ALPHA
OCEAN STYLE 80OF - (Exploded View)
Appliance Code: 47-532-03

Appliance Diagram


Exploded View diagram for Alpha Ocean Style 80OFClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 6.1000700, SEAL KIT 700 (WATER COMPLETE) (STYLE) SEAL KIT 700 (WATER COMPLETE) (STYLE)
Alpha part no. 6.1000700
£50.61
0 Part number 6.1000705, SEAL KIT 705 (DHW HEAT EXCH) (STYLE) SEAL KIT 705 (DHW HEAT EXCH) (STYLE)
Alpha part no. 6.1000705
£15.15
0 Part number 6.1000710, SEAL KIT 710 (3 PORT VALVE) (STYLE) SEAL KIT 710 (3 PORT VALVE) (STYLE)
Alpha part no. 6.1000710
£35.97
0 Part number 6.1000715, SEAL KIT 715 (W/F/S-PRI HT EX) (STYLE) SEAL KIT 715 (W/F/S-PRI HT EX) (STYLE)
Alpha part no. 6.1000715

0 Part number 6.1000720, SEAL KIT 720 (ISOL VALVES) (STYLE) SEAL KIT 720 (ISOL VALVES) (STYLE)
Alpha part no. 6.1000720
£15.31
0 Part number 6.1000725, SEAL KIT 725 (GAS COMPLETE) (STYLE) SEAL KIT 725 (GAS COMPLETE) (STYLE)
Alpha part no. 6.1000725
£10.60
0 Part number 6.1000730, SEAL KIT 730 (FAN/FLUE) (STYLE SEAL KIT 730 (FAN/FLUE) (STYLE
Alpha part no. 6.1000730
£15.07
1   OBSOLETE BURNER ASSY (STYLE)
Alpha part no. 6.5615061

17   MAIN BURNER INJECTOR(NG)D=1.18 (STYLE)
Alpha part no. 6.5209150
£5.04
31   MAIN BURNER INJECTOR(NG)D=1.18 (STYLE)
Alpha part no. 6.5209150
£5.04
32 Part number 6.5615071, GAS VALVE (NG) (V4600Q)(STYLE) GAS VALVE (NG) (V4600Q)(STYLE)
Alpha part no. 6.5615071
£269.27
33 Part number 6.5604732, OBSOLETE PILOT BURNER (STYLE) OBSOLETE PILOT BURNER (STYLE)
Alpha part no. 6.5604732

34 Part number 6.5201550, OBSOLETE PILOT INJECTOR (NG) D=0.27 OBSOLETE PILOT INJECTOR (NG) D=0.27
Alpha part no. 6.5201550

35   OBSOLETE ELECTRODE LEAD 450MM (STYLE)
Alpha part no. 6.8413451

36 Part number 6.8420930, SPARK ELECTRODE-STY/240P/280P SPARK ELECTRODE-STY/240P/280P
Alpha part no. 6.8420930
£16.81
37 Part number 6.5611791, NOW USE 1.015610 PUMP NOW USE 1.015610 PUMP
Alpha part no. 6.5611791

42 Part number 6.5616401, HEATING T/STAT KNOB (STYLE FF) HEATING T/STAT KNOB (STYLE FF)
Alpha part no. 6.5616401
£15.96
45 Part number 6.5614712, LIMIT T/STAT & LEADS (STYLE) LIMIT T/STAT & LEADS (STYLE)
Alpha part no. 6.5614712
£68.69
46 Part number 6.5614721, THERMOCOUPLE (STYLE FF) THERMOCOUPLE (STYLE FF)
Alpha part no. 6.5614721
£17.35
47   THERMOCOUPLE CONNECTOR(STYLE)
Alpha part no. 6.5202491

50   NATURAL DRAUGHT DIVERTER (STYLE OF)
Alpha part no. 6.5624600
£82.43
52   OBSOLETE DRIP TRAY
Alpha part no. 6.5618601

58   OBSOLETE WATER FLOW SWITCH & PIPE STYLE
Alpha part no. 6.5635010

60 Part number 6.5610362, OBSOLETE DHW HEAT EXCHANGER (STYLE) OBSOLETE DHW HEAT EXCHANGER (STYLE)
Alpha part no. 6.5610362

62 Part number 6.5617081, MICROSWITCH ASSY(3 PORT VALVE) (STYLE) MICROSWITCH ASSY(3 PORT VALVE) (STYLE)
Alpha part no. 6.5617081
£56.14
64 Part number 6.5623431, 3 PORT VALVE COMPLETE (STYLE) 3 PORT VALVE COMPLETE (STYLE)
Alpha part no. 6.5623431

66 Part number 6.5618331, SELECTOR KNOB TAP/RAD SYMBOLS (STYLE FF) SELECTOR KNOB TAP/RAD SYMBOLS (STYLE FF)
Alpha part no. 6.5618331
£16.07
67 Part number 6.5606221, OBSOLETE HEATING EXPANSION VESSEL STYLE OBSOLETE HEATING EXPANSION VESSEL STYLE
Alpha part no. 6.5606221

