ALPHA
OCEAN STYLE 80OF - (Pipe Work)
Appliance Code: 47-532-03

Appliance Diagram


Pipe Work diagram for Alpha Ocean Style 80OFClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

72 Part number 6.5608551, NOW USE 1.021738 PRESSURE RELIEF VALVE NOW USE 1.021738 PRESSURE RELIEF VALVE
Alpha part no. 6.5608551

80 Part number 6.5614281, OBSOLETE GAS COCK (STYLE FF) OBSOLETE GAS COCK (STYLE FF)
Alpha part no. 6.5614281

154   OBSOLETE ISO VALVE RETAINING CLIP 3/4IN
Alpha part no. 6.5102691

156   OBSOLETE 3/4 UNION ELBOW
Alpha part no. 6.5615531

157   3/4" GAS COCK UNION (STYLE)
Alpha part no. 6.5615521
£18.64
158   1/2" UNION ELBOW (STYLE)
Alpha part no. 6.5615541
£15.63
159   OBSOLETE HTG / RTN ISO VALVE WITH DRAIN
Alpha part no. 6.5621431

160 Part number 6.5626412, OBSOLETE MAINS WATER INLET ISOL VLV 1/2 OBSOLETE MAINS WATER INLET ISOL VLV 1/2
Alpha part no. 6.5626412

161   OBSOLETE FLOW/RETURN HEATING ISOL VLV
Alpha part no. 6.5613691

163   OBSOLETE SAFETY VALVE ELBOW (STYLE)
Alpha part no. 6.5610111

164   EXTENSION BAR (TOP BRACKET)
Alpha part no. 6.5610701
£16.34
166 Part number 6.1000720, SEAL KIT 720 (ISOL VALVES) (STYLE) SEAL KIT 720 (ISOL VALVES) (STYLE)
Alpha part no. 6.1000720
£15.31
167 Part number 6.1000720, SEAL KIT 720 (ISOL VALVES) (STYLE) SEAL KIT 720 (ISOL VALVES) (STYLE)
Alpha part no. 6.1000720
£15.31
