fitting (R 1/2) COMPRESSION FITTING (R 1/2)
Vaillant part no. 083408
26 Part number 190757, Temperature and Pressure relief valve TEMPERATURE AND PRESSURE RELIEF VALVE
Vaillant part no. 190757		 £149.10
27   OBSOLETE T-PIECE (RP 3/4 X RP 3/4 X RP 1/2)
Vaillant part no. 129240
28   OBSOLETE DOUBLE NIPPLE
Vaillant part no. 136384
29 Part number 050734, Valve 3-port VALVE 3-PORT
Vaillant part no. 050734
30   CONNECTION TUBE
Vaillant part no. 084968		 £4.88
31   OBSOLETE COVER
Vaillant part no. 076091
32 Part number 082205, drain valve DRAIN VALVE
Vaillant part no. 082205		 £11.30
33 Part number 0020218158, Foot FOOT
Vaillant part no. 0020218158		 £6.53
34 Part number 149113, Pressure reducing valve PRESSURE REDUCING VALVE
Vaillant part no. 149113		 £211.43
35 Part number 149109, pressure reducing valve cartridge PRESSURE REDUCING VALVE CARTRIDGE
Vaillant part no. 149109
36 Part number 149210, Pressure relief valve PRESSURE RELIEF VALVE
Vaillant part no. 149210
37 Part number 190709, pressure limiting valve inset PRESSURE LIMITING VALVE INSET
Vaillant part no. 190709