68 Part number 6.5624241, WATER HAMMER ARRESTOR CALF/525 525040 WATER HAMMER ARRESTOR CALF/525 525040
Alpha part no. 6.5624241
£74.36
70 Part number 6.5617451, NOW USE 6.5617441A PRIMARY HEAT EXCHANGER (STYLE) NOW USE 6.5617441A PRIMARY HEAT EXCHANGER (STYLE)
Alpha part no. 6.5617451

73   INSULATION SET (COMB CHAMBER)
Alpha part no. 6.5614731

77   INSULATION SET (COMB CHAMBER)
Alpha part no. 6.5614731

81 Part number 6.1000725, SEAL KIT 725 (GAS COMPLETE) (STYLE) SEAL KIT 725 (GAS COMPLETE) (STYLE)
Alpha part no. 6.1000725
£10.60
82   PEIZO SPARK GENERATOR STYLE OF
Alpha part no. 6.8433221
£36.44
85 Part number 6.8922330, PRESSURE GAUGE (240/280/500) (STYLE FF) PRESSURE GAUGE (240/280/500) (STYLE FF)
Alpha part no. 6.8922330

87   PILOT TUBE COMPLETE (STYLE)
Alpha part no. 6.5614851
£27.78
91 Part number 6.5600731, OBSOLETE AUTOMATIC AIR VENT (STYLE) OBSOLETE AUTOMATIC AIR VENT (STYLE)
Alpha part no. 6.5600731

100   OBSOLETE PIPE-MAINS INLET (STYLE)
Alpha part no. 6.5610941
£37.66
101   BRASS CAP 1/2" (STYLE)
Alpha part no. 6.5201351
£8.36
103   CONTROL COVER R/H/S (STYLE)
Alpha part no. 6.5615352
£19.54
106 Part number 6.5630531, NOW USE 6.5630531A 3 PORT DIVERTER BODY (STYLE) NOW USE 6.5630531A 3 PORT DIVERTER BODY (STYLE)
Alpha part no. 6.5630531

106 Part number 6.5630531A, DIVERTER BODY AND SEAL KIT 710 DIVERTER BODY AND SEAL KIT 710
Alpha part no. 6.5630531A
£132.72
107   OBSOLETE PIPE-HEATING EXPANSION VESSEL
Alpha part no. 6.5607391

108   OBSOLETE CONTROL PANEL
Alpha part no. 6.5621161

110 Part number 6.5623410, DOMESTIC PRESSURE SENSOR-STYLE DOMESTIC PRESSURE SENSOR-STYLE
Alpha part no. 6.5623410
£101.84
111   OBSOLETE FLOW SWITCH CONNECTION PIPE
Alpha part no. 6.5610161

127   SCREW HTG STAT/EXT BAR
Alpha part no. 6.8100611
£3.27
129   M5 X 10 BOLT
Alpha part no. 6.8101181
£3.80
132   OBSOLETE PIPE RETAINING CLIP 3 PRT VLVE
Alpha part no. 6.5101841
£5.37
133 Part number 6.5610751, OBSOLETE PIPE-RETAINING PLATE (RIGHT) OBSOLETE PIPE-RETAINING PLATE (RIGHT)
Alpha part no. 6.5610751

137   OBSOLETE PIPE-GAS INLET/GAS VALVE
Alpha part no. 6.5615441

141   INSULATION SET (COMB CHAMBER)
Alpha part no. 6.5614731

142   OBSOLETE GAS VALVE KNOB - SHAFT
Alpha part no. 6.5400861

143   GAS VALVE KNOB (WHITE)(STYLE)
Alpha part no. 6.5616411
£15.96
145   OBSOLETE PIPE-RETAINING PLATE (LEFT)
Alpha part no. 6.5610741

146   OBSOLETE PIPE-3PRT / DHW EXCH(STYLE FF)
Alpha part no. 6.5622671

152   OBSOLETE WHITE UNDERSIDE GUARD
Alpha part no. 6.5109031

153   OBSOLETE LOWER PLASTIC PANEL HINGE
Alpha part no. 6.5401901

155   ISO VALVE RETAINING CLIP 1/2
Alpha part no. 6.5102701
£4.15
172   PIPE-D H W OUTLET (STYLE)
Alpha part no. 6.5615311
£38.94
174   OBSOLETE PIPE-HEATING RETURN (STYLE)
Alpha part no. 6.5608363

178   PIPE PRIMARY FLOW (STYLE OF)
Alpha part no. 6.5617961
£41.78
179   OBSOLETE PIPE-HEATING FLOW (STYLE FF)
Alpha part no. 6.5605911

180   OBSOLETE PIPE-DHW EXCH / 3 PORT VLV
Alpha part no. 6.5203191
