ALPHA
INTEC 26C - (Exploded View)
Appliance Code: 47-532-47

Appliance Diagram


Exploded View diagram for Alpha Intec 26CClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 1.030996, EXPANSION VESSEL EXPANSION VESSEL
Alpha part no. 1.030996		 £118.12
3 Part number 3.021702, PUMP PUMP
Alpha part no. 3.021702		 £212.87
9   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
10   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
11   GAS MANIFOLD COVER
Alpha part no. 1.023442		 £34.03
15   AIR INTAKE PIPE
Alpha part no. 1.031101		 £50.04
16 Part number 1.027277, PRIMARY PRESSURE SWITCH PRIMARY PRESSURE SWITCH
Alpha part no. 1.027277		 £23.12
17   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
18   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
19   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
20   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
21   SCREW M4 X 6 - CONDENSATE TRAP
Alpha part no. 1.0153		 £1.12
22 Part number 1.027178, FAN FAN
Alpha part no. 1.027178		 £164.65
23 Part number 1.023999, BURNER CD25 BURNER CD25
Alpha part no. 1.023999		 £91.42
24   PRESSURE POINT CAP
Alpha part no. 1.025690		 £5.22
27 Part number 1.021972, SPRING PIPE CLAMP FOR D.22 SILICONE PIPE SPRING PIPE CLAMP FOR D.22 SILICONE PIPE
Alpha part no. 1.021972		 £1.13
29   SCREW M5 X 25
Alpha part no. 1.023578		 £0.53
30 Part number 1.028572, 3-WAY VALVE MOTOR 3-WAY VALVE MOTOR
Alpha part no. 1.028572		 £53.35
34   SCREW M5 X 8
Alpha part no. 1.1176		 £1.51
35   METAL SHEET CLIP - INTEC
Alpha part no. 2.014033		 £1.40
36   CONDENSATE DRAIN ELBOW
Alpha part no. 1.023581		 £12.32
37   PIPE COLD INLET (CD25/28X)
Alpha part no. 1.023583		 £14.36
38   TWO PUMP COUPLER FITTINGS OKIT
Alpha part no. 3.021694		 £16.40
43   M5 LOCK WASHER -STAINLESS STEEL (CD50)
Alpha part no. 1.012468		 £1.17
44 Part number 1.8372, M5 X 10 SCREW M5 X 10 SCREW
Alpha part no. 1.8372		 £0.38
48   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
54 Part number 1.016187, SILICONE TUBE 8 X 12 750mm SILICONE TUBE 8 X 12 750MM
Alpha part no. 1.016187		 £13.94
55 Part number 1.028647, COLD INLET BLOCK COLD INLET BLOCK
Alpha part no. 1.028647		 £45.22
56 Part number 1.024296, FLUE TEMPERATURE SENSOR FLUE TEMPERATURE SENSOR
Alpha part no. 1.024296		 £22.36
57   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
60   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
61   FAN FLANGE
Alpha part no. 1.031102		 £7.49
62   PLUG FOR POCKET FLANGE CD25/28/35C
Alpha part no. 1.021464		 £6.86
67   FLUE TURRET
Alpha part no. 1.030636		 £21.29
72 Part number 3.020380, 3-WAY MOTOR CARTRIDGE ASSEMBLY 3-WAY MOTOR CARTRIDGE ASSEMBLY
Alpha part no. 3.020380		 £190.66
74   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
75   CLIP - INTEC RANGE
Alpha part no. 1.029426		 £1.88
76   SCREW M5 X 16
Alpha part no. 1.010289		 £0.34
88 Part number 1.028650, AUTO BYPASS HOUSING AUTO BYPASS HOUSING
Alpha part no. 1.028650		 £103.51
89 Part number 1.028643, 3-BAR PRESSURE RELIEF VALVE 3-BAR PRESSURE RELIEF VALVE
Alpha part no. 1.028643		 £30.66
90   FLUE TRAY CONNECTION
Alpha part no. 1.030667		 £12.48
92   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
93   BURNER INSP WINDOW BRACKET
Alpha part no. 2.013322		 £2.40
94   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
97   GAS MANIFOLD
Alpha part no. 1.023334		 £94.21
98   COMB CHAMBER INS PANEL FRONT
Alpha part no. 1.024543		 £8.83
99   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
100 Part number 1.028548, HOUSING, OUTLET MANIFOLD HOUSING, OUTLET MANIFOLD
Alpha part no. 1.028548		 £84.04
105 Part number 3.017281, CONDENSATE TRAP CONDENSATE TRAP
Alpha part no. 3.017281		 £39.93
106 Part number 1.028570, NOW USE 1.035365 FLOW SWITCH NOW USE 1.035365 FLOW SWITCH
Alpha part no. 1.028570
106 Part number 1.035365, DHW FLOW SWITCH DHW FLOW SWITCH
Alpha part no. 1.035365		 £42.68
108   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
109 Part number 1.019144, PIPE- CONDENSATION DISCHARGE PIPE- CONDENSATION DISCHARGE
Alpha part no. 1.019144		 £11.76
110 Part number 1.031447, PRI HEAT EX - INT 26C,24X,18S PRI HEAT EX - INT 26C,24X,18S
Alpha part no. 1.031447		 £320.60
111   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
112 Part number 3.021689, BY-PASS ASSEMBLY BY-PASS ASSEMBLY
Alpha part no. 3.021689		 £33.38
114   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
115   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
116 Part number 1.025380, DHW TEMPERATURE SENSOR DHW TEMPERATURE SENSOR
Alpha part no. 1.025380		 £15.69
117   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
118   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
121 Part number 3.021692, DHW 12 PLATE HEAT EXCHANGER WITH SEAL KIT DHW 12 PLATE HEAT EXCHANGER WITH SEAL KIT
Alpha part no. 3.021692		 £134.44
126 Part number 1.016967, SPRING CLIP SILICONE TUBE SPRING CLIP SILICONE TUBE
Alpha part no. 1.016967		 £1.35
127 Part number 1.024387, T PIECE - MANIFOLD TRAY TUBE T PIECE - MANIFOLD TRAY TUBE
Alpha part no. 1.024387		 £8.11
135   VENTURI (CD24S/C)
Alpha part no. 1.010918		 £39.33
138   SCREW 3.5 X 6.4
Alpha part no. 1.1656		 £1.18
147 Part number 1.018162, SPARK GENERATOR (CD24S/C) SPARK GENERATOR (CD24S/C)
Alpha part no. 1.018162		 £36.49
156 Part number 3.016875, CONDENSATE TRAP, COMPLETE (CD18R) CONDENSATE TRAP, COMPLETE (CD18R)
Alpha part no. 3.016875		 £29.38
157   SCREW M4 X 8 (CD50) FLUE INLET / OUTLET MOULDING
Alpha part no. 1.2170		 £0.29
158 Part number 1.019228, DRAIN TAP - CONDENSATE TRAP DRAIN TAP - CONDENSATE TRAP
Alpha part no. 1.019228		 £6.15
159 Part number 3.017477, IGNITION ELECTRODE AND LEAD IGNITION ELECTRODE AND LEAD
Alpha part no. 3.017477		 £46.14
160   AIR TRAP PLUG
Alpha part no. 1.021892		 £0.25
161   SCREW 2.9 X 9.5 - SELF TAPPING
Alpha part no. 1.6984		 £1.12
170   M5 COPPER WASHER
Alpha part no. 1.016869		 £1.12
172   PRIMARY H/E SEAL KIT
Alpha part no. 3.022654		 £43.37
176 Part number 1.032007, FLAME SENSING ELECTRODE FLAME SENSING ELECTRODE
Alpha part no. 1.032007		 £30.42
177   HOSE UNION FOR SILICONE TUBES (CD24S/C)
Alpha part no. 1.6221		 £0.71
179 Part number 1.027110, AUTOMATIC AIR VENT AUTOMATIC AIR VENT
Alpha part no. 1.027110		 £56.22
183 Part number 1.021762, TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY) TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY)
Alpha part no. 1.021762		 £14.92
185   BRASS FAN PRESSURE PORT CD25/28/35C
Alpha part no. 1.024996		 £3.95
190   PUMP ONLY - INTEC
Alpha part no. 3.022793		 £205.69
196 Part number 1.025797, O/H THERMOSTAT 100c O/H THERMOSTAT 100C
Alpha part no. 1.025797		 £15.68
198   PIPE CLAMP(SILICONE)
Alpha part no. 1.010500		 £1.35
200   SCREW M5 X 14MM POZI-DRIVE
Alpha part no. 1.024084		 £1.17
202   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
204   FLEXIBLE HOSE (1.200)
Alpha part no. 1.025898		 £2.77
206 Part number 1.019654, L.600 HOSE (CD24S/C) L.600 HOSE (CD24S/C)
Alpha part no. 1.019654		 £16.27
208   WASHER M3 X 7 X 0.5MM (CD50)
Alpha part no. 1.011163		 £0.84
212 Part number 1.031823, GAS VALVE ASSEMBLY GAS VALVE ASSEMBLY
Alpha part no. 1.031823		 £146.31
213   M4 BRASS WASHER
Alpha part no. 1.0237		 £0.57
221   INJECTOR INTEC 26C,18S,24X LPG
Alpha part no. 1.022050		 £25.96
221   INJECTOR-INTEC 30C, 28 LPG
Alpha part no. 1.022052		 £81.79
221   MAIN INJECTOR 5.1MM
Alpha part no. 1.022472		 £14.63
221   BURNER INJECTOR - 6.80MM
Alpha part no. 1.031471		 £17.23
221   INTEC 28S, 34C, 40GS LPG INJECTOR
Alpha part no. 1.022049		 £20.60
222 Part number 1.0017, SCREW M6 X 12 (CB50) SCREW M6 X 12 (CB50)
Alpha part no. 1.0017		 £1.28
228   HYDRAULIC ASSEMBLY SEAL KIT
Alpha part no. 3.022653		 £16.69
363   FLUE AND AIR CONNECTION
Alpha part no. 3.022655		 £16.69
